Side 1/3
• The bonnets are machine washable in cold water. However hand washing will
extend the life of the bonnet.
• Always store the polisher with the foam pad facing up to extend the life and
shape.
• When not in use, remove bonnet from the foam pad. This will ensure that the
foam pad will dry out and retain its shape.
• Keep the vents of the polisher clean at all times. If possible, prevent foreign
matter from entering the vents.
• After each use, blow air through the polisher housing to ensure it is free from
all dust particles which may build up. Build up of dust particles may cause the
polisher to overheat and fail.
• If the enclosure of the polisher requires cleaning, do not use solvents but
a moist soft cloth only. Never let any liquid get inside the polisher; never
immerse any part of the polisher into a liquid.
Carbon Brushes
When the carbon brushes wear out, the polisher
will spark and/or stop. Discontinue use as soon
as this happens. They should be replaced prior to
recommencing use of the polisher. Carbon brushes
are a wearing component of the polisher and are
therefore not covered under warranty. Continuing
to use the polisher when carbon brushes need to
be replaced may cause permanent damage to the
polisher. Carbon brushes will wear out after many uses. When the carbon
brushes need to be replaced, take the polisher to an electrician or a power
tool repairer for a quick and low cost replacement. Always replace both carbon
brushes at the same time.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by the repair of the polisher by an unauthorised person or by
mishandling of the polisher.
BUFFER
POLISHER
110W
ORIGINAL INSTRUCTIONS
SPECIFICATIONS
Voltage: 230V ~ 50Hz
Power: 110W
No Load Spead: 3,200/min
Buffing Pad Diameter: 240mm (10”)
Orbital Diameter: 12.7mm (1/2”)
Weight: 3.65kg
WHAT’S IN THE BOX
Buffer Polisher
Applicator Bonnet
& Polishing Bonnet
MAINTENANCE
DESCRIPTION OF SYMBOLS
TROUBLE SHOOTING
Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing vents.
This is normal and does not indicate a problem.
Excessive sparking visible through the housing air vents
and/or the drill failing to operate
May indicate the carbon brushes have worn out and need to be replaced. Carbon
brushes should only be replaced by a qualied electrician or power tool repairer.
Operation Tips
Never force the buffer polisher. The weight of the unit supplies adequate pressure,
allowing the discs to do the work. Applying additional pressure will slow the motor,
rapidly wear the discs, and greatly reduce the rotational speed. This will slow the
removal rate and produce an inferior quality surface.
CAUTION: Excessive pressure will overload the motor, causing possible damage
to the buffer polisher by overheating the motor; or damage to the workpiece.
Do not polish on one spot for too long. The polisher’s rapid action may remove
too much material, creating an uneven surface.
SPARE PARTS
ozito-diy.co.uk
BUFFER POLISHER SAFETY WARNINGS
OZBP110WAU
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
Before you connect the equipment to the mains supply make sure that the data on the rating plate are
identical to the mains data.
This tool is double insulated therefore no earth wire is required.
If the supply cord of this power tool is damaged, it must be replaced by a specially prepared cord available
through the service organization.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
To reduce the risk of electrical shock, a residual current device (rated 30mA or less) should be used.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power
tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Hold power tool by insulated gripping surfaces, because the pad may
contact its own cord. Cutting a “live” wire may make exposed metal parts of the power
tool “live” and could give the operator an electric shock.
This power tool is intended to function as a polisher. Read all safety warnings, instructions,
illustrations and specications provided with this power tool. Failure to follow all instructions
listed below may result in electric shock, re and/or serious injury.
Operations such as grinding, sanding, wire brushing, or cutting-off are not recommended to
be performed with this power tool. Operations for which the power tool was not designed may
create a hazard and cause personal injury.
Do not use accessories which are not specically designed and recommended by the tool
manufacturer. Just because the accessory can be attached to your power tool, it dose not assure
safe operation.
The rated speed of the accessory must be at least equal to the maximum speed marked on
the power tool. Accessories running faster than their rated speed can break and y apart.
Do not allow any loose portion of the polishing bonnet or its attachment strings to spin
freely. Tuck away or trim any loose attachment strings. Loose and spinning attachment strings
can entangle your ngers or snag on the workpiece.
Wear personal protective equipment. Depending on application, use face shield, safety
goggles or safety glasses. As appropriate, wear dust mask, hearing protectors, gloves
and workshop apron capable of stopping small abrasive or workpiece fragments. The eye
protection must be capable of stopping ying debris generated by various operations. The dust
mask or respirator must be capable of ltrating particles generated by your operation. Prolonged
exposure to high intensity noise may cause hearing loss.
Keep bystanders a safe distance away from work area. Anyone entering the work area must
wear personal protective equipment. Fragments of workpiece or of a broken accessory may y
away and cause injury beyond immediate area of operation.
Position the cord clear of the spinning accessory. If you lose control, the cord may be cut or
snagged and your hand or arm may be pulled into the spinning accessory.
Never lay the power tool down until the accessory has come to a complete stop. The spinning
accessory may grab the surface and pull the power tool out of your control.
Do not run the power tool while carrying it at your side. Accidental contact with the spinning
accessory could snag your clothing, pulling the accessory into your body.
Regularly clean the power tool’s air vents. The motor’s fan will draw the dust inside the housing
and excessive accumulation of powdered metal may cause electrical hazards.
Do not operate the power tool near ammable materials. Sparks could ignite these materials.
Do not use accessories that require liquid coolants. Using water or other liquid coolants may
result in electrocution or shock.
WARNING! Some dust created by power sanding, sawing, grinding, drilling and other
construction activities contain chemicals known to cause cancer, birth defects or other
reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks, cement and other masonry products, and;
• Arsenic and chromium from chemically-treated timber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well ventilated area and work with approved safety
equipment, such as dust masks that are specially designed to lter out microscopic particles.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any
other accessory. Pinching or snagging causes rapid stalling of the rotating accessory which in turn
causes the uncontrolled power tool to be forced in the direction opposite of the accessory’s rotation
at the point of the binding. Kickback is the result of power tool misuse and/or incorrect operating
procedures or conditions and can be avoided by taking proper precautions as given below.
• Maintain a rm grip on the power tool and position your body and arm to allow you to resist
kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or
torque reaction during start-up. The operator can control torque reactions or kickback forces, if
proper precautions are taken.
• Never place your hand near the rotating accessory. Accessory may kickback over your hand.
• Do not position your body in the area where power tool will move if kickback occurs. Kickback
will propel the tool in direction opposite to the wheel’s movement at the point of snagging.
• Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing have a tendency to snag the rotating accessory
and cause loss of control or kickback.
1 Insert a long-bladed
screwdriver between the
foam pad and the motor
housing to stop the spindle
moving.
3 To reinstall the foam pad,
screw anti-clockwise.
2 Using a at-bladed
screwdriver,
remove the screw
folding the foam
pad by turning it
clockwise.
Removing the Foam Pad
WARRANTY
OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG 0616
All of our products undergo strict quality checks to ensure that they reach
you in perfect condition. In the unlikely event that your device develops a
fault, please contact our service department at the address shown on this
guarantee card. You can also contact us by telephone using the customer
service number shown. Please note the following terms under which
guarantee claims can be made:
1. These warranty terms regulate additional warranty services, which the
manufacturer mentioned below promises to buyers of its new products
in addition to their statutory guarantee claims are not affected by this
guarantee. Our guarantee is free of charge to you.
2. The warranty services only covers defects due to material or
manufacturing faults on a product which you have bought from the
manufacturer mentioned below are limited to either the rectication of said
defects on the product or the replacement of the product, whichever we
prefer.
Please note that our devices are not designed for use in commercial, trade
or professional applications. A guarantee contract will not be created if the
device has been used by commercial, trade or industrial business or has
been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly
instructions or due to incorrect installation, a failure to follow the operating
instructions (for example connecting it to an incorrect mains voltage or
current type) or a failure to follow the maintenance and safety instructions
or by exposing the device to abnormal environmental conditions or by lack
of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example
overloading the device or the use or unapproved tools or accessories),
ingress of foreign bodies into the device (such as sand, stones or dust,
transport damage), the use of force or damage caused by external forces
(for example by dropping it).
- Damage to the device or parts of the device caused by normal or natural
wear or tear or by normal use of the device.
4. Your Product is guaranteed for a period of 36 months from the original
date of purchase and is intended for DIY (Do It Yourself) use only. Lithium
Ion batteries and chargers are covered by a 12 month warranty. Warranty
excludes consumable parts. Guarantee claims should be submitted
before the end of the guarantee period within two weeks of the defect
being noticed. No guarantee claims will be accepted after the end of the
guarantee period. The original guarantee period remains applicable to the
device even if repairs are carried out or parts are replaced. In such cases,
the work performed or parts tted will not result in an extension of the
guarantee period, and no new guarantee will become active for the work
performed or parts tted. This also applies if an on-site service is used.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO THE PLACE OF PURCHASE WITH YOUR
REGISTER RECEIPT.
Please refer to the restrictions of this warranty concerning wearing parts,
consumables and missing parts as set out in the service information in
these operating instructions.
CUSTOMER SERVICE HELPLINE
GB: 0151 294 4488
IRL: 1850 882711
Ozito-diy.co.uk
Volts HertzV Hz
Alternating current Watts ~ W
/min Revolutions or
reciprocation per minute
Double insulated Read instruction manual
no No load speed
Warning
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse or Homebase store.
For further information, or any parts visit
www.ozito-diy.co.uk or contact Ozito Customer Service:
Great Britain: 0151 294 4488
Ireland: 1850 882711
E-mail: enquires@ozito-diy.co.uk
Produkt Specifikationer
| Mærke: | Ozito |
| Kategori: | Polermaskine |
| Model: | OZBP110WAU |
Har du brug for hjælp?
Hvis du har brug for hjælp til Ozito OZBP110WAU stil et spørgsmål nedenfor, og andre brugere vil svare dig
Polermaskine Ozito Manualer
6 August 2024
24 Juni 2023
Polermaskine Manualer
- Polermaskine Bosch
- Polermaskine Metabo
- Polermaskine DeWalt
- Polermaskine RYOBI
- Polermaskine Silverline
- Polermaskine Skil
- Polermaskine Zipper
- Polermaskine Makita
- Polermaskine Worx
- Polermaskine Güde
- Polermaskine Biltema
- Polermaskine Bartscher
- Polermaskine Vonroc
- Polermaskine Milwaukee
- Polermaskine Parkside
- Polermaskine Black And Decker
- Polermaskine Einhell
- Polermaskine Hikoki
- Polermaskine Topcraft
- Polermaskine Ultimate Speed
- Polermaskine Kärcher
- Polermaskine Powerplus
- Polermaskine Westfalia
- Polermaskine GlobalTronics
- Polermaskine Porter-Cable
- Polermaskine Sun Joe
- Polermaskine Kalorik
- Polermaskine Panduit
- Polermaskine RIKON
- Polermaskine Holzmann
- Polermaskine APA
- Polermaskine Cocraft
- Polermaskine Tryton
- Polermaskine Full Boar
- Polermaskine Robust
- Polermaskine Einhell Bavaria
Nyeste Polermaskine Manualer
12 September 2024
8 September 2024
6 September 2024
3 September 2024
2 September 2024
2 September 2024
2 September 2024
1 September 2024
31 August 2024
31 August 2024
