XCV / YCV / SWITCH: Voltage co
trol over the crossfade amount
the respective crossfader. Setti
the switch to the right position w
normal XCV to YCV. The center p
sition will break the normal. T
left position inverts the CV fro
XCV and applies it to YCV.
Stereo patching in the Eurorack environment is becoming more common every day.
While easy to understand, stereo crossfading can be resource intensive to patch. AXYS
solves this issue by providing two high quality CV controllable crossfaders in 6HP . We
sweeten the package with flexible normalling and ever useful input metering. AXYS is
simply a must have for any system utilizing the stereo field.
A LVL / B LVL LED’s: Displays t
combined input level of the cor
sponding input pair.
ECS:
wer: +12V = 50mA; -12V = 50mA
ze: 6HP
pth: 38mm.
Input Impedance: 100K
dio Input Impedance: 20k
tput Impedance: 220 ohms
A / IN B: Inputs for the cross-
ders. The bottom jacks normal
the top jacks, indicated by the
row.
OSSFADE X / Y: Manually cross-
de between the corresponding
put pairs. Crossfade level is in-
cated on the orange LED’s above
e potentiometer.
AXYS
DUAL STEREO CROSSFADER
Placing the dry signal into IN A and
the effected signal into IN B on cross-
fader x. Run the output into IN B of
crossfader y. Leave IN A of crossfad-
er y empty. The Crossfade X knob is
your wet/dry control. Crossfade Y is
volume.
o Panning:
g one crossfader section, mult your sig
to the bottom jack of IN A and the top
of IN B. Insert a cable or dummy plug
the top jack of IN A to break the normal
the crossfade knob or corresponding CV
an your mono signal.
allel Compression:
your non-compressed signal into
A on either crossfader. Put your
pressed signal into IN B on the
e crossfader. Listen to the output
use the crossfade knob to bal-
e between the two signals.
