Side 1/1
Level
Lumens
1
2
2
20
3
80
4
210
5
380
6
600
7
850
8
1100
9
1500
10
2000
®
User Manual
Features
Utilizes a CREE MT-G2 LED
Max output of up to 2000 lumens
Runtime of up to 325 hours
• A multifunctional rotary switch offers unprecedented ease of use
10 brightness levels and 5 special modes for multiple applications
• Advanced temperature regulation (ATR) technology ensures stability and longevity
High efficiency constant current circuitry provides unwavering and dependable
output
Features intelligent memory function in regular output modes
Features 2 x battery power indicators on the tail
Direct access to turbo/ultra-low
Utilizes a micro-textured metal reflector for peripheral illumination
Stainless steel bezel ring protects core components from damage
Toughened ultra-clear mineral glass with anti-reflective coating
Constructed from aerospace grade aluminum alloy
HAIII military grade hard-anodized
Waterproof in accordance with IPX-8
Impact resistant to 1.5 meters
Tail stand capability
Dimensions
Length: 6.81” (173mm)
Head diameter: 1.97” (50mm)
Tail: 1.10” x 1.65” (28mm x 42mm)
Weight: 8.89oz (252g)(without battery)
Thanks for purchasing NITECORE!
Brightness & Runtime
The All-Round Flashlight Expert
Accessories
Battery carrier, quality holster, lanyard,
rubber switch casing, spare O ring
Battery Options
Operating Instructions
Battery Installation
Insert 2 x 18650 batteries or 4 x CR123
batteries as illustrated:
NOTE:
After loading the batteries, the power
indicators will blink to indicate the battery
power levels. Please refer to the “Power
Tips” section of this manual for details.
WARNING
1. This product CANNOT be powered by
flat-top batteries.
2. AVOID direct eye exposure.
To switch the light off: Press the ON/OFF button again until a click is heard
Brightness Levels
NOTE: The P36s multiple functions can be accessed by operating the rotary switch.
NOTE
The above data has been
measured in accordance
with the international
flashlight testing standards
ANSI/NEMA FL1 using 2 x
Nitecore 186503.7V
2600mAh) batteries or 4 x
Nitecore CR123 (3V
1550mAh) batteries under
laboratory conditions. The
data may vary during
real-world use due to battery
type, individual usage habits
and environmental factors.
TYPE
Nominal voltage
Compatible
Primary Lithium battery CR123 3V Y (Recommended)
18650 Rechargeable Li-ion battery 18650 3.7V Y (Recommended)
Rechargeable Li-ion battery RCR123 3.7V Y
P36
SYSMAX Industry Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address Rm1401-03, Glorious Tower, 850 East Dongfeng Road,
Guangzhou, China 510600
TURBO HIGH* MID*
LUMENS
2000
LUMENS
1500
LUMENS
380
185
h
45
min
7
h
30
min
45
min
5
h
30
min
LOWER
LUMENS
2
325
h
1
h
300m
(Beam Distance)
22300cd
(Peak Beam Intensity)
IPX-8, 2m
(Waterproof AND Submersible)
1.5m
(Impact Resistant)
4×CR123
2×18650
* The ten brightness levels provide output from 2 lumens to 2000 lumens, with
corresponding runtime ranging from 45 minutes to 325 hours.
The ANSI lumen rating for each of the ten brightness levels is as follows:
With the light switched on, rotate the rotary switch to
access ten brightness levels.
Rotate the rotary switch counterclockwise to increase
output lumens until the turbo mode is selected.
Alternatively, rotate the rotary switch clockwise to lower
output lumens until the ultra-low mode is selected
Direct Access to Ultra-low/Turbo
With the light switched off, slide the rotary switch
counterclockwise quickly and press the ON/OFF button
within three seconds to enter turbo mode (2000 lumens);
Alternatively, with the light switched off, slide the rotary switch clockwise quickly and
press the ON/OFF button within three seconds to enter ultra-low mode (2 lumens).
NOTE: The P36 has an intelligent memory function, ensuring the last used output will
be saved and resumed when the P36 is reactivated.
Special Modes (Strobe/Slow Flashing/Quick
Flashing/Location Beacon/SOS)
With the light switched on, press the rotary switch to enter Strobe mode. To cycle
through the special modes (slow flash, quick flash, location beacon, SOS and strobe)
simply rotate the rotary switch counterclockwise. To resume the previously used
special mode, simply rotate the rotary switch in reverse. To exit special modes, simply
press the rotary switch again to resume the last used brightness level.
NOTE: The P36 does not have an intelligent memory function for any of its special
modes.
Strobe Ready
Press and hold the rotary switch for over one second in any state to enter strobe
mode immediately. Simply release to exit the strobe mode.
Power Tips
1. With the light on, the red power indicators will flash once every two seconds when
battery power levels fall to 50%. The red power indicators will flash quickly when
battery power is close to depletion
2. With the light off, tightening the bezel or pressing the rotary switch after battery
installation will activate the two red power indicators on the tail. The power indicators
will blink three times when power levels are above 50%; twice when power levels are
below 50%; and once when battery power is close to depletion.
ATR Technology
Advanced temperature regulation (ATR) technology allows the P36 to
dynamically adjust output performance according to its body temperature.
This prevents damage from overheating and prolongs its working life.
Changing/Charging Batteries
Batteries should be replaced or recharged when output appears to be dim or
the flashlight becomes unresponsive.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin
coating of silicon-based lubricant.
Warranty Service
All NITECORE® products are warranted for quality. Any defective /
malfunctioning NITECOR product can be repaired free of charge for a
period of 60 months (5 years) from the date of purchase. Beyond 60 months
(5 years), a limited warranty applies, covering the cost of labor and
maintenance, but not the cost of accessories or replacement parts.
The warranty is nullified in all of the following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by
unauthorized parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE® products and services, please
contact a local NITECOR distributor or send an email to
service@nitecore.com
All images, text and statements specified herein this user manual are for
reference purpose only. Should any discrepancy occurs between this manual
and information specified on www.nitecore.com, information on our official
website shall prevail. Sysmax Industry Co., Ltd. reserves the rights to
interpret and amend the content of this document at any time without prior
notice.
Momentary Illumination
Press and hold the ON/OFF button halfway to turn the light on, simply release
to turn the light off.
ON/OFF
To switch the light on: Press the ON/OFF button until a click is heard
20150923
Please find us on facebook:
NITECORE Flashlights
