SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: https://www.supermicro.com/wdl/driver/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2023 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
X13srn-H/-e-WoHs
Q r g 1.00uICk eferenCe uIde
• One Supermicro Motherboard
with passive heatsink
(-WOHS without heatsink)
• One Quick Reference Guide
• One Audio Cable (line-out, mic-in)
• One COM Cable
• One SATA Cable
• One SATA Power Cable
• One USB 2.0 Cable
• One DC IN Power Cable
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
F or your system to work properly please download appropriate,
drivers images user s manual From the links below/ / ' :
MNL-2620-QRG-100
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
CPU
JPW1
FAN1
JHDMI1
USB6
USB7
USB4
USB5
JHDMI2
LED1 LAN2 LAN1
JGP1
BT1
JF1
JSIM1_OPT
USB0/1
USB2/3
JSPKR1
AUDIO FP
I-SATA0
P1_PE2 4-0
JPH1
COM3/COM4COM1/COM2
JPT1
MH3
MH1 MH4
MH2
SRW1
SRW2
SRW4
SRW5
USB8
Jumpers, LED Indicators and ConnectorsMotherboard Layout and Features
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide.
Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
Connector Description
BT1 Battery Cable Connector
FAN1 4-pin Fan Header
AUDIO FP Front Panel Audio Header (Line-out, Mic-in)
COM1/COM2 COM Header for two RS232/422/485
COM3/COM4 COM Header for two RS232
I-SATA0 SATA 6 Gb/s Port
JF1 Front Control Panel Header
JGP1 8-bit General Purpose I/O Header
JHDMI1 Back Panel HDMI 2.0b Port
JHDMI2 Back Panel HDMI 1.4b Port
JPH1 4-pin HDD Power Connector
JPW1 8-pin 12-24 V Main Power-in Connector
JSIM1 Nano SIM Card slot
JSMBUS1 System Management Bus Header
JSPKR1 Speaker-out with 3 W Amplier
LAN1, LAN2 2.5G RJ45 LAN Ports
M.2-B1 M.2 B-Key 2242/2280/3042 slot with a Nano SIM slot and support for
SATA 6 Gb/s or PCIe 3.0 x1/USB 3.0/USB 2.0
M.2-E1 M.2 E-Key 2230 PCIe 3.0 x1/USB 2.0/Intel CNVi Slot
M.2-M1 M.2 M-Key PCIe 4.0 p1-x4 2242/2280 Slot
P1_PE2 4-0 PCIe 4.0 p1-x4 SlimSAS Slot
USB0/1, USB 2/3 Front Accessible USB 2.0 headers for four USB 2.0 Ports
USB4, USB6 USB 3.2 (10 Gb/s)/DisplayPort 1.4 Alt Mode Type-C ports on the rear
I/O panel
USB5, USB7 USB 3.2 (10 Gb/s) Type-A ports on the rear I/O panel
USB8
USB 3.2 (5 Gb/s) Type-A
Jumper Description Default
JPME2 CMOS Clear
Manufacturing Mode
Pins 1-3 (Normal)
Pins 4-6 (Normal)
JPT1 Force Power On
TPM 2.0 Enable/Disable
Pins 2-4 (Force Power On)
Pins 1-3 (Enable)
JSIM1_OPT
SIM Detect Option
5G/LTE USB/PCIe Option
M.2 B-Key Storage LED
Pins 2-4 (Low Active)
Pins 1-3 (USB)
Pins 5-6 (Enabled)
LED Description Status
LED1 Onboard Power LED
Green: System On
Red: S5 or Main Power Fail
Off: System Off
LED Indicators
Jumpers
Connectors
DESIGNED IN USA
X13SRN
REV:1.02
2230
22802280
2242 2242
JPME2
JSIM1
SRW3
JSMBUS1
M.2-B1 M.2-E1 M.2-M1
DIMMB1
DIMMA1
SO-DIMM Memory Installation
CPU and Memory Support
Front Control Panel (JF1)
1
4
1
5
1
3
1
7
1
8
1
21
6
X13SRN-H/-H-WOHS supports 13th Generation Intel® Core™ i7-1370PE.
X13SRN-E/-E-WOHS supports 13th Generation Intel® Core™ i5-1350PE.
The X13SRN-H/-E and X13SRN-H/-E-WOHS support up to 64 GB of Non-
ECC DDR5 SO-DIMM with speeds of up to 4800 MT/s in two memory slots.
87
3.3V Stby
3.3V HDD LED
Power LED
21
Reset Button
Power Button
Ground
Ground
# #Denition Description
1 52.5G RJ45 LAN USB 3.2 Type-A
2 62.5G RJ45 LAN USB 3.2/DP 1.4 Type-C
3 7HDMI 1.4b USB 3.2 Type-A
4 USB 3.2/DP 1.4 Type-C HDMI 2.0b8
Align
1. Position the SO-DIMM module's bottom key so it aligns with the receptive
point on the slot.
2. Insert the SO-DIMM module vertically at about a 45-degree angle. Press
down until the module locks into place. The side clips will automatically
secure the SO-DIMM module, locking it into place.
Insert this end rst
Locking Clip
1. Push the side clips at the end of slot to release the SO-DIMM module.
Pull the SO-DIMM module up to remove it from the slot.
Rear I/O Panel Connectors
1
1
SO-DIMM Memory Uninstallation
Top Layout
Bottom Layout
= mounting hole
