Side 1/2
Tips
For initial registration of the ONT, you can configure the quick registration function according to the page
prompts. In INTERNET Settings module, you can set the parameters to set up a WAN connection
according to your ISP and your own needs, and click . If not, refer to the following to set up Apply Changes
a WAN connection.
➊ Choose > .WAN PON WAN
➋ Tick .Enable VLAN
➌ Enter the VLAN ID provided by your ISP.
➍ Set Channel Mode to .PPPoE
➎ Set Connection Type to INTERNET.
➏ Enter the PPPoE UserName and Password provided by your ISP.
➐ Set other parameters according to your ISP and your own needs.
➑ Click .Apply Changes
➒ Click when OK Change setting successfully is shown on the page.
Step 2: Set up a WAN connection
UserName:
Password:
PON WAN
Apply Changes Delete
This page is used to configure the parameters for PONWAN
Enable VLAN:
VLAN ID:
Channel Mode:
Connection Type:
ppp0_nas0_0
11
test
11
PPPoE
INTERNET
LED indicator Color Status Description
Solid on
Solid on
PWR
INET
PON
LOS
LAN
WPS
TEL
Green
Green
Green
Green
Green
USB Green
Red
The ONT is powered on.
The internet access is available through the ONT.
Data is being transmitted through the ONT.
No internet access is available through the ONT.
Solid on The ONT is registered successfully.
Blinking
Blinking
Blinking
Blinking
Solid on
Off
Off
Green
WLAN/
2.4G/5G Green
The received optical power is at a proper value.
Off
Off
The ONT is registering.
Off The ONT is powered off.
The received optical power is lower than the optical receiver sensitivity.
The LAN port is connected. No data is being transmitted.
The ONT is unregistered.
The LAN port is transmitting data.
The LAN port is disconnected.
Blinking
Solid on
Off
The ONT is registered with IMS. No data is being transmitted.
The ONT is registered with IMS and is transmitting data.
The ONT is not registered with IMS.
Blinking
Solid on
Off
The USB port is connected. No data is being transmitted.
The USB port is transmitting data.
The USB port is disconnected.
Blinking
Solid on for
2 minutes
Off
A WPS connection is established.
The WPS negotiation is ongoing.
The WPS function is not activated.
Blinking
Solid on
Off
The Wi-Fi network is enabled.
Data is being transmitted wirelessly.
For the device without the LED indicator: If the WPS function is WPS
activated on the device, the WLAN/2.4G/5G LED indicator blinking
means that the device is performing WPS negotiation.
The Wi-Fi network is disabled.
Port/Button Description
ON/OFF
PON
WLAN
WPS/RST
LED
Press the button to turn on or turn off the ONT.
Optical fiber port. Used to connect to optical network through a fiber cord.
PWR Used to connect the ONT to a power source using the included power adapter.
USB USB 2.0 port. Used to connect to a USB storage for resource sharing.
Wi-Fi on/off button. Press the button to enable or disable the Wi-Fi function of the ONT.
TEL
LAN1-4
Telephone port. Used to connect to a telephone for voice service using a telephone cable.
Gigabit LAN ports. Used to connect to such devices as routers, switches, computers or IPTV
set-top boxes.
LED indicator on/off button. Press the button to turn on or off the LED indicators of the ONT.
WPS/Reset button.
• : WPS-supported devices can connect to the Wi-Fi networks of the ONT without entering WPS
the password through WPS negotiation.
Press the button for about 1-3 seconds to start the WPS negotiation process of the ONT. The
WPS (marked ) LED indicator blinks quickly. Within 2 minutes, enable the WLAN/2.4G/5G/WPS
WPS function to establish a WPS connection on a WPS-supported device.
• : Restore the ONT to the configurations preset by the ISP or restore the ONT to factory Reset
settings.
- To restore the ONT to the configurations preset by the ISP: After the ONT completes
startup, press the button for 10 to 60 seconds and release it. All LED indicators will light
off in a few seconds. When the LED indicator lights solid on again, the ONT is PWR
restored to the configurations preset by the ISP.
- To restore the ONT to factory settings: After the ONT completes startup, press the button
for more than 1 minute and release it. All LED indicators will light off in a few seconds.
When the LED indicator lights solid on again, the ONT is restored to the factory PWR
settings.
Tips
This ONT supports wall mounting (two mounting holes on the bottom). The recommended parts are as follows:
- Expansion bolt: Thread diameter: 6.0 mm; Length: 26.4 mm; Inner diameter: 2.4
- Screw: Quantity: 2; Diameter: 3.0-4.0 mm; Head diameter: 5.0-6.5 mm.
Tips
• HG15 is used for illustration here unless otherwise specified. The actual product prevails
• Press button (if any) to turn on the ONT.ON/OFF
• If ISP provides any parameters for registration, you can use them to manually register the ONT with the quick
registration function. The quick registration function is available only when the ONT is registered for the first time.
Method:
Refer to Step 1 Router mode 2. Configure the internet access in the of the .
➊ Log in to the web UI of the ONT.
➋ In (or ) module, register with the parameters provided by your ISP and click GPON Settings EPON Settings
Apply Changes.
➋
Get to know the ONT
1. Connect and register the ONT
Caution, laser
DO NOT look directly at the port when the device is powered on, as well as the terminal of the indoor fiber PON
cord, to prevent any harm to your eyes.
Connect the ONT as shown in the figure. Wait until the LED indicator lights solid on, then the ONT is PON
registered successfully.
(Example: HG15)
Tips
HG15 is used for illustration here unless otherwise specified. The actual product prevails.
(Example: HG15)
Power adapter
Rear panel
PON TEL LAN2 LAN1PWR
WPS / RST
Bottom panel
Fiber cord
PON port
Tips
If the above page does not appear, refer to in . Q1 FAQ
Tips
- PPPoE is used for illustration here. Change the parameters as required by your ISP.
- Choose a desired mode to configure your internet access:
Router mode: Configure the internet on the ONT.
Bridge mode: Dial-up on the router or terminal connected to the ONT.
Tips
You can log in to the web UI of the ONT with user permissions or administrator permissions. Administrator
permissions are for the installation and maintenance personnel only.
• : Able to view and modify partial configurations of the ONT. The default login user User Permissions
name is . You can get the password from the bottom label on the ONT.admin
• Administrator Permissions: Able to view and modify all configurations of the ONT. Some
configurations changed by the installation and maintenance personnel will affect the normal operation
of the ONT. Therefore, use the administrator permissions with caution. The default login user name and
password are both admin (or root).
2. Configure the internet access
➊ Connect to the ONT.
• Wired device: Connect a LAN port of the ONT to a wired device, such as a computer, using an Ethernet
cable.
• Wireless device: Connect your wireless device, such as a smartphone, to the Wi-Fi network of the ONT
using the (Wi-Fi name) and (Wi-Fi password) on the bottom label.SSID Key
➋ Start a web browser and visit .192.168.1.1
➌ Enter the and User Name Password according to the actual permissions.
➍ Click .Login
Step 1: Log in to the web UI
Router mode
192.168.1.1
User Name:
Password:
ResetLogin
Ports/Buttons
Quick Installation Guide
HG Series xPON ONT
Package contents
• xPON ONT x 1
• Power adapter x 1
• Ethernet cable x 1
• Telephone cable x 1 (if any)
• Optical fiber cable x 1 (if any)
• Quick installation guide x 1
LED indicators
The LED indicators may vary with models. The actual product prevails. The ports and buttons may vary with models. The actual product prevails.
➊
