PACKAGE CONTENTS

Unit User Manual

L60 / L61

• rThe Pod uct warrranty is printed on the back of this gu ide.

• r rThis P oduct is manufactu ed for use onl y in USA / CA.

• r y.This P oduct is suitable for 120 V onl

Model Name:

Ultra sonic Humi diﬁer

Mist Nozzle

Water

Tank Cap

Mist Rotary

Switch

Water Tank

Bottom

Water Level Sensor

Air Outlet

Ultrasonic Transducer

WHERE TO USE

MODEL PART DIAGRAM

12~18 in

•Position the humidifier at least 12 in / 30 cm away from walls and

appliances to prevent them from getting wet.

•Place the humidifier on a table or desk. Do not place it directly on

the floor or carpet.

•Do not place the unit against walls or objects or in areas with poor

air circulation. Doing so may result in improper readings produced

by the built-in humidity sensor.

•If used in a closed (sealed) room without proper ventilation and no

heat exchange with outside air, water collection can occur when

the humidified air touches the cold surface. In such cases, it is

recommended to use in a lower mist level.

01. Power & Mist Rotary Switch Button

•Turn the control dial clockwise.

•Power and mist level can be set by dialing the knob control, freely adjust the mist for quieter operation.

02. Empty Tank Alarm

If there is not enough water, the unit will stop and the red LED indicator will continue to blink at the same time.

03. Night Mood Light

•Press the Night Mood Light button once to turn on the Night Mood Light. The light at the bottom of the water

tank will turn on, illuminating the tank.

•The brightness of the light can be switched OFF > Blue > Green > Amber > OFF.

CONTROL PANEL

Capacity

•0.6 Gallon - 2.2 Liters

Max. 30 Hours Runtime

•Based on the natural humidity level in your home, the temperature of water you use, and the mist-level setting

you choose, you may experience longer or shorter runtimes.

Adjustable Mist Level

•Mist adjusts from the lowest output to highest ouput.

•The corresponding mist level will be lit on the Mist Rotary Switch Button.

Whisper-Quiet Operation

•Noise level below 28 dB allows you to sleep easily in a comfortable and quiet environment.

Night Mood Light

•A useful light feature is included with the option of an independent Night Mood Light or touch button controls.

Auto Shut Off Protection

•When the tank is empty, the unit will shut off automatically.

How do you add essential oils?

1. Essential oil can only be added to the base.

2. Always add around 100 ml water to the base before adding essential oil.

MAINTENANCE AND CLEANING

ULTRASONIC WARM & COOL MIST HUMIDIFICATION

Read all instructions before installation and use

•Always place humidifier on a firm, flat surface.

A waterproof mat or pad is recommended for under

the humidifier. A finished floor may be damaged by

water or moisture exposure.

•Do not reach for a unit that has fallen into water.

Unplug it immediately.

•Always unplug the unit from the electrical outlet

immediately after using and before cleaning.

•Do not place or store the unit where it can fall or be

pulled into a tub or sink.

Wash the nozzle, cover separately, and let tank dry in

the shade

•Clean tank at least once or twice a week using

clean water.

•Naturally occurring stains inside the tank can be

cleaned using a soft cloth.

•Do not use chemicals such as bleach, abrasive, etc.

to clean.

Cleaning the ultrasonic transducer

•Clean the ultrasonic module of

the humidifier at least once or

twice a week.

•Tilt it in the direction of the air

hinge when disposing of

the water in the main body.

•Do not allow water into this

opening.

•Never touch the transducer / ultrasonic membrane

with your fingers; the natural oils in skin can

damage the surface.

•Never clean the ultrasonic membrane by scraping

with a hard object. Scratching the surface of the

vibrator with a sharp object may cause the Mist

Output to weaken or cause failure.

•Never submerge the base in water or any other liquid.

•In general, if the user touches the transducer/

ultrasonic membrane with your fingers, the natural

oil and cosmetics in your skin can damage the

surface, resulting in irregular mist output.

In order to have the unit run properly after this

occurs, you need to:

1. Wash the water tank and the base 2 ~ 3 times and

then restart the unit. In case the unit is not washed,

the unit will operate normally after running for

30 min ~ 1 hour on continuous mode.

2. If the water is not enough, the mist may not be

generated properly. (This may be a defect in the air

hinge or water valve).

There should be at least

30 mm of water in the base after removing the

water tanks.

Guide bracket silencer

•It is best to wash off with clean running water.

•Dry and refit.

Deep cleaning (with vinegar)

•Before and after storing the humidifier for a long

period of time, dry the water in the Mist Output

completely and wipe clean.

•Clean the tank, reservoir, tank cap, and the

transducer/ultrasonic membrane with a 10:1

mixture of water and white vinegar.

•Fill the tank with diluted vinegar water to the

maximum level.

•Put about 400 mL of mixed water into the main

body.

•Fill the water tank and main body with water and

leave for 30 to 60 minutes.

•Pour mixed water and rinse with clean tap water

2 ~ 3 times.

•Dry the parts in a well-shaded place.

•Please reassemble the dried product.

INITIAL OPERATION

1. Position the unit on a flat and hard surface.

Remove the upper cover and water tank from

the base.

2. Pour around room temperature water into the

base.

3. Add 6 - 7 drops of essential oil into the base as

shown. You may increase the amount of essential

oil to your liking.

4. Place the water tank back on and fill it with room

temperature water, not exceeding the MAX line.

If you don’t use essential oil, please ignore steps 2 - 4.

5. Place the cover back on the water tank and make

sure it is sitting well.

6. Plug in and turn on the appliance. Always add

the water into the unit before connecting to power.

•This prouct is intended for household use only.

•Never cover the unit while it is operating.

•Always keep the cord away from high temperature and

fire.

•Perform regular maintenance on the ultrasonic

membrane.

•Never use detergent to clean the ultrasonic membrane.

•Do not attempt to adjust or repair the unit. Servicing must

be performed by a professional or qualified personnel.

•Stop using the unit if there is an unusual noise or smell.

•Unplug the unit when not in use for a long period of time.

•Do not touch the water or any parts of the unit that are

covered by water while the unit is on or plugged in.

•Never operate without water in the tank.

•Only use water in the tank.

•Never use any additives in the water.

•Keep this unit out of the reach of children. Do not allow

children to use this unit without supervision.

•Do not use outdoors. For indoor use only.

W A R N I N G

Follow the instructions in this manual to reduce

the risk of electric shock, short circuit, and/or fire.

•If the power cord is damaged, it must be replaced

with a special cord. Reassembly is available from the

manufacturer or its service agent.

•This appliance is not intended for use by a person

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge

about this unit, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

•Children should be supervised to ensure that they do not

play with the appliance.

•This unit is not intended to be used to preserve

documents or for art conservation.

Do not pull on the power cord when unplugging

the unit.

Do not tie or knot the power cord while unit is in

operation.

If the unit becomes submerged in water, unplug it

and contact customer service.

Do not unplug or move the unit while in operation.

Do not plug additional appliances into the same

outlet or power supply.

Do not touch the plug with wet hands.

Unplug the unit when not in operation for extended

periods of time.

Do not place around heating elements.

Do not use around mist or fumes from industrial oil

or around large quantities of metallic dust.

The cord can become damaged by forcefully

bending, pulling, twisting, bundling, pinching or

placing heavy objects on it.

Do not install in any sort of motor or transport

vehicle (trucks, boats, ships, etc.).

Do not place in an area with excessive amounts of

noxious gases.

Do not place near any flammable materials

(aerosols, fuel, gases, etc.).

Do not have the unit facing into wind or drafts.

Do not place below any electrical outlet.

Do not place in excessively humid areas where

the unit may become wet.

To reduce the risk of fire or electric shock,

do not use this appliance with any solid-state

speed control device.

SAFETY & CAUTIONS

1 2

CAUTION: Before filling the tank with water, turn the power off and unplug the unit from the outlet.

LUNA0.5_EN.indd 1

LUNA0.5_EN.indd 1LUNA0.5_EN.indd 1 2020-10-22  5:51:13

2020-10-22  5:51:13

2020-10-22  5:51:132020-10-22  5:51:13
