Side 1/1
1 2
4. Speaker orientaon- Direct the speaker towards the center of the
coverage area. Adjust the vercal orientaon using the two locking nuts
on the U-bracket on either side of the speaker.
5. Internal volume control to allow on-site tuning: while tesng the
sound output, please adjust the volume on the back of the speaker to
reach comprehensive sound distribuon and to avoid excessive
loudness.
Horn Speaker
USER MANUAL
PR-HS30W
3 4
- +
General Informaon
This IP66 outdoor horn speaker has been tested and approved for proper
outdoor use as described in following instrucons.
All outdoor cabling should be done by a professional installer.
Correct speaker locaon and orientaon are crucial to ensure
comprehensive sound distribuon in operang areas.
Please note:
* Before installaon, please make sure the speaker will be located next to a
suitable audio device or PROVISION-ISR Camera which has an available
Audio-out plug. Provision-ISR audio out plug is mostly marked by the
leers “HP” (female 3.5mm, stereo).
* All outdoor cable connecons must be well insulated from dust and
weather using a wiring box or another mean of outdoor cable protecon.
Mounng instrucons
1. Mounng: Use the stainless steel screws to
mount the speaker to a suitable support structure
such as a wall, locate close enough to
Provision-ISR camera or another audio source.
2. Connect power cable to power source (DC24V-12V, 2A). Power
cable can be added an extension of up to 100m in total length. Longer
cable length than the standard provided by seller may have some effect on
sound quality and volume.
3. Cable Connecon
A. If working with camera, connect the speaker
directly to the camera using the standard 3.5mm
Audio cable.
B. If working with NVR/DVR, connect the standard 3.5mm Audio Cable to
the provided RCA adapter and then to the NVR/DVR.
Speaker Specificaons (PR-HS30W)
ITEM SPECIFICATIONS
DIMENSIONS11 285(W) × 205(H)× 280(L)mm
RATED IMPEDANCE12 ACR 8 Ohm
RESONANCE REQUENCY3 700 ± 15%Hz at 1V, 25 ℃
RATED FREQUENCY RANGE 4 300Hz ~ 5.5K Hz (-20dB band)
SOUND PRESSURE LEVEL5 112 ± 3dB 1w/m @ 1K Hz
POWER HANDLING Rated power 30 W Max power 40 W6
SPECIALITY2 Weather proof Paging horn speaker
TOTAL HARMONIC DISTORTION1 5% Max at 1KHz 1W
RUB & BUZZ TEST 285(W) × 205(H)× 280(L)mm 7
SPEAKER WEIGHT 2.1kg ± 10%8
MATERIAL&FINISH9
WORK INVIROMENT10
Finish: White;
Horn: ABS;
Bracket: Stainless Steel
Temp -20℃~+40℃,
Humidity 45%~85%,
Elevation under 1000 m, Dust,
corrosive gas or vibration
which requires special
condition must not be present 285 280
205
100
3- 11
www.provision-isr.com
~60°
90°
3.5m
12 ft
8m
27 ft
13
