Side 1/2

200.00 mm

270.00 mm

Headset pictures..........................................................................................................1

Charging the battery.....................................................................................................1

Turning on the Headset.................................................................................................1

Turning off the Headset.................................................................................................1

Headset in Pairing Mode...............................................................................................2

Establishing Bluetooth Link...........................................................................................3

Answering incoming calls..............................................................................................3

Transferring calls.........................................................................................................4

Muting the microphone.................................................................................................4

Ending calls.................................................................................................................4

To make a new call using v oice d ial................................................................................4

Redialing last dialed number.........................................................................................5

Reject a call.................................................................................................................5

Adjusting speaker volume.............................................................................................5

To wear the headset.....................................................................................................5

Low-battery indication..................................................................................................6

Battery recharging........................................................................................................6

LED Status..................................................................................................................7

Voice Over Internet Protocol (VoIP) Application..............................................................8

FCC Interference statement ........................................................................................9

Declaration of Conformity..........................................................................................11

● Charging the battery

Thank you for buying the new PBT30M Headset with Bluetooth wireless technology. Before

first time use, it is important to charge the battery for 8 hours.

● Turning on the Headset

While the Headset is powered down, press and hold S1 until blue LED turns on. A low tone

followed by a high tone will indicate that the PBT30M is powered up. Afterward, blue LED

will flash every 3 seconds.

● Turning off the Headset

While the Headset is powered up, press and hold S1 until red LED turns on. A high tone

followed by a low tone will indicate that the PBT30M is powered down.

Microphone

Speaker

On Off S1/ ( )

Volume Up (S2)

Volume Down S3 ( )

LED

DC Socket

Redialing las t dialed number (Mo bile pho nes wit h Handsfre e pr ofi les o nly )

To redial th e last numbe r, pre ss a nd ho ld S3 u ntil 4 to nes are h eard. I t ind ic ate s the red ial

is active.

Reject a cal l (Mobil e phone s with Hands free pr ofile s onl y )

To reject a call at t he t ime t he PB T3 0M rings, press and hold S 1 un til y ou hear 2 t one s.

Adjustin g Spe aker Volume:

When a call i s ongoing , pressing and r eleasing S 2 will increa se the speaker volume and

pressing and releasing S3 will decrease the speaker volume on the He ad set . There is a

key ton e to indic ate volume i ncr eas e or decrease. However, a wa rning tone wil l be he ard

when the vol ume l ev el re ac hes i ts maximum o r minimum.

To wear the head set

Make sure th e mic ro phone is poi nting towa rd s you r mou th.

Transferring Calls (For Nokia 3650 or equivalent models)

When you are in session, calls can be transferred from the Bluetooth phone to the HS and from

the HS to the Bluetooth phone.

To transfer a call from the Bluetooth phone to the HS: press S1 once, the call will be

transferred to the HS.

To transfer a call from HS to the Bluetooth phone, please follow the operating instructions of

your phone.

Muting the microphone

To mute the microphone during an active call press both S2 and S3 buttons simultaneously for

about a second and the microphone will be muted. A periodic beep tone will be heard when the

mute function is active.

To end the mute function: When the microphone is muted, press both S2 and S3 buttons

simultaneously. Mute function is ended and the periodic beep tone will stop.

Ending Calls

While a call is in session on the Headset pressing S1 will disconnect the call. After the call is

disconnected, the blue LED will flash normally again.

To make a new call using voice dial

Make sure the voice dialing function is set up in the mobile phone and it is within the range of

the Headset. Press S1 on the PBT30M shortly. There is a beep tone on the headset.Then use

your recorded voice commands ( eg. By saying the name of the person). The call will be

connected in a few seconds.

User Manual

PBT30M

Bluetooth Headset

Headset in Pairing Mode

 Ma sure the PBT30M is fully charged and the charging cable is disconnected from it be fore ke

pairing starts. Wh ile the PBT30M is po wered off, press and ho ld S1 until red and blue LE Ds

flashing alternately. It indicates that the He adset is in Pa iring Mode.

 Follow th e operating instructions for your Bl uetooth mobile phone to st art the pairing pr ocess.

Typically, this has to be done by going to a setup or connect me nu and then selecting the

options to discover Bluetooth devices. Bl uetooth ma y take several seconds to establish a

connection.

 Your phone's display sh ould indicate that it has found the “PBT30M” headset and asks if you

want to pair it. You should confirm this. The ph one's display would pr ompt you for a passkey

or PIN. Enter a sequence of “ ”.0000

 The headset LED will flash blue every 3 seconds, indicating successful pairing. Us ually the

phone will also ask whether you want to change the headset's na me. We recommend to ke ep

the default name PBT30M instead of changing it.

 If pairing does no t occur as ex pected:Turn of f both the headset and the phone and wait for 10

seconds. Turn on the headset and phone again and repeat all steps from beginning. Pairing

does authorize the devices like mobile phones and headsets wi th ea ch other and only needs

to be performed once.

Establishing Bluetooth Link

After successfully pairing the PBT30M and the mobile phone, you may need to establish a Bluetooth

link between them according to the operation manual of your mobile phone. To establish the link, press

S1 shortly. Use Nokia 6130i as an example, the mobile phone will show “Do you accept PBT30M

request for connection?” Select YES to establish the link. You are ready to make and answer calls on

the Headset. For other phones, please follow the operation manual to establish the link. You are ready

to make and answer calls on the Headset.

Please note:

If the headset is powered down, turning on the headset will auto reconnect the last used device. If the

headset is disconnected but powered on, press S1 shortly to connect the link again. If there is

abnormal loss of link happened (e.g. out of range), the headset will automatically try to reconnect the

mobile phone several times.

If the mobile phone cannot locate the network signal (e.g. out of reach) , alert tone will be heard every

5 seconds in the headset.

Not every mobile phone supports no network signal alert feature.

If there is no Bluetooth connection for more than 1 hour, the headset will switch off automatically.

Answering Incoming Calls

When you wear the headset, an incoming call is present, the PBT30M headset will ring. Pressing S1

will answer the call.

Attention: Some phones put the Bluetooth connection into Standby Mode if it has not been used for

some time. When there is phone call in, only the mobile phone rings and it will take a few seconds to

transfer the call to headset. You have to wait until you hear the ring tone in headset. If you press S1 to

take the call before you hear the ring tone in headset, the headset will try to establish Bluetooth

connection. This will cause connection conflicts between mobile phone and headset.

Low-ba ttery indic at ion

The PBT3 0M LED will fla sh r ed instead of b lue when th e ba tt ery is low. There will also a

short be ep period ic ally. After thi s indi cation yo u stil l have up to 15 m in utes talk tim e. Whe n

the batt ery level is too low, the Heads et w ill autom at ic ally power off. I t ca nnot be powered o n

again un less the ch arger is connecte d or the battery is s ufficiently charged.

Battery rechargin g

To recha rge the bat te ry, put t he h eadset on pho ne holder. Dur in g recharg ing, the LED

shows a steady red li ght.

When the battery is f ul ly c harged, t he i ndicato rs o f re d light wil l be off .

The achi evable ta lk t ime and stand by time for the PBT30 M can vary with d iffe rent Blueto oth

mobile phones due to different imple mentation o f po wer down modes.

Keep the headset away from fire to avo id damage.

(1) A/C cha rging (2) Car charging

Note

Material 80g Woodfree Paper:

AB C D E

AB C E

PART NO .:

MCB-8127020-1A

MODEL:

8127

DRAWN:

Limingzan

DATE:

20071204

PAPER SIZE :

UNIT:

SCALE:

: 1 1

:DESCRIPTION

#User Manual For PYLE Logo

In Tech Electronics Ltd- .

Produkt Specifikationer

Mærke:	Pyle
Kategori:	Hovedtelefon
Model:	PBT30M
Vægt:	7 g
Produktfarve:	Sort
Produkttype:	Headset
Bluetooth:	Ja
Batteriteknologi:	Lithium polymer (LiPo)
Dimensioner (BxDxH):	45.97 x 15.49 x 10.16 mm
Bluetooth-version:	2.0+EDR
Forbindelsesteknologi:	Trådløs
Certificering:	CE/FCC/BQB
Taletid:	6 t
Standby tid:	100 t
Bæremåde:	I ørerne
Headset type:	Mono
Trådløs rækkevidde:	10 m
Ørekobling:	Intraaural
