User Manual
Features
• Utilizes a CREE XP-G2 R5 LED
• Maximum output of 360 lumens
• Integrated “Precision Digital Optics Technology” provides extreme reflector
performance
Boasts a peak beam intensity of 6,500 cd and a throw distance up to 160 meters
• Tail switch designed for tactical applications
• Side switches for selecting brightness levels or modes
• Features intelligent memory effect
• Red LED provides constant/flashing illumination
• Displays battery voltage with red light (accurate to 0.1V)
• High efficiency constant current circuit enables maximum runtime of 180 hours
• Direct access to turbo/red light mode
• Reverse polarity protection prevents damage from incorrectly inserted batteries
• Stainless steel titanium-plated two-way clip
• Toughened ultra-clear mineral glass with anti-reflective coating
• Robust HAIII military grade hard-anodized
• Waterproof in accordance with IPX-8 (two-meter submersible)
• Tail stand capability
Dimensions
Length: 6.18” (156.9mm)
Head Diameter: 1” (25.4mm)
Tail Diameter: 0.85”(21.5mm)
Weight: 2.65oz (75g)(without battery)
Thanks for purchasing NITECORE!
Battery Options
The All-Round Flashlight Expert
NOTICE:
The stated data has been measured in accordance with the international flashlight testing
standards ANSI/NEMA FL1, using two high quality AA rechargeable batteries (1.2V,
2500mAH) under laboratory conditions. The data may vary in real-world use due to different
battery usage or environmental conditions.
Brightness Levels
When the MT20A is switched on, press the step-up switch repeatedly to switch among
the following brightness levels: red beacon-red light-ultralow-low-medium-high-turbo. The
MT20A has memory effect. When it is switched on, the MT20A will enter the brightness
level last used.
When the MT20A is switched on, press the step-down switch repeatedly to level down
its brightness until it reaches red beacon mode, after which there is no cycling back to
other brightness levels.
Direct Access to Red Light Mode:
When the MT20A is switched on, press and hold the step-down switch for over one
second to access red light mode; OR:
When the MT20A is switched off, press and hold the step-down switch while the tailcap
button is being held simultaneously to access the red light mode.
Direct Access to Turbo:
When the MT20A is switched on, press and hold the step-up switch for over one
second to access turbo output (360 lumens); OR:
When the MT20A is switched off, press and hold the step-up switch and press the
button on the tailcap to access turbo output (360 lumens).
Note: After three minutes' using of turbo mode, the flashlight will lower its output
automatically for preventing overheating, and efficiently ensure the battery runtime.
Special Modes (Strobe/Location Beacon/SOS)
With the light switched on, press both side switches to enter strobe mode. When in
strobe mode, press both side switches again to cycle through Location Beacon,
SOS, and Strobe modes. To exit and resume the brightness level last used, simply press
the step-up or step-down switch . The MT20A has memory effect in strobe mode. If
it is turned off in strobe mode, it will enter strobe mode immediately when switched on
again.
Power Tips
With the light switched off, press both side switches and the button on the tailcap to
activate the red power indicator to blink and indicate battery voltage (accurate to ±0.1V).
For example, when battery voltage is at 2.4V, the red power indicator will blink 2 times,
followed by a one second pause and another 4 blinks. Different voltages represent the
corresponding remaining battery power levels.
Changing / Charging Battery
Batteries should be replaced or recharged when output appears to be dim or the flashlight
becomes unresponsive.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin coating
of silicon-based lubricant.
Warranty Service
All NITECORE® products are warranted for quality. Any defective / malfunctioning
NITECORE® product can be repaired free of charge for a period of 60 months (5
years) from the date of purchase. Beyond 60 months (5 years), a limited warranty
applies, covering the cost of labor and maintenance, but not the cost of accessories
or replacement parts.
The warranty is nullified in all of the following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by unauthorized
parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE® products and services, please contact a
local NITECORE® distributor or send an email to service@nitecore.com
※All images, text and statements specified herein this user manual are for reference
purpose only. Should any discrepancy occurs between this manual and information
specified on www.nitecore.com, information on our official website shall prevail.
Sysmax Industry Co., Ltd. reserves the rights to interpret and amend the content of
this document at any time without prior notice.
Accessories
Quality holster clip, lanyard, spare tail ,
cap cover, spare O-ring
Brightness & Runtime
Operating Instructions
Battery Installation
Insert two AA batteries as illustrated.
WARNING:
Ensure batteries are inserted with the positive
(+) end pointing towards the head. The MT20A
will not be operational with incorrectly inserted
batteries.
Momentary Illumination
Momentary illumination can be achieved by switching the flashlight off and then half
pressing and holding the tail switch. Release switch to turn the light off.
Switching ON/OFF
Switch ON: Press the button on the tailcap all the way down until a “click” is heard.
Switch OFF: Press the button on the tailcap all the way down until a “click” is heard.
Standby Mode:
When power is off, press both side switches and the button on the tailcap
simultaneously to activate the red power indicator to flash and indicate battery
voltage. Three seconds after electrical voltage is reported, the MT20A enters standby
mode where the indicator flashes once every three seconds. In standby mode, the
MT20A will operate for approximately 60 days with the indicator on.
MT20A
Type
Nominal voltage
Compatible
Primary AA battery AA 1.5V Y (Recommended)
Rechargeable AA battery AA 1.2V Y (Recommended)
Primary AA Lithium battery L91 1.5V Y (Recommended)
Primary LiFePO4 battery 14500 3.2V N (Banned)
Rechargeable Li-ion battery 14500 3.7V N (Banned)
TURBO HIGH MID LOW
LUMENS
240
LUMENS
360
LUMENS
120
LUMENS
17
2
h min15
5
h min45
1
h min45
24
h
LOWER
LUMEN
1
180
h
160m
(Beam Distance)
6500cd
(Peak Beam Intensity)
IPX-8, 2m
(Waterproof and Submersible)
1.5m
(Impact Resistant)
2.7V2.1V 2.4V 2.5V
Low Power Full Power
SYSMAX Industry Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address: Rm1401-03, Glorious Tower, 850 East Dongfeng Road,
Guangzhou, China 510600
Please find us on facebook: NITECORE Flashlights
20150818
