Side 1/1
440
White Light
TURBO
White Light
HIGH
White Light
MID
White Light
LOW
White Light
LOWER
2×CR1231×18650
LUMENS
280
LUMENS
160
LUMENS
25
LUMENS
1
LUMENS
1
h
45
min
1
h
45
min
2
h
45
min
5
h
45
min
32
h
260
h
3
h
30
min
7
h
43
h
400
h
190m
(Beam Distance)
9000cd
(Peak Beam Intensity)
1.5m
(Impact Resistant)
IPX-8, 2m
(Waterproof AND Submersible)
®
Features
• Featuring five individual light sources: two main LEDs plus secondary red,
green and blue LEDs.
• Five selectable modes of output (red, green, blue, white and infrared)
• Dual side switches offer convenient control of color modes
• Purpose designed for military, hunting, detection and communication
applications
• White LED: CREE XP-G2 (R5) LED provides Maximum output of up to 440
lumens.
• Infrared LED provides 1500mW, 850nm
• Maximum runtime of up to 400 hours on lowest mode of output
• Integrated “Precision Digital Optics Technology” and Second generation of
‘Crystal Coating Technology’ provides extreme reflector performance
• Equipped with a unique multi-colored (red, green and blue) signaling mode
• Dual side switches control white and colored LEDs independently.
• Side switch features integrated power indicator light for displaying remaining
battery power (patented)
• Instant-On functionality: enter turbo mode directly
• Physical reverse polarity protection mechanism (patented)
• Stainless steel titanium-plated clip
• Stainless steel retaining ring protects the core components from damage
• Toughened ultra-clear mineral glass with anti-reflective coating
• Constructed from aero-grade aluminum alloy
• HAIII military grade hard-anodized finish
• Waterproof in accordance with IPX-8 (two meters submersible)
• Impact resistant to 1.5 meters
• Tail stand capability
Dimensions
Length: 143mm (5.63”)
Head Diameter: 40mm (1.57”)
Tail Diameter: 25.4mm (1”)
Weight: 138grams (4.87oz) (without battery)
Accessories
Quality holster, clip, tactical ring, lanyard, spare tail cap, spare O-ring
Optional accessories
Remote switch (RSW1), Gun Mount (GM02, GM03, GM04)
Battery Options
Brightness & Runtime
The All-Round Flashlight Expert
Momentary Illumination
Momentary illumination can be achieved by switching off the flashlight and then
half pressing and holding the tail switch. Simply release the switch to turn the
light off.
Switching ON/OFF
To switch ON: Press the button on the tailcap until a “click” is heard.
To switch OFF: Press the button on the tailcap a second time until a “click” is
heard.
Brightness Selection
Tips: Two side switches control the two main LEDs as well as strobe / beacon/
SOS modes.
With the light turned on at the tailcap, press the left switch repeatedly to cycle
though the following WHITE LED brightness levels: ultra-low, low, medium, high
and turbo. Once a desired setting is displayed, it will be saved by turning the light
off at the tail switch.
With the light turned on, press the COLOR(right) switch, it will get access to
Infrared Output.
Instant Turbo / Instant Infrared Mode
With the light turned off, press and hold a side switch and then press the tail
switch to go directly to Turbo Mode or Infrared Mode (left switch for turbo white
and right switch for Infrared). This function is designed to provide instant access
to the either the highest output of white light or Infrared mode.
NOTE: 1. Infrared light is invisible to the human eye and requires specialized
night vision equipment.
2. When use two CR123A batteries, after twenty minutes’ using of turbo
mode, the flashlight will lower its output automatically for preventing
overheating, and efficiently ensure the battery runtime.
Special Modes
With the light turned on, press and hold the left (white) switch to activate Strobe
mode. Press and hold in succession to cycle: Location Beacon, SOS, Strobe
mode.
With the light turned on, press and hold the right (colored) switch all the way
down for more than 1 second to cycle through the following modes :secondary
red -> secondary green -> secondary blue -> Red/Blue police warning Signals .
Press the switch again to turn this mode off.
NOTE: Among all special modes, only SOS and Location Beacon mode can not
be saved.
Power Tips
1. With the light switched on, the blue power indicator will blink once every two
seconds when power levels reach 50%.
2. With the light switched on, the blue power indicator will blink rapidly when
power levels are low.
Changing Batteries
When the power indicator blinks rapidly this indicates the batteries need to be
replaced. Alternatively if the light becomes dim or unresponsive to adjustment this
also indicates batteries need to be replaced.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin
coating of silicon-based lubricant.
Warranty Service
All NITECORE® products are warranted for quality. DOA / defective products can
be exchanged for replacement through a local distributor/dealer within the 14
days of purchase. After 14 days, all defective / malfunctioning NITECORE
®
products will be repaired free of charge for a period of 18 months from the date of
purchase. After 18 months, a limited warranty applies, covering the cost of labor
and maintenance, but not the cost of accessories or replacement parts. The
warranty is nullified in all of the following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by
unauthorized parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE
® products and services, please contact
your national NITECORE
® distributor or send an email to service@nitecore.com
The Nitecore official website shall prevail in case of any product data changes.
NOTICE
The above data has been
measured in accordance with
the international flashlight
testing standards ANSI/NEMA
FL1 using one x 3.7V
2600mAh Nitecore 18650
battery and 2 x 3V 1550mAh
Nitecore CR123 batteries
under laboratory conditions.
The data may vary slightly
during real-world use due to
battery type, individual usage
habits and environmental
factors.
NITECORE (SYSMAX) is a member of PLATO, participating in and helping to
develop the ANSI FL1 standard of measurement. Product testing data is in
accordance with these internationally recognized scientific standards.
SIZE
Nominal voltage
Compatible
Primary Lithium battery CR123 3V Y (Recommended)
18650 Rechargeable Li-ion battery 18650 3.7V Y (Recommended)
Rechargeable Li-ion battery RCR123 3.7V Y
User Manual
CI6
SYSMAX Industry Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address Rm1407-08, Glorious Tower, 850 East Dongfeng Road, ：
Guangzhou, China 510600
Operation Instructions
Battery Installation
Insert one 18650 battery or two CR123 /
RCR123 batteries with the positive pole
pointing forward (toward the light head).
WARNING
1. Ensure batteries are inserted with the
positive (+) end pointing to the head. The
Chameleon will not operate with
incorrectly inserted batteries.
2. Ensure when turning the Chameleon on,
the beam is directed a way from the eyes
of people or animals.
Thanks for purchasing NITECORE!
Please follow our facebook for
more info: NITECORE Flashlights
