Side 1/3

CORDLESS GRASS

TRIMMER & SHEAR

ORIGINAL INSTRUCTIONS

SPECIFICATIONS

Voltage: 18V

No Load Speed: 1,200/min

Hedge Trimmer: 200mm Blade

Grass Shear: 100mm Blade

Max. Cutting Cap.: 8mm

Weight: 1.0kg

PXCGSS-018U

WHAT’S IN THE BOX

Cordless Grass Trimmer /

Shear

Hedge Trimmer Blade

MAINTENANCE

DESCRIPTION OF SYMBOLS

TROUBLESHOOTING

WARRANTY

ozito-diy.co.uk

WARNING! When using mains-powered tools, basic safety precautions, including

the following, should always be followed to reduce risk of ﬁre, electric shock, personal

injury and material damage.

Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.

Save these instructions and other documents supplied with this tool for future reference.

Before you connect the charger to the mains supply make sure that the data on the rating plate are identical to the mains data.

This tools charger is double insulated therefore no earth wire is required.

If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.

Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for

added protection against injury resulting from a possible electrical insulation failure within the tool.

The power supply for this products charger should be protected by a residual current device (rated at 30mA or less). A residual current

device reduces the risk of electric shock.

GENERAL POWER TOOL SAFETY WARNINGS

ELECTRICAL SAFETY

0716

THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR

BATTERY CHARGER.

1. Before using the charger read all instructions and cautionary markings on the charger, battery pack and the product using the

battery pack.

2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use may result in risk of re,

electric shock or electrocution.

3. Do not place any object on top of the charger or place the charger on a soft surface that may result in excessive internal heat.

Place the charger in a position away from any heat source.

4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the charger.

5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.

6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord could result in the risk of re,

electric shock or electrocution.

7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Have it checked by an

electrician or power tool repairer.

8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is required. Incorrect reas-

sembly may result in a risk of electric shock, electrocution or re.

9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the battery pack

will not reduce this risk.

10. Never attempt to connect 2 chargers together.

11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as inside sheds or

metal buildings in summer).

12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt to use it on any other

voltage!

13. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging notes and

procedures.

14. The longest life and best performance can be obtained if the battery pack is charged when the air temperature is between 18 -

24ºC. Do not charge the battery pack in an air temperature below 10ºC or above 40ºC. This is important and will prevent damage

to the battery pack.

15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery can explode in a re.

16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, immediately

discontinue use and do not recharge.

17. During charging, the battery must be placed in a well ventilated area.

WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and

instructions may result in electric shock, re and/or serious injury.

Save all warnings and instructions for future reference. The term “power tool” in the

warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)

power tool.

1. Work area safety

a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b. Do not operate power tools in explosive atmospheres, such as in the presence of

ﬂammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose

control.

2. Electrical safety

a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use

any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will

reduce risk of electric shock.

b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges

and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk

of electric shock.

d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power

tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords

increase the risk of electric shock.

e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces the risk of electric shock.

f. If operating a power tool in a damp location is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3. Personal safety

a. Stay alert, watch what you are doing and use common sense when operating a power

tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol

or medication. A moment of inattention while operating power tools may result in serious personal injury.

b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust

mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting

to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with

your nger on the switch or energising power tools that have the switch on invites accidents.

d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may result in personal injury.

e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the

power tool in unexpected situations.

f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and

gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

g. If devices are provided for the connection of dust extraction and collection facilities,

ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

4. Power tool use and care

a. Do not force the power tool. Use the correct power tool for your application. The correct

power tool will do the job better and safer at the rate for which it was designed.

b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be

controlled with the switch is dangerous and must be repaired.

c. Disconnect the plug from the power source and/or the battery pack from the power

tool before making any adjustments, changing accessories, or storing power tools. Such

preventive safety measures reduce the risk of starting the power tool accidentally.

d. Store idle power tools out of the reach of children and do not allow persons unfamiliar

with the power tool or these instructions to operate the power tool. Power tools are dangerous in

the hands of untrained users.

e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of

parts and any other condition that may affect the power tool’s operation. If damaged,

have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to

bind and are easier to control.

g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,

taking into account the working conditions and the work to be performed. Use of the power

tool for operations different from those intended could result in a hazardous situation.

5. Battery tool use and care

a. Recharge only with the charger speciﬁed by the manufacturer. A charger that is suitable for one

type of battery pack may create a risk of re when used with another battery pack.

b. Use power tools only with speciﬁcally designated battery packs. Use of any other battery packs may

create a risk of injury and re.

c. When battery pack is not in use, keep it away from other metal objects, like paper clips,

coins, keys, nails, screws or other small metal objects, that can make a connection from

one terminal to another. Shorting the battery terminals together may cause burns or a re.

d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If

contact accidentally occurs, ﬂush with water. If liquid contacts eyes, additionally seek

medical help. Liquid ejected from the battery may cause irritation or burns.

6. Service

a. Have your power tool serviced by a qualiﬁed repair person using only identical

replacement parts. This will ensure that the safety of the power tool is maintained.

BATTERY AND CHARGER SAFETY WARNINGS

Cleaning and Storage

• Keep air intake clean and air vents free of debris to avoid overheating the motor.

• Do not use cleaning agents to clean the plastic parts of the tool.

A mild detergent on a damp cloth is recommended. Water must never come into contact with

the tool.

• If the trimmer vibrates abnormally, stop motor immediately. Abnormal vibration usually indicates

a mechanical problem continued operation could lead to injury or damage.

• Always place the blade cover on the blade before storing or transporting the hedge trimmer. Use

caution to avoid the sharp teeth of the blade.

• Store the hedge trimmer indoors, in a dry place that is inaccessible to children.

WARNING! ALWAYS ENSURE THE TOOL HAS

COMPLETELY STOPPED AND THE BATTERY IS

REMOVED PRIOR TO ANY MAINTENANCE.

Problem Cause Remedy

Trimmer is not

starting

Possible clogging Clean the trimmer blade of any

leaves or debris.

Battery is low in charge Charge battery

Battery not inserted properly Insert battery pack correctly

Trimmer is not

operating at full

capacity

Possible clogging Clean the trimmer blade of any

leaves or debris.

Motor stops while

trimming

Battery has no power Charge battery

Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the

trimmer by an unauthorised person or by mishandling of the trimmer. This tool is designed for DIY use

- use in commercial or industrial environments will void the warranty.

GRASS TRIMMER & SHEAR SAFETY WARNINGS

Read instruction manual

Keep bystanders away. Do not operate whilst people especially

children or pets are in the area.

Sharpening the cutting blade

1. Start and stop your trimmer

until the cutter blade and the

guard are slightly offset.

2. Remove the battery pack from

your trimmer/shear.

3. Clamp the blade assembly in a

vise and le the exposed cutting surface of each blade tooth. Remove as

little material as possible.

4. Remove the blade from

the vise and insert the battery pack. Repeat

steps 1-3 for the unsharpened edges of the

blade teeth.

Note: Do not operate your trimmer/shear with

dull or damaged cutting blades. This may cause

overload and will give unsatisfactory cutting

results.

Lubricating the blade

For best operation and longer blade life, lubricate the blade with light weight machine

oil before and after each use.

1. Remove the battery pack from the trimmer/

shear.

2. Lay the blade on a at surface. Apply a light

weight machine oil along the edge of the top

blade.

Grass Shear Blade

WARNING! DO NOT OIL WHILE THE TRIMMER/

SHEAR IS RUNNING.

Blade Covers

• Keep all parts of the body away from the cutter blade. Do not remove cut

material or hold material to be cut when blades are moving. Make sure the switch is off when

clearing jammed material. A moment of inattention while operating the trimmer may result in

serious personal injury.

• Carry the trimmer by the handle with the cutter blade stopped. When

transporting or storing the trimmer always t the blade cover. Proper handling of the trimmer will

reduce possible personal injury from the cutter blades.

• Hold the power tool by insulated gripping surfaces only, because the

cutter blade may contact hidden wiring. Cutter blades contacting a “live” wire may

make exposed metal parts of the power tool “live” and could give the operator an electric shock.

• Perform visual inspection on the hedge being trimmed. To ensure no wire

fences or foreign objects that the hedge trimmer may contact during operation.

• Never allow children or people unfamiliar with these instructions to use the trimmer.

• Avoid using the trimmer, while people, especially children or pets, are nearby.

• Use the trimmer only in daylight or good articial light.

• Never operate the trimmer with damaged blades in place.

• Switch on the trimmer only when the hands and feet are away from the cutting blades.

• Use only the manufacturer’s recommended replacement parts and accessories.

• Inspect and maintain the trimmer regularly. Have the trimmer repaired only by an authorized

repairer.

• When not in use, store the trimmer out of the reach of children.

• Face the cutting blades away from yourself, other people and animals while the power is connected

to the trimmer (especially during operation).

• Keep ventilation openings clear of debris. Keep handles dry, clean and free of oil and grease.

• Never reach underneath the trimmer (the cutting blade area) until it has completely stopped.

WARNING! When servicing, use only identical replacement parts. Use of any other parts

may create a hazard or cause product damage. To ensure safety and reliability, all repairs

should be performed by a qualied service technician.

WARNING! This appliance is not intended for use by young or inrm persons unless

supervised by a responsible person to ensure that they can use the appliance safely. Young

children should be supervised to ensure that they do not play with the appliance.

Battery & Charger sold

separately

OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG

All of our products undergo strict quality checks to ensure that they reach you in perfect

condition. In the unlikely event that your device develops a fault, please contact our service

department at the address shown on this guarantee card. You can also contact us by

telephone using the customer service number shown. Please note the following terms under

which guarantee claims can be made:

1. These warranty terms regulate additional warranty services, which the manufacturer

mentioned below promises to buyers of its new products in addition to their statutory

guarantee claims are not affected by this guarantee. Our guarantee is free of charge to you.

2. The warranty services only covers defects due to material or manufacturing faults on

a product which you have bought from the manufacturer mentioned below are limited to

either the rectication of said defects on the product or the replacement of the product,

whichever we prefer.

Please note that our devices are not designed for use in commercial, trade or professional

applications. A guarantee contract will not be created if the device has been used by

commercial, trade or industrial business or has been exposed to similar stresses during the

guarantee period.

3. The following are not covered by our guarantee:

- Damage to the device caused by a failure to follow the assembly instructions or due to

incorrect installation, a failure to follow the operating instructions (for example connecting

it to an incorrect mains voltage or current type) or a failure to follow the maintenance and

safety instructions or by exposing the device to abnormal environmental conditions or by

lack of care and maintenance.

- Damage to the device caused by abuse or incorrect use (for example overloading the

device or the use or unapproved tools or accessories), ingress of foreign bodies into the

device (such as sand, stones or dust, transport damage), the use of force or damage caused

by external forces (for example by dropping it).

- Damage to the device or parts of the device caused by normal or natural wear or tear or by

normal use of the device.

4. Your Product is guaranteed for a period of 60 months from the original date of purchase

and is intended for DIY (Do It Yourself) use only. Lithium Ion batteries and chargers are

covered by a 12 month warranty. Warranty excludes consumable parts. Guarantee claims

should be submitted before the end of the guarantee period within two weeks of the defect

being noticed. No guarantee claims will be accepted after the end of the guarantee period.

The original guarantee period remains applicable to the device even if repairs are carried

out or parts are replaced. In such cases, the work performed or parts tted will not result

in an extension of the guarantee period, and no new guarantee will become active for the

work performed or parts tted. This also applies if an on-site service is used.

IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO

THE PLACE OF PURCHASE WITH YOUR REGISTER RECEIPT.

Please refer to the restrictions of this warranty concerning wearing parts, consumables and

missing parts as set out in the service information in these operating instructions.

CUSTOMER SERVICE HELPLINE

GB: 0151 294 4488

IRL: 1850 882711

Ozito-diy.co.uk

SPARE PARTS

Spare parts can be ordered from the Special Orders Desk at your local

Bunnings Warehouse or Homebase store.

For further information, or any parts visit

www.ozito-diy.co.uk or contact Ozito Customer Service:

Great Britain: 0151 294 4488

Ireland: 1850 882711

E-mail: enquires@ozito-diy.co.uk

Produkt Specifikationer

Mærke:	Ozito
Kategori:	Grastrimmer
Model:	PXCGSS-018U

Har du brug for hjælp?

Hvis du har brug for hjælp til Ozito PXCGSS-018U stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Grastrimmer Ozito Manualer

Ozito PXCLTK-218U Manual

31 August 2024

Ozito PXCLTS-018U Manual

31 August 2024

Ozito PXCGSS-018U Manual

28 August 2024

Ozito PXCLTS-182U Manual

6 August 2024

Ozito LTR-630U Manual

6 August 2024

Ozito LTR-529U Manual

6 August 2024

Ozito OGT-018 Manual

1 August 2024

Grastrimmer Manualer

Nyeste Grastrimmer Manualer

Husqvarna 110iL Manual

9 Oktober 2024

Stihl FS 490 C-M Manual

30 September 2024

Stiga SGT 226 J Manual

29 September 2024

RYOBI One+ P20220 Manual

24 September 2024

Husqvarna 325RDX Manual

22 September 2024

Flymo 18V EasiTrim 250 Manual

19 September 2024

Stihl FixCut 5-2 Manual

19 September 2024

Stihl AutoCut 5-2 Manual

18 September 2024

Worx WG930.2 Manual

15 September 2024

Husqvarna 327RJX Manual

15 September 2024
