SP1
L2
L1
L1
L2
SCALING POLARIZER 1 & 2
Use these controls to change the of the respective input signals.amplitude and polarity
Center position (0) turns the respective input signal level o.
Maximum position (+) results in the full, normal signal.
Minimum position (-) results in the full, inverted signal.
OFFSET 1 & 2
Use these controls to to the respective input signals. This control will add a (+/-5V) DC oset
send a bipolar DC oset to the output whether or not a signal is applied to one of the
inputs.
Center position (0) turns the oset level o.
Maximum position (+) results in the full, (+5V) positive oset signal.
Minimum position (-) results in the full, (-5V) inverted oset signal.
S.P.O. is a polarizing scaler and oset generator. Up to two inputs can be summed into a single
scaler/oset generator. The oset generator provides a DC oset for shifting signals into the
positive or negative voltage region. The scaler provides a means of attenuating and polarizing
(inverting) the applied signal. S.P.O. works with audio and control voltages (CV).
SUMMING INPUTS 1 & 2
These are the respective inputs to the polarizers and oset generators. There are two
inputs each. Applying two signals will sum them together. Both audio and control
voltages (CV) can be utilized.
BIPOLAR LEVEL LED 1 & 2
These LEDs indicate of the polarity of the input signal and/or oset. BLUE is positive and
RED is negative.
OUT
PANEL CONTROL
LED INDICATOR
INPUT
OUTPUT
COLOR KEY LEGEND
OUTPUTS 1 & 2
These are the respective outputs for each polarizer/oset generator.
OF1
SP1
SP2
OF2
IN 1
A+B IN 2
A+B
2
OUT
1
SP2
OF1
OF2
IN 1
A+B
IN 2
A+B
OUT
1
OUT
2
IN 1
OUT
+
+
SP 1
SIGNAL PATH DIAGRAM
A
IN 1
B
ΣOF 1 1
+
IN 2
OUT
+
+
SP 2
A
IN 2
B
ΣOF 2 2
+
Σ= SUM
