User Manual
Features
• Premium CREE XM-L2 T6 LED
• Maximum output of 960 lumens
• High efficiency regulation circuit
• Maximum runtime of up to 28 hours
• Intelligent charging circuit with voltage detection charges safely and rapidly
• Integrated micro USB charging port is water, dust and impact resistant.
• Multiple output modes are conveniently accessed via rapid rotary switch
• User-defined mode provides customized brightness levels plus strobe and SOS modes.
• Intelligent memory function stores preferred brightness setting
• Broad voltage circuit accepts both rechargeable and non-rechargeable Lithium
batteries
• Optimized ultra-precise reflector offers a longer beam distance than competing
products
• Waterproof in accordance with IPX-8 (submersible to two meters)
• Stainless steel bezel ring protects core components from damage
• Toughened ultra-clear mineral glass with anti-reflective coating
• Constructed from aerospace-grade aluminum alloy
• HAIII military grade hard-anodized
• Reverse polarity protection
• Stainless steel titanium-plated clip
• Anti-rolling design
Dimensions
Length: 160mm (6.3”)
Head Diameter: 40mm (1.57”)
Tail Diameter: 25.4mm (1”)
Weight: 145grams (5.1oz)(without battery)
Thanks for purchasing NITECORE!
Battery Options
The All-Round Flashlight Expert
Operation instructions
Battery Installation
1. Unscrew the tail cap in a counter-clockwise
direction.
2. Insert one 18650 battery or two CR123
batteries with the positive pole pointing
forward (toward the light head).
NOTE:
Ensure batteries are inserted with the
positive (+) end pointing to the head. The
MH25 will not operate with incorrectly
inserted batteries.
outlet as shown in the adjacent image. Fully charging a depleted 18650 battery
takes approximately 6 hours.
2. Under normal charging conditions, the red indicator light near the charging port will
blink twice every second.
3. If a problem is detected during the charging process, the MH25 will stop charging
and the red indicator will blink rapidly. This is usually caused by faulty or
incorrectly inserted batteries.
4. When charging is complete, the red indicator will illuminate steadily.
Accessories
Nitecore 18650 Li-ion battery(NL183),
tactical ring, lanyard, USB cable, clip,
holster, spare switch cap and spare
O-ring
TYPE
Nominal voltage
Compatible
Primary Lithium battery * CR123 3V Yes (Compatible but can
NOT be recharged)
Yes (Compatible but can
NOT be recharged)
18650 Rechargeable Li-ion battery 18650 3.7V Yes (Compatible and
can be recharged)
Rechargeable Li-ion battery * RCR123 3.7V
*Warning: Charge 18650 rechargeable Li-ion batteries only, do not attempt to
charge non-rechargeable batteries, CR123 or RCR123 batteries.
Brightness & Runtime
18650 2×CR123
TURBO HIGH MID LOW
LUMENS
350
LUMENS
960
LUMENS
143
LUMENS
44
28
h
1
h min30
1
h min45
7
h min30
8
h min30
3
h min15
22
h
3
h
310m (Beam Distance)
24000cd (Peak Beam Intensity)
IPX-8, 2m
(Waterproof AND Submersible)
1.5m (Impact Resistant)
NOTICE
Stated data has been
measured according to
the international flashlight
testing standards
ANSI/NEMA FL1 using a
quality NITECORE 18650
(3.7V 2600mAh) battery or
two SYSMAX CR123 (3V
1550mAh) batteries under
laboratory conditions. The
data may vary due to
individual usage habits
and environmental
conditions.
Caution:
The MH25 needs to be turned on in
order to enter charging mode.
Switching ON/OFF
To switch ON: Press the button on the tailcap until a “click” is heard.
To switch OFF: Press the button on the tailcap a second time until a “click” is heard.
Mode Switching
The Nitecore MH25 has two modes: Turbo and user-defined. These two modes can
be changed by simply tightening and loosening the flashlight head. Turbo provides
100% output while user-defined contains five selectable sub-modes.
Turbo Mode
Turbo mode provides an output of 860 lumens and is accessed when the flashlight is
switched ON with the head lightly tightened. While in this mode, momentary
illumination can be achieved by switching off the flashlight and then half pressing and
holding the switch.
Note: After three minutes of use in turbo mode, the flashlight will lower its
output automatically to preventing overheating and increase runtime.
User-Defined Mode
User-defined mode is accessed by slightly loosening the flashlight head. In this mode,
lightly and rapidly pressing the switch will cycle through brightness and other
functions in the following order: “High-Mid-Low-SOS-Strobe”. Pressing the switch all
the way down will save and memorize a desired setting.
Tips: Make NITECORE MH25 your perfect Multitask Hybrid flashlight.
NITECORE MH25 flashlights essentially have two modes: Turbo mode (100% output)
and custom mode. Turbo mode is accessed by tightening the flashlight head while
any of the five customizable modes (strobe, SOS, low, medium and high) are selected
by loosening the head and rapidly pressing the on/off switch to cycle through the
modes. A given mode can be saved by simply turn off the light while in that mode.
Real-world examples include: When used as a flashlight around the home, the head
can be loosened and low level selected in custom mode, providing long runtimes at a
lower light intensity. The same flashlight could then be taken out and used a
law-enforcement duty light, with user-defined mode set in strobe, making it easy to
alternate between turbo mode and strobe with a simple twist of the flashlight head.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin coating
of silicon-based lubricant.
Warranty Service
All NITECORE® products are warranted for quality. Any defective / malfunctioning
NITECORE® product can be repaired free of charge for a period of 60 months (5
years) from the date of purchase. Beyond 60 months (5 years), a limited warranty
applies, covering the cost of labor and maintenance, but not the cost of accessories
or replacement parts.
The warranty is nullified in all of the following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by unauthorized
parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE® products and services, please contact a
local NITECORE® distributor or send an email to service@nitecore.com
※All images, text and statements specified herein this user manual are for reference
purpose only. Should any discrepancy occurs between this manual and information
specified on www.nitecore.com, information on our official website shall prevail.
Sysmax Industry Co., Ltd. reserves the rights to interpret and amend the content of
this document at any time without prior notice.
Charging Function
The MH25 is capable of charging a protected 18650 Li-ion battery via the included
USB cable. Simply install a protected 18650 Li-ion cell, plugging one end of the USB
cable into the flashlight and the other end into a universal USB port / adaptor and the
MH25 will take care of the rest.
Charging indicator light
1. Connect the charging cable to the flashlight and the A/C power adapter to the wall
20150916
Please find us on facebook:
NITECORE Flashlights
SYSMAX Industry Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address： Rm1401-03, Glorious Tower, 850 East Dongfeng Road,
Guangzhou, China 510600
