Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com
INS-TCM-365/TCM-5B-22
Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com
INS-TCM-365/TCM-5B-22
Instruction Manual
TCM-365 and TCM-5B
US PATENT 9,713,217
TCM-365
TCM-5B
WEAPON SAFETY
FAILURE TO FOLLOW SAFETY AND OPERATING
MEASURES WHEN HANDLING A FIREARM OR THE
NIGHTSTICK TCM WHEN MOUNTED ON A FIREARM IS
DANGEROUS AND CAN RESULT IN SERIOUS INJURY,
DAMAGE TO PROPERTY, OR DEATH.
Use of a fi rearm under any circumstance is inherently
dangerous. SERIOUS INJURY OR EVEN DEATH may
result without proper training in the safe handling of
fi rearms. Proper training should be obtained from an
accredited fi rearms safety program conducted by a
qualifi ed instructor.
Read, understand and follow all of the safety
instructions that come with your fi rearm before
attaching your new TCM.
INSTALL THE BATTERY
SAFETY WARNING: ALWAYS ENSURE HANDGUN
IS SAFE AND UNLOADED BEFORE CHANGING THE
BATTERY.
Unscrew and remove the bezel.
Insert the included CR123A battery with the positive(+)
end fi rst.
Replace the bezel and turn until fully seated.
INSTALL THE LIGHT ONTO YOUR FIREARM
Push inward on the head of the rail clamp tension
thumbscrew to fully open the adjustable portion of the rail
clamp.
Rotate the rail clamp of the TCM onto your handgun’s rail.
Tighten the rail clamp tension thumbscrew by hand.
Use a coin to fully tighten the tension thumbscrew.
IMPORTANT: Periodically check to ensure that the rail
clamp tension thumbscrew remains tight.
PROGRAM THE USER-SELECTABLE
SETTINGS
To program the strobe or battery safe mode, both
switches are pressed at the same time. Light can be on or off.
Strobe and battery safe mode are disabled when product
arrives from the factory.
STROBE MODE
Press down quickly 5 times (less than 1 second between
presses) to enable or disable strobe mode.
After fi ve presses, the light will fl ash on and off 2 times to
confi rm a change in the strobe mode.
NOTE: The user-selected strobe mode is retained in
memory when batteries are removed or fully discharged.
BATTERY SAFE MODE
Press both switches and hold for 3 seconds to enable or
disable battery safe mode.
After three seconds the light will fl ash on and off 1 time to
confi rm a change in the battery safe mode.
NOTE: The battery safe mode reverts to disabled when
batteries are removed or fully discharged.
OPERATION
The left and right side switches operate independently.
Activation of either switch will turn on the light.
Turn on/off: Press down for .5 seconds or less and
release.
Momentary on: Press and hold for .5 seconds or longer.
Release to turn off.
If strobe is enabled, press down either switch quickly 2
times and hold on the second press to turn on strobe. (Less
than .5 seconds between presses.) Strobe remains on until
switch is released.
STROBE WARNING
Exposure to strobing lights may cause dizziness,
disorientation, and nausea. A very small percentage of people
suffer from photosensitive epilepsy and may experience
seizures or blackouts triggered by strobing lights. For more
information from the EPILEPSY FOUNDATION about
photosensitivity and seizures, please visit www.epilepsy.
com. Anyone who has had symptoms linked to this condition
should consult a doctor before using this product.
WARRANTY
LIMITED LIFETIME WARRANTY
Bayco Products, Inc. warrants this product to be free
from defects in workmanship and materials for the original
purchaser’s lifetime. The Limited Lifetime Warranty includes
the LEDs, housing and lenses. Rechargeable batteries,
chargers, switches, electronics and included accessories are
warranted for a period of two years with proof of purchase.
Normal wear and failures which are caused by accidents,
misuse, abuse, faulty installation and lightning damage are
excluded.
We will repair or replace this product should we determine
it to be defective. This is the only warranty, expressed or
implied, including any warranty of merchantability or fi tness
for a particular purpose.
For a complete copy of the warranty, go to www.
baycoproducts.com/nightstick-product-support/warranties.
Retain your receipt for proof of purchase.
Always assume every fi rearm is loaded and treat that
fi rearm as such.
Never point a fi rearm at anything that you are not willing
to destroy.
Never service your fi rearm or your TCM when mounted
on a fi rearm without fi rst activating the weapon’s safety
(if applicable), removing the magazine, opening the
action and physically and visually inspecting to make
sure that no ammunition is installed in the fi rearm.
WEAPON MOUNTED LIGHT SAFETY
Nightstick recommends that the TCM should only be
activated with the non-trigger hand (support hand) while
employing a two-hand grip on the handgun and with
the trigger fi nger fully outside the trigger guard when
applicable.
Thoroughly practice (employing safe training
conditions) with the TCM and an unloaded handgun
before using the weapon.
BEFORE ATTACHING, INSPECTING
OR SERVICING THE TCM
WARNING: IT IS IMPERATIVE THAT SAFETY
MEASURES BE EMPLOYED AT ALL TIMES WHILE
HANDLING A FIREARM.
Engage the safety on the fi rearm (if applicable).
Remove the magazine from the fi rearm (if applicable).
Open the action and visually and physically inspect the
chamber to be sure it is empty.
Keep the barrel pointed in a safe direction at all times and
never place your hand in front of the muzzle.
GENERAL SAFETY WARNINGS
NOT FOR USE ABOVE HAZARDOUS LOCATIONS
DO NOT use in explosive atmospheres, near fl ammable
liquids, or where explosion proof lamps are required.
DO NOT use in the proximity of vehicles or equipment
when there is a risk of fl ammable liquids coming into
contact with the fl ashlight.
DO NOT expose the batteries to water or salt water, or
allow the batteries to get wet.
DO NOT store the batteries with metallic objects that
may cause a short circuit.
Immediately discontinue use of the batteries if they emit
an unusual smell, feel hot, change color, change shape or
appear abnormal in any way.
Keep out of the reach of children.
MODEL COMPATIBILITY
The TCM-365 fi ts P365 Sig Sauer series handguns.
The TCM-5B fi ts Glock, Heckler & Koch, Smith &
Wesson, Beretta, Springfi eld Armory and many more 1913
Short Railed Subcompact handguns.
Visit nightstick.com TCM-365 and TCM-
-
-
--5B product
pages for specifi c model compatibility.
