Nitecore P12GT Manual
Læs nedenfor 📖 manual på dansk for Nitecore P12GT (1 sider) i kategorien Zaklamp. Denne guide var nyttig for 9 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/1
HIGH MID LOW
LUMENS
280
LUMENS
1000
LUMENS
55
LUMEN
1
1
h
28
h
5h15min
LOWER
520
h
3
h min30
300
h
20
h
45
min
320m
(Beam Distance)
25,700cd
(Peak Beam Intensity)
IPX-8, 2m
(Waterproof AND Submersible)
1.5m
(Impact Resistant)
1×18650 2×CR123
®
User Manual
Features
• Premium CREE XP-L HI V3 LED
• Maximum output up to 1000 lumens
• ‘Crystal Coating Technology’ combined with ‘Precision Digital Optics
Technology’ provide extreme reflector performance
• Boasts a peak beam intensity of 25,700cd and a throw distance up to 320
meters
• High efficiency circuit board provides up to 520 hours runtime on low level
• Side switch interface provides one-handed operation and easy access to all
functions
• Side switch features an indicator light which displays remaining battery
power (Chinese Patent: ZL201220057767.4)
• Features advanced temperature regulation (ATR) technology
• Power indicator’s secondary function displays battery voltage (accurate to
0.1V)
• Intelligent memory function stores preferred brightness setting
• High-efficiency regulation circuit provides unwavering output
• Toughened ultra-clear mineral glass with anti-reflective coating
• Constructed from aero grade aluminium alloy with HAIII military grade
hard-anodized finish
• Waterproof in accordance with IPX-8 (two meters submersible)
• Impact resistant to 1.5 meters
• Stainless steel titanium-plated two-way clip included
• Tail stand capability
Dimensions
Length: 5.51” (140mm)
Head Diameter: 1”(25.4mm )
Tail Diameter: 1” (25.4mm)
Weight: 3.21oz (91g)(without battery)
Thanks for purchasing NITECORE!
Brightness & Runtime
The All-Round Flashlight Expert
Accessories
Quality holster, clip, tactical
ring, lanyard, spare tail cap
cover, spare O-ring
Battery Options
Operating Instructions
Battery Installation
Insert one 18650 battery or two CR123
batteries with the positive ends pointing
toward the light head.
WARNING
Ensure when turning the P12GT on, the
beam is directed away from the eyes of
people or animals.
Momentary Illumination
Momentary illumination mode is accessed
by pressing the tail switch partway down
and holding with the flashlight in standby.
Release the switch to turn the light off .
Switching ON/OFF
To switch ON: Press the tailcap switch until a “click” is heard.
To switch OFF: Press the tailcap switch a second time until a “click” is heard.
General Operations
With the light turned on, press the side switch to cycle through the following
brightness levels: ultra-low, low, medium and high. Once a desired setting is
displayed, it can be saved by turning the light off at the tail switch.
Special Modes
With the light turned on, press and hold the side switch to activate Strobe
mode. Press and hold once again to access Location Beacon mode and
repeat once more for SOS mode. To exit any one of these modes simply
press the side switch to return to your previously used brightness level.
Note: Strobe mode is the default special mode and is the only special mode
that has a memory function. If the light is turned off in strobe mode, strobe will
resume when the light is turned on. SOS and Location Beacon modes have
no memory function.
ATR Technology
Advanced temperature regulation (ATR) technology allows P12GT to
dynamically adjust output performance based on its internal temperature. This
prevents damage from overheating and prolongs its working life.
Power Tips
1. With the light switched on, the power indicator will blink once every two
seconds when power levels are below 50%.
2. With the light switched on, the power indicator will blink rapidly when power
levels are close to depletion.
3. With the light turned off, press and hold the side switch while
simultaneously pressing the tail switch to display the battery voltage
(accurate to ±0.1V) with serial of blinks. For example, when the battery
voltage is at 4.2V, the power indicator will blink 4 times in quick succession,
followed by a one second pause and two more blinks.
Changing Batteries
When the power indicator blinks rapidly, the batteries need to be replaced.
Alternatively if the light becomes dim or unresponsive to adjustment, this also
indicates batteries need to be replaced.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin
coating of silicon-based lubricant.
Warranty Service
All NITECORE® products are warranted for quality. Any defective /
malfunctioning NITECORE® product can be repaired free of charge for a
period of 60 months (5 years) from the date of purchase. Beyond 60 months
(5 years), a limited warranty applies, covering the cost of labor and
maintenance, but not the cost of accessories or replacement parts.
The warranty is nullified in all of the following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by
unauthorized parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE® products and services, please
contact a local NITECORE® distributor or send an email to
service@nitecore.com
※All images, text and statements specified herein this user manual are for
reference purpose only. Should any discrepancy occurs between this manual
and information specified on www.nitecore.com, information on our official
website shall prevail. Sysmax Industry Co., Ltd. reserves the rights to
interpret and amend the content of this document at any time without prior
notice.
NOTICE
The above data has
been measured in
accordance with the
international flashlight
testing standards
ANSI/NEMA FL1 using
one x 3.7V 3400mAh
Nitecore 18650 battery
and 2 x 3V 1700mAh
Nitecore CR123
batteries under
laboratory conditions.
The data may vary
slightly during
real-world use due to
battery type, individual
usage habits and
environmental factors.
TYPE
Nominal voltage
Compatible
Primary Lithium battery CR123 3V Y (Recommended)
18650 Rechargeable Li-ion battery 18650 3.7V Y (Recommended)
Rechargeable Li-ion battery RCR123 3.7V Y
P12GT
SYSMAX Industry Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address： Rm1401-03, Glorious Tower, 850 East Dongfeng Road,
Guangzhou, China 510600
20151120
Please find us on facebook:
NITECORE Flashlights
