Side 1/228
G
BLU-RAY DISC PLAYER
LECTEUR BLU-RAY DISC
BD-S2900
OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
GEBRUIKSAANWIJZING
i
VAROITUS
Muiden kuin tässä esitettyjen toimintojen säädön tai asetusten muutto
saattaa altistaa vaaralliselle säteilylle tai muille vaarallisille
toiminnoille.
DK
Advarsel: Usynlig laserstråling ved åbning når sikkerhedsafbrydere er
ude af funktion. Undgå utsættelse for stråling.
Bemærk: Netafbryderen STANDBY/ON er sekundært indkoblet og
ofbryder ikke strømmen fra nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket sidder i stikkontakten.
N
Observer: Nettbryteren STANDBY/ON er sekundert innkoplet. Den
innebygdenetdelen er derfor ikke frakoplet nettet så lenge apparatet er
tilsluttet nettkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på annat sättþän i denna
bruksanvisning specificerats, kan användaren utsättas för osynlig
laserstrålning, som överskrider gränsen för laserklass 1.
Observera! Strömbrytaren STANDBY/ON är sekundärt kopplad och
inte bryter inte strömmen från nätet. Den inbyggda nätdelen är därför
ansluten till elnätet så länge stickproppen sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen muulla kuin tässä käyttöohjeessa
mainitulla tavalla saattaa altistaa käyttäjän turvallisuusluokan 1
ylittävälle näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei saa olla alttiina tippu-ja
roiskevedelle.
Toiminnanvalitsin STANDBY/ON on kytketty toisiopuolelle, eikä se
kytke laitetta irti sähköverkosta. Sisäänrakennettu verkko-osa on
kytkettynä sähköverkkoon aina silloin, kun pistoke on pistorasiassa.
Important notes for users in
the U.K.
Mains plug
This apparatus is fitted with an approved 13 Amp plug. To
change a fuse in this type of plug proceed as follows:
1Remove fuse cover and fuse.
2Fix new fuse which should be a BS1362 5 Amp, A.S.T.
3Refit the fuse cover.
If the fitted plug is not suitable for your jack outlets, it should be
cut off and an appropriate plug fitted in its place.
If the mains plug contains a fuse, this should have a value of 5
Amp. If a plug without a fuse is used, the fuse at the distribution
board should not be greater than 5 Amp.
Note: The severed plug must be disposed to avoid a possible
shock hazard should it be inserted into a 13 Amp jack elsewhere.
How to connect a plug
The wires in the mains lead are coloured with the following
code:
blue = neutral (N), brown = live (L).
•As these colours may not correspond with the colour
markings identifying the terminals in your plug, proceed as
follows:
– Connect the blue wire to the terminal marked N or
coloured black
– Connect the brown wire to the terminal marked L or
coloured red.
– Do not connect either wire to the earth terminal in the
plug, marked E (or e) or coloured green (or green and
yellow).
Before replacing the plug cover, make certain that the cord grip
is clamped over the sheath of the lead - not simply over the two
wires.
Copyright in the U.K.
Recording and playback of material may require consent. See
Copyright Act 1956 and The Performer’s Protection Acts 1958
to 1972.
VARO!
AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET
ALTTIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
ÄLÄ KATSO SÄ TEESEEN.
VARNING!
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR
ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ
STRÅLEN.
ii
CAUTION
Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
AVERTISSEMENT
L’utilisation de commandes et l’emploi de réglages ou de méthodes
autres que ceux décrits ci-dessous, peuvent entraîner une exposition
à un rayonnement dangereux.
VORSICHT
Die Verwendung von Bedienelementen oder die Einstellung bzw.
die Ausführung von anderen als in dieser Anleitung beschriebenen
Vorgängen kann zu Gefährdung durch gefährliche Strahlung führen.
OBSERVERA
Användning av reglage eller justeringar eller utförande av åtgärder
på annat sätt än så som beskrivs häri kan resultera i farlig strålning.
ATTENZIONE
L’uso di controlli, regolazioni, operazioni o procedure non
specificati in questo manuale possono risultare in esposizione a
radiazioni pericolose.
PRECAUCIÓN
El uso de los controles, los ajustes o los procedimientos que no se
especifican enste manual pueden causar una exposición peligrosa a
la radiación.
LET OP
Gebruik van bedieningsorganen, instellingen of procedures anders
dan beschreven in dit document kan leiden tot blootstelling aan
gevaarlijke stralen.
ПРЕДОСТЕРЕЖЕНИЕ
Использование органов управления или произведение
настроек или выполнение процедур, не указанных в данной
инструкции, может отразиться на выделении опасной
радиации.
CAUTION
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
ADVARSEL
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING.
UNDGÅ UDSÆTTELSE FOR STRÅLING.
ADVARSEL
SYNLIG OG USYNLIG LASERSTRÅLING NÅR DEKSEL
ÅPNES. UNNGÅ EKSPONERING FOR STRÅLEN.
VARNING
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD. BETRAKTA EJ STRÅLEN.
VARO!
AVATTAESSA OLET ALTTIINA NÄKYVÄLLE JA
NÄKYMÄTTÖMÄLLE LASER SÄ TEILYLLE. ÄLÄ KATSO
SÄTEESEEN.
VORSICHT
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG
WENN ABDECKUNG GEÖFFNET. NICHT DEM STRAHL
AUSSETSEN.
DANGER
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
ATTENTION
RAYONNEMENT LASER VISIBLE ET INVISIBLE EN CAS
D’OUVERTURE. EXPOSITION DANGEREUSE AU FAISCEAU.
ПРЕДУПРЕЖДЕНИЕ
ПPИ OTKPЫTИИ УCTPOЙCTBA BЫ MOЖETE
ПОДBEPГHУTБСЯ ВОЗДЕЙСТВИЮ BИДИMOГO И
HEBИДИMOГO ЛAЗEPHOГO ИЗЛУЧEHИЯ.
ИЗБЕГAИTE BOЗДЕЙСТВИЯ ЛУЧA.
CAUTION: READ THIS BEFORE OPERATING THIS UNIT.
iii En
1To assure the finest performance, please read this manual carefully.
Keep it in a safe place for future reference.
2Install this unit in a well ventilated, cool, dry, clean place — away
from direct sunlight, heat sources, vibration, dust, moisture, or cold.
In a cabinet, allow about 2.5 cm (1 inch) of free space all around
this unit for adequate ventilation.
3Locate this unit away from other electrical appliances, motors, or
transformers to avoid humming sounds.
4Do not expose this unit to sudden temperature changes from cold to
hot, nor locate this unit in an environment with high humidity (i.e., a
room with a humidifier) to prevent condensation inside this unit,
which may cause an electrical shock, fire, damage to this unit, and/
or personal injury.
5Avoid installing this unit in a location where foreign objects may
fall onto this unit or where this unit may be exposed to liquid
dripping or splashing. On the top of this unit, do not place:
– Other components, as they may cause damage and/or
discoloration on the surface of this unit.
– Burning objects (i.e., candles), as they may cause fire,
damage to this unit, and/or personal injury.
– Containers with liquid in them, as they may fall, spilling the
liquid and causing an electrical shock to the user and/or
damage to this unit.
6Do not cover this unit with a newspaper, tablecloth, curtain, etc. in
order not to obstruct heat radiation. If the temperature inside this
unit rises, it may cause fire, damage to this unit, and/or personal
injury.
7Do not plug in this unit to a wall outlet until all connections are
complete.
8Do not operate this unit upside-down. It may overheat, possibly
causing damage.
9Do not use excessive force on switches, knobs and/or cords.
10 When disconnecting the power cord from the wall outlet, grasp the
plug; do not pull the cord.
11 Do not clean this unit with chemical solvents; this might damage the
finish. Use a clean, dry cloth.
12 Use only the voltage specified on this unit. Using this unit with a
higher voltage than specified is dangerous and may cause fire,
damage to this unit, and/or personal injury. Yamaha will not be held
responsible for any damage resulting from use of this unit with a
voltage other than as specified.
13 Do not attempt to modify or fix this unit. Contact qualified Yamaha
service personnel when any service is needed. The cabinet should
never be opened for any reason.
14 When not planning to use this unit for long periods of time (i.e.,
vacation), disconnect the AC power plug from the wall outlet.
15 Be sure to read the “TROUBLESHOOTING GUIDE” section on
common operating errors before concluding that this unit is faulty.
16 Before moving this unit, press STANDBY/ON to set the unit in
standby mode, then disconnect the AC power plug from the wall
outlet.
17 Install this unit near the AC outlet and where the AC power plug
can be reached easily.
18 The batteries shall not be exposed to excessive heat such as
sunshine, fire or the like.
LASER SAFETY
This unit employs a laser. Due to possible eye injury, only a qualified
service person should remove the cover or attempt to service this
device.
DANGER
This unit emits visible laser radiation when open. Avoid direct eye
exposure to beam.
When this unit is plugged into a wall outlet, do not place your eyes
close to the opening of the disc tray and other openings or look inside.
CAUTION: READ THIS BEFORE OPERATING THIS UNIT.
The unit is not disconnected from the AC power source as long as it
is connected to the wall outlet, even if this unit itself is turned off by
STANDBY/ON. This state is called the standby mode. In this state,
this unit is designed to consume a very small quantity of power.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
LASER Specification:
Class 1 LASER Product
Wave length: 782 nm (CDs)/662 nm (DVDs)/405 nm (BDs)
Laser power: No hazardous radiation is emitted with the safety
protection
Region management information
BD-Video
This unit plays BD-Video marked with labels containing the region code B.
Example:
DVD-Video
This unit plays DVD-Video marked with labels containing the region number “2” or “ALL”.
Example:
2ALL 35
2
2 En
GETTING STARTED
This chart shows the different type of retail/commercial discs you can use, and also includes the industry-standard logos that should appear on the discs and/or
packaging.
This chart shows the different type of discs recorded with DVD recorders, DVD video cameras, personal computers, etc. that you can use.
This mark means you must finalize the disc with the DVD recorder, etc. before playback. For details about finalizing, refer to the operating
instructions for your equipment.
DISC AND CARD INFORMATION
Packaged discs
Recorded discs
Type of media/Logo
Features
Indicated as
BD-Video High Definition (HD) movie and music
discs
Type of media/Logo
Features
Indicated as
DVD-Video High quality movie and music discs
CD Compact Discs (CD’s) that contain audio
and music
• Operation and sound quality of CDs
that do not conform to CD-DA
specifications (copy control CDs,
etc.) cannot be guaranteed.
• It may not be possible to play the above discs in some cases due to the type of discs,
the condition of the recording, the recording method and how the files were created.
• When a disc recorded in the AVCHD format is being played, the video may be
paused for a few seconds at portions spliced, due to deletion or editing.
Type of media/Logo
Formats
Indicated as
BD-RE • Version 3 of the BD-RE Recording
Format
•JPEG format
BD-R • Version 2 of the BD-R Recording
Format
DVD-RAM • Version 1.1 of the DVD Video
Recording Format
•JPEG format
• AVCHD format
DVD-R/RW • DVD-Video Format
• Version 1.1 of the DVD Video
Recording Format
• AVCHD format
Type of media/Logo
Formats
Indicated as
DVD-R DL • DVD-Video Format
• Version 1.2 of the DVD Video
Recording Format
• AVCHD format
DVD+R/+RW/
+R DL
• DVD+VR (DVD+R/+RW Video
Recording) Format
• AVCHD format
CD-R/RW • CD-DA format
•MP3 format
•JPEG format
3 En
English
GETTING STARTED
This chart shows the different type of cards recorded with High Definition Camcorder or personal computers, etc. that you can use.
• Enjoy Final Standard Profile functions (]11), such as picture-in-picture. The various functions differ depending on the disc.
• When playing a set of two or more BD-Video discs, the menu screen of the previous disc may continue to display even if the disc has been ejected.
• Regarding high specification audio (7.1ch) of BD-Video such as Dolby Digital Plus, Dolby TrueHD, DTS-HD High Resolution Audio and DTS-
HD Master Audio (]20)
– they can be reproduced in the original format only when connected to a compatible amplifier/receiver with a HDMI AV OUT terminal (]5) and when “BD-
Video Secondary Audio” is set to “Off” and “Bitstream” is selected in each format.
– they are output only as Dolby Digital bitstream when “BD-Video Secondary Audio” is set to “On” even when the unit is connected using the HDMI AV OUT
terminal.
– they are output only as Dolby Digital or DTS bitstream (depending to the original format) when the unit is connected using the DIGITAL AUDIO OUT terminal.
SD cards
Regarding BD-Video
Discs that cannot be played
USING REMOTE CONTROL
*Including miniSD Card and microSD Card
• When using from 4 GB to 16 GB SD cards, only SD cards that display the SDHC logo
can be used.
• This unit is compatible with SD Memory Cards that meet SD Card Specifications
FAT 12 and FAT 16 formats, as well as SDHC Memory Cards in FAT 32 format.
• In t
hi
s owner
’
s manua
l
, t
h
e car
d
s s
h
own
i
n t
h
e ta
bl
e
(]l
e
f
t
)
are compre
h
ens
i
ve
l
y
called SD cards.
• A miniSD Card and a microSD Card must be used with the attached
adaptor that comes with the card.
• Usable memory is slightly less than the card capacity.
• If the SD card is formatted on a PC, you may not be able to use it on this
unit.
• Keep the Memory Card out of reach of children to prevent swallowing.
• When a card recorded in the AVCHD format is being played, the video
may be paused for a few seconds at portions spliced, due to deletion or
edition.
• Switch the write-protect switch to the “LOCK” position to protect the content from
accidental erasure.
Type of media Formats Indicated as
SD Memory Card*
(from 8 MB to 2 GB)
SDHC Memory Card
(from 4 GB to 16 GB)
•JPEG format
• AVCHD format
• BD-RE with the cartridge
• 2.6 GB and 5.2 GB DVD-RAM
• 3.95 GB and 4.7 GB DVD-R for Authoring
• DVD-RAM that cannot be removed from their cartridges
• Version 1.0 of DVD-RW
• DVD+R 8 cm (3"), DVD-ROM, CD-ROM, CDV, Photo CD, MV-Disc and PD
• SACD (except for CD layer)
• DVD-Audio (except for DVD-Video part)
• Video CD and SVCD
• WMA discs
• DivX discs
• HD DVD
• Other discs that are not specifically supported
Batter
i
es
Insert so the poles (+ and –) match those in the remote control.
• Do not use rechargeable type batteries.
• Do not mix old and new batteries.
• Do not use different types at the same time.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in an automobile exposed to direct sunlight
for a long period of time with doors and windows closed.
• Do not take apart or short circuit.
• Do not attempt to recharge alkaline or manganese batteries.
• Do not use batteries if the covering has been peeled off.
Mishandling of batteries can cause electrolyte leakage which can
damage items the fluid contacts and may cause a fire.
Remove batteries if the remote control is not going to be used for a
long period of time. Store in a cool, dark place.
Use
AA, R6, UM-3
Remote control signal sensor
6 m (20 feet) directly in front of the unit
4 En
GETTING STARTED
From the list below, please choose the connection method that fits your TV viewing environment best.
• If you connect to a television using an included Audio/Video cable ]
• If you connect to an HDMI (]29) compatible television ]
• If you connect to an HDMI compatible television and an HDMI compatible amplifier/receiver to enjoy surround sound ] (]5)
• For other connection methods, please see pages 5 and 6.
Connecting to a television with an Audio/Video cable
Connecting to an HDMI compatible television
You can enjoy high quality, digital video and audio.
CONNECTION
•Do not connect through the video cassette recorder. Due to copy guard protection, the picture may not display properly.
• Turn off all equipment before connection and read the appropriate operating instructions.
Conserving power
This unit consumes a small amount of power even when it is turned off (less than 1 W). To save power when the unit is not to be used for
a long time, unplug it from the household AC mains socket.
• Non-HDMI-compliant cables cannot be utilized.
• Please use HIGH SPEED HDMI cables that have the HDMI logo (as shown on the cover).
Basic connections
Notes
• Connect terminals of the same colour.
• High definition video cannot be output
with this connection.
Use connection , or (]5) for
high definition video.
* With audio cables, connect the AUDIO OUT
terminals to the two-channel audio input
terminals of an analog amplifier/receiver or
system component in place of a television to
enjoy stereo sound.
To improve picture quality
• Use connections or (]5).
To enjoy a richer sound
• Use connections or (]6).
(Unplug the red and white plugs.)
Note
NECESSARY SETTINGS
• “HDMI Video Mode” and “HDMI Audio
Output” : “On” (]21)
To enjoy a richer sound
• Use connections or (]6)
additionally.
In this case, set “HDMI Video Mode” to
“On” and “HDMI Audio Output” to “Off”
(]21).
With this connection, you can use linked
operations with the TV (]16).
BE SURE TO READ PAGE i BEFORE CONNECTION.
For the United Kingdom only
Television
Audio/Video cable
(included)
AUDIO/
VIDEO IN
VIDEO OUT
2ch AUDIO OUT*
Cooling fan
Back of the unit
Power cable (included)
Connect only after all other
connections are complete.
To a household mains socket
(AC 230 V, 50 Hz)
Tips
HDMI
compatible
television
HDMI cable
HDMI AV OUT
Cooling fan
Back of the unit
Power cable (included)
Connect only after all other connections are complete.
To a household mains socket
(AC 230 V, 50 Hz)
HDMI IN
Tips
5 En
English
GETTING STARTED
Connecting to an HDMI compatible television and HDMI compatible amplifier/receiver
When connected to a compatible amplifier/receiver, you can enjoy surround sound recorded with Dolby Digital Plus, Dolby TrueHD or DTS-HD.
With S VIDEO OUT
The S VIDEO OUT terminal provides a more vivid picture than the VIDEO OUT terminal.
With COMPONENT VIDEO OUT
You can enjoy high definition images by connecting to a component video terminals that supports 720p (750p) and 1080i (1125i) signals.
Notes
NECESSARY SETTINGS
• “HDMI Video Mode” and “HDMI Audio
Output” : “On” (]21)
• “Speaker” : “Multi Channel” (]22)
• “Digital Audio Output” : Depending on the
connected amplifier/receiver (]20)
With this connection, you can use linked
operations with the TV (]16).
Connection methods for using other video terminals
Notes
• High definition video cannot be output
with this connection.
Use connection (]4), or for
high definition video.
• Unplug the yellow plug of Audio/Video
cable.
• Actual video quality depends on the
television.
Notes
• Connect terminals of the same colour.
• Unplug the yellow plug of Audio/Video cable.
• The video output resolution is restricted to
“576p/480p” when DVD-Video and BD-
Video discs recorded at a rate of 50 frames
per second is output from the
COMPONENT VIDEO OUT terminals.
If you have a regular television (CRT:
cathode ray tube)
• Progressive output may cause some flickering,
even if it is progressive compatible. Turn off
“Progressive” if you are concerned about it.
This is the same for multi system televisions
using PAL mode. (]18, “Progressive”)
To enjoy high definition/progressive video
• Connect to a television that supports 576p/
480p or higher.
• Set “Component Resolution” to “576p/
480p”, “720p” or “1080i”. (]22)
• Set “HDMI Video Mode” to “Off”. (]21)
Otherwise, the video is output as 576i/480i.
HDMI
compatible
television
HDMI IN
Power cable
(included)
Connect only after all
other connections are
complete.
To a household mains socket
(AC 230 V, 50 Hz)
Multi channel speakers
Back of the unit HDMI Cable
HDMI compatible
amplifier/receiver
HDMI IN
HDMI AV OUT
HDMI OUT
Cooling fan
Tip
Television
Audio/
Video cable
(included)
S Video cable
Back of the unit
Television
Audio/Video cable
(included)
Component
Video cable
Back of the unit
Tips
8 En
GETTING STARTED
1STANDBY/ON button (]8)
Press to switch the unit from on to standby mode or vice versa. In
standby mode, the unit is still consuming a small amount of power.
2Disc tray (]9)
3Display
The indicator blinks when reading data from a disc or card.
4SD Card LED
• It is possible to set the LED to turn on/off. (]21, SD Card
LED Control)
5SD card slot (]12)
6Remote control signal sensor (]3)
7Open or close the disc tray (]9)
8Search/Slow-motion/Skip (]10)
Search: Press and hold (During play)
Slow-motion: Press and hold (During pause)
Skip: Press
9Start play (]9)
0Pause (]10)
qStop (]10)
Rear panel terminals (]4-7)
After connecting your new player and pressing the standby/on button, a screen for the basic settings will appear.
Disc indicator SD card indicator
EASY SETTING
Preparation
Turn on the television and select the appropriate video input on the television.
1Press [ STANDBY/ON].
➜Setup screen appears.
2Follow the on-screen instructions and make the settings with
[, ] and [OK].
➜“On-screen Language” and “TV Aspect” (]19) are set.
• You can perform this setup anytime by
selecting “Easy Setting” in the Setup
menu. (]19)
• You can also change these settings
individually. (]19)
• If this unit is connected to a Panasonic TV
(VIERA) supporting HDAVI Control 2 or
HDAVI Control 3 via an HDMI cable,
then the “On-screen Language” and “TV
Aspect” setting information on the TV are
captured from the TV.
Tips
PLAYBACK
11 En
English
Some discs permit a variety of interactive functions in addition to the ordinary playback operation.
The Pop-up menu is a special feature available with some BD-Video discs. This menu may vary with discs. For the operating method, refer to the
instructions for the disc.
Secondary video can be played from a disc compatible with the picture-in-picture function.
For the playback method, refer to the instructions for the disc.
DIFFERENT KINDS OF PLAYBACK FOR BD-VIDEO
Showing Pop-up menu
1Press [POP-UP MENU].
2Press [ , , , ] to select the item and press
[OK].
Pop-up menu also appears by pressing [OPTION] and
selecting “Pop-up Menu”.
To exit the screen
• Press [POP-UP MENU].
•The Final Standard Profile [“Picture-in-picture”, “Virtual Package” (]below), etc.] is a new playback function of BD-Video. Contents of playback and
the operating method may vary with the disc. For details, refer to the instructions for the disc.
Playing secondary video (picture-in-picture) and secondary audio
To turn on/off secondary video
Press [PIP].
➜Secondary video is played.
• “PiP ON” is displayed.
• Press the button to turn it ON and OFF.
To turn on/off audio with the secondary video
Press [SECONDARY AUDIO].
➜The secondary audio is played.
• “Secondary Audio ON” is displayed.
• Press the button to turn it ON and OFF.
Notes
• Only the primary video is played during search/ slow-
motion or frame-by-frame.
• When “BD-Video Secondary Audio” in “Digital
Audio Output” is set to “Off”, secondary audio will
not be played even if [SECONDARY AUDIO] is
pressed. Please check that “BD-Video Secondary
Audio” is set to “On” (]20).
Virtual package
For a disc compatible with the virtual package (]29), data is copied to other media
(]29, Local storage) from the disc to use the different functions while playing the data.
For this unit, data is copied to an SD card.
The methods for copy and playback and the required available capacity on the card may
vary with the disc. For details, refer to the instructions for the disc.
To use the above functions, it is recommended that you format the card on this unit.
Format the card using the following procedures. BD-Video data, such as secondary video
recorded on the card, can also be erased with the following procedures.
■Formatting SD cards/Deleting data
1Insert an SD card (]12).
2Press [FUNCTIONS].
3Press [ , ] to select “To Others” and press [OK].
4Press [ , ] to select “Card Management” and press [OK].
5Press [ , ] to select “BD-Video Data Erase” or
“Format SD Card” and press [OK].
6Press [ , ] to select “Yes” and press [OK].
7Press [ , ] to select “Start” and press [OK].
Notes
• If the SD card is removed from this unit when using
data that was copied with the virtual package function,
disc playback stops.
• Images and audio may freeze momentarily during
playback.
• Data cannot be copied in the following cases.
– The card is protected.
– Available capacity on the card is too small. Delete
unnecessary data or use a new card.
• When the function fails to work properly, even if the
data is copied, format the card again with this unit. (In
this case, all data will be erased.)
If an SD card with files in different formats is used,
images and audio may not play back properly. It is
recommended that you use an SD card with no data or an
SD card formatted on this unit.
Note
It is impossible to restore data after formatting the card or
erasing the data. Once a card is formatted, all data
including those recorded on the PC is erased as well,
even if the data were protected with other equipment.
Confirm whether the card can be formatted.
Previous Next
e.g., Tips
Secondary video
Primary video
Free space 300 MB
SD card
Format this SD Card.
OK
RETURN
BD-Video Data Erase
Format SD Card
Card Management No. of Files 6
Tip
PLAYBACK
12 En
You can play still pictures recorded onto a BD-RE, DVD-RAM, CD-R/RW and an SD card.
CHAPTER PLAYBACK
1Insert a disc (]9).
2While “Title View” screen is displayed
Press [ , ] to select the title and press [OPTION].
3Press [ , ] to select “Chapter View” and press [OK].
4Press [ , ] to select the chapter and press [OK].
PLAYING STILL PICTURES
1Insert a disc (]9) or an SD card (]right).
• If a disc or an SD card containing data in different file formats
is inserted, the file selection menu may be displayed.
SD card:
Press [ , ] to select “Picture (JPEG)” and press [OK].
CD-R/RW:
Press [ , ] to select “JPEG” and press [OK].
2Press [ , , , ] to select the item and press [OK].
3Press [ , , , ] to select the still picture and press [OK].
• Insert the SD card into the SD card slot.
– Press on the centre of the card until it
clicks into place.
Removing the card
Press on the centre of the card and pull it
straight out.
• Press [ , ] to display the previous or
next still picture.
• Press [ , ] to show other pages.
To return to the previous screen
Press [RETURN].
To exit the screen
Press [TOP MENU/DIRECT
NAVIGATOR].
CD-R/RW
Discs containing data in different file formats.
To switch from the MP3 menu to JPEG
menu, perform steps below.
1Press [FUNCTIONS].
2Press [ , ] to select “Menu” and press
[OK].
3Press [ , ] to select “JPEG” and press
[OK].
Note
Small-sized still pictures are displayed with a
frame.
Properties
To picture
Chapter View
To display the title properties
(recording date, etc.)
To select the chapter
Playing still pictures (]below)
e.g.,
Select an action or press RETURN.
OK
RETURN
OPTION
SD Card
Picture (JPEG)
HD Movie (AVCHD)
e.g.,
BD-RE, DVD-RAM
• “Album View” screen is displayed
• When the “Title View” screen is
displayed, press the [B] button to switch
to the “Album View” screen.
CD-R/RW, SD card
• “Picture View” screen is displayed
➜Go to step 3
2008 9 12
OPTION
Video Picture
OK
RETURN Video Picture
DIRECT NAVIGATOR
DVD-RAM(VR)
Album View
106_DVD Total 13
Total 8
Previous Next
Press [OK] to go to Picture View
Slideshow
Page 02/02
BA
e.g.,
CD(JPEG)
OPTION
Play
RETURN
Picture View
dog_jpg
Page 01/01
Folders can be selected from OPTION.
DIRECT NAVIGATOR
005
009
006
002 003
007
001
008
004
e.g.,
Video Picture
OPTION
Picture View
Play
RETURN
2008 9 12
DIRECT NAVIGATOR
DVD-RAM(VR)
Page 001/001
0008
00040001
0005
0009
0006 0007
0002 0003
e.g.,
Inserting a card
Insert the card label up with the
cut-off corner on the right.
Tips
PLAYBACK
14 En
You can play generally available music CD or MP3 files recorded onto a CD-R/RW.
Some functions of this unit can be operated from the FUNCTIONS menu.
PLAYING MUSIC
1Insert a disc. (]9)
• If a disc containing data in different file formats is inserted,
the file selection menu may be displayed. Press [ , ] to
select “MP3” and press [OK].
2Press [ , ] to select the track and press [OK].
➜Play starts on the selected track.
• Discs containing data in different file
formats.
• To switch from the JPEG menu to MP3
menu, perform steps below.
1Press [FUNCTIONS].
2Press [ , ] to select “Menu” and press
[OK].
3Press [ , ] to select “MP3” and press
[OK].
• You can use search and skip functions.
(]10)
• When the “Screen Saver Function” is set to
“On” (]21), the screen switches to
Screen Saver mode if there is no operation
for 10 minutes after starting playback.
(Playback continues.)
Playing a track in another folder
1While the “Music list” is displayed
Press [OPTION], press [ , ] to select “Select Folder” and press [OK].
2Press [ , ] to select a folder and press [OK].
The “Music list” for the folder appears.
Note
You cannot select folders that contain no
compatible tracks.
To return to the previous screen
Press [RETURN].
Playing music continuously even after turning off power to the television
When the unit is connected to a Panasonic TV (VIERA) that supports HDAVI Control 2 or HDAVI
Control 3 and a receiver supports VIERA Link, the unit is turned off if the power to the television is
turned off, since “Power off link” (]16) operates.
The following operations make it possible to keep the power of the unit ON and to play music
continuously.
1While playing music
Press [OPTION].
2Press [ , ] to select “TV Power” and press [OK].
Notes
• Sound may be discontinued for several
seconds when the power to the television is
turned off.
• If the operation mentioned left is executed
while audio is output from the television,
the sound may not be output from the
receiver. It is recommended to set the
receiver beforehand so that audio will be
output from the receiver.
SHOWING FUNCTIONS MENU
1Press [FUNCTIONS].
• Items to be displayed may vary with the media.
2Press [ , ] to select the item and press [OK].
• Top Menu
•Menu
• Playback
• SD card Switches to the SD drive.
• BD/DVD/CD Switches to the disc drive.
• To Others “Setup” (]19)
“Card Management” (]11)
“Playlists”:
You can play playlists created on DVD-VR.
Press [ , , , ] to select the playlist and press [OK].
CD
Select an action or press RETURN.
OK
RETURN
OPTION
JPEG
MP3
0.09 4.30
CD
No 4min30sec
3min41sec
4min30sec
3min11sec
5min 2sec
Play
RETURN
Music list
DIRECT NAVIGATOR
Track1
5 Tracks / Total Play Time 20min54sec
Track Name Play Time
Track1
Track2
Track3
Track4
Track5
01
02
03
04
05
“ ” indicates the track currently playing.
e.g.,
Tips
CD(MP3)
OK
RETURN
DIRECT NAVIGATOR
Select Folder
F 7/25
MP3 music
001 My favorite
002 Brazilian pops
003 Chinese pops
004 Czech pops
005 Hungarian pops
006 Liner notes
007 Japanese pops
008 Mexican pops
009 Philippine pops
010 Swedish pops
011 Momoko
012 Standard number
013 Piano solo
014 Vocal
Selected folder No. /Total folders
If the folder has no track, “– –” is displayed as folder
number.
Tip
OK
RETURN
OPTION
Menu
BD Player
DVD-Video
Top Menu
FUNCTION MENU
SD CARD
To Others
e.g.,
SETTINGS
17 En
English
Some items may be changed only on the disc specific menu. (]9, 11)
SETTINGS
CHANGING SETTINGS WITH THE ON-SCREEN MENU
On-screen menu operations
1Press [ON SCREEN].
2Press [ , ] to select the menu and
press [ ].
3Press [ , ] to select the item and
press [ ].
4Press [ , ] to select the setting.
Note
Depending on the condition of the unit
(playing, stopped, etc.) and disc contents,
there may be some items that you cannot
select or change.
Some items can be changed by pressing
[OK].
To exit the on-screen menu
Press [ON SCREEN].
What you can change with the on-screen menu
Menus Items Settings and details
Disc Signal Type
• Primary Video
Video: The video recording method appears. (]below, Video recording method)
Soundtrack: Select the type of audio or language. (]below, Language, Audio attribute)
• Secondary Video
Video: Select on/off of images.
The video recording method appears. (]below, Video recording method)
Soundtrack: Select on/off of audio and the language. (]below, Language, Audio attribute)
Video
The video recording method appears. (]below, Video recording method)
Soundtrack
Select the type of audio or language. (]below, Language, Audio attribute)
The audio attributes appear. (]below, Audio attribute)
Subtitle
Turn the subtitle on/off and select the language. (]below, Language)
(Only discs that contain subtitle on/off information)
Turn the subtitle on/off.
Subtitle Style
Select the subtitle style.
Audio channel
(]10, Changing audio during play)
Angle
Select the number of the angle.
Video recording method
MPEG-2 This is a standard for compressing and decompressing colour motion pictures efficiently. This compression method is used for DVDs, etc.
MPEG-4 AVC
VC-1
These are standards for compressing and decompressing colour motion pictures more efficiently than MPEG-2 and used for Blu-ray Discs,
etc.
Play
Subtitle
Subtitle Style
Off Main
- -
1ENG
Disc
Signal Type
Angle
Sound
e.g., BD-Video
Menus Items Settings
Tip
Language
ENG: English
FRA: French
DEU: German
ITA: Italian
ESP: Spanish
NLD: Dutch
SVE: Swedish
NOR: Norwegian
DAN: Danish
POR: Portuguese
RUS: Russian
JPN: Japanese
CHI: Chinese
KOR: Korean
MAL: Malay
VIE: Vietnamese
THA: Thai
POL: Polish
CES: Czech
SLK: Slovak
HUN: Hungarian
FIN: Finnish
*: Others
Audio attribute
LPCM/q Digital/q Digital+/
q TrueHD/DTS/DTS-HD/MPEG
Signal type
ch (channel) Number of channels
k (kHz) Sampling frequency
b (bit) Number of bits
SETTINGS
19 En
English
Change the unit’s settings if necessary. The settings remain intact even if you switch the unit to standby.
Underlined items are the factory presets.
■“General”
■“Disc”
■“Picture”
CHANGING THE UNIT’S SETTINGS
Setup menu operations
1While stopped
Press [SETUP].
2Press [ , ] to select the menu and press [OK].
3Press [ , ] to select the item and press [OK].
If there are any other items, repeat these steps.
4Press [ , , , ] to select the option and press [OK].
Note
There may be differences in operation
methods. If this happens, follow the on-
screen instructions for the operation.
To return to the previous screen
Press [RETURN].
To exit the screen
Press [SETUP].
Summary of settings
Easy Setting
You can execute basic settings (On-screen Language, TV Aspect).
•Yes •No
Default Settings
This returns all values in the Setup menu and the on-screen menu, except for
“On-screen Language”, “DVD-Video Ratings” and “BD-Video Ratings” to the default
settings.
•Yes •No
DVD-Video Ratings
Set a ratings level to limit
DVD-Video play.
Follow the on-screen instructions. Enter a 4-digit
password with the numbered buttons when the password
screen is shown. It will be the common password for
both “DVD-Video Ratings” and “BD-Video Ratings”.
• Do not forget your password.
•8 No Limit: All DVD-Video can be played.
• 1 to 7: Prohibits play of DVD-Video with corresponding ratings recorded
on them.
• 0 Lock All: Prohibits play of all DVD-Video.
• Unlock Player • Change Password
• Change Level • Temporary Unlock
BD-Video Ratings
Set an age limit of BD-
Video play.
• No Limit: All BD-Video can be played.
• 0 to 254 year(s): Prohibits play of BD-Video with corresponding ratings
recorded on them.
• Unlock Player • Change Password
• Change Level • Temporary Unlock
Soundtrack Preference Choose the language for audio, subtitle and disc menus.
• Some discs start in a certain language despite any
changes you make here.
• When the selected language is not available on the
disc, the default language is played.
There are discs where you can only switch the
language from the menu screen. (]9, 11)
• Enter a code (]28) with the numbered buttons when
you select “Other ****”.
• English • German • French
• Italian • Spanish • Dutch
• Original: The original language of each disc will be selected.
• Other ****
Subtitle Preference • Automatic:
If the language selected for “Soundtrack Preference” is not available, subtitles of
that language will automatically appear if available on that disc.
• English • German • French • Italian
• Spanish • Dutch • Other ****
Menu Preference • English • German • French • Italian
• Spanish • Dutch • Other ****
Still Mode
Select the type of picture shown when you pause playback (]29, Frames and fields).
• Automatic
• Field: Select if jittering occurs when “Automatic” is selected. (The picture is
coarser.)
• Frame: Select if small text or fine patterns cannot be seen clearly when
“Automatic” is selected. (The picture is clearer and finer.)
Seamless Play
Select the play mode between playlist chapter segments and partially deleted titles.
•On
: The chapters in playlists are played seamlessly. This does not work
while searching or when there are several audio types included on the
playlist. Additionally, the positioning of chapter segments may change
slightly.
• Off: The points where chapters in playlists change are played accurately,
but the picture may freeze for a moment.
NTSC Contents Output
Select PAL60 or NTSC output when playing NTSC discs.
•NTSC
: NTSC discs are played as NTSC.
• PAL60: Select if picture is not displayed correctly when “NTSC” is selected.
Disc
Display
TV / Device Connection
RETURN
OK
Setup
General
Sound
Tips
SETTINGS
20 En
■“Sound”
Note
Regarding Audio Output Formats when selecting “User” from “Priority setting”
Refer to the following table for audio output.
• DTS-HD means DTS-HD High Resolution Audio or DTS-HD Master Audio in the following table.
• “The original format” means it will be output in the audio formats of the disc.
• When Secondary Audio is On, the audio output will be changed according to the setting of Dolby D/Dolby D+/Dolby TrueHD.
When the setting of Dolby D/Dolby D+/Dolby True HD is Bitstream, the audio output as Dolby Digital.
When the setting of Dolby D/Dolby D+/Dolby True HD is PCM, the audio output as PCM.
• When playing BD-Video without secondary audio or clicking sound, the audio is output as the same format as if “BD-Video Secondary Audio” was set to “Off.”
• The settings emphasized in bold letters are recommended to output the high specification audio of Dolby Digital Plus, Dolby TrueHD, DTS-HD High
Resolution Audio and DTS-HD Master Audio as the original format.
Dynamic Range Compression
(Dolby Digital, Dolby Digital Plus and Dolby
TrueHD only)
Change the dynamic range (]29) for late night viewing.
•On •Off
Digital Audio Output
•Press [OK] to show the following settings.
Priority setting
• Select priority items for “Digital Audio Output”.
• Secondary Audio:
“BD-Video Secondary Audio” is set to “On”, and “Digital Audio Output” is fixed to “PCM”.
• Audio Quality:
“Digital Audio Output” is set to “Bitstream”, and “BD-Video Secondary Audio” is
fixed to “Off”.
– If the connected equipment can only decode Dolby Digital and DTS, Dolby Digital
Plus, Dolby TrueHD, and DTS-HD will be output as Dolby Digital or DTS.
– If the connected equipment can only decode one of either Dolby Digital and DTS,
please select “User” and set whichever cannot be decoded to “PCM”.
•User:
Items in “Digital Audio Output” can be set individually. However, these have
restrictions, as set out in Regarding “User” setting of “Priority setting” below.
Dolby D/Dolby D+/Dolby TrueHD Notes
• Not making the proper settings
may result in noise.
• If the unit is connected with the
HDMI AV OUT terminal, the
specifications of the connected
equipment take preference over
this unit and audio selected in
these items may not be output
(e.g., when a television is
connected, the HDMI audio
output of this unit is limited to
down-mixed 2ch.)
• Bitstream:
When “Bitstream” is selected, audio is output as bitstreams from either the HDMI
AV OUT or DIGITAL AUDIO OUT terminal. Select “Bitstream” when the
connected equipment can decode the respective audio format. (The logo shown on
the left is displayed on the equipment.)
•PCM
:
When “PCM” is selected, these audio formats are output as PCM 5.1ch from the
HDMI AV OUT and PCM 2ch from DIGITAL AUDIO OUT terminal.
Select “PCM” when the connected equipment cannot decode the respective audio
format. (The logo shown on the left is not displayed on the equipment.)
DTS/DTS-HD
MPEG Audio • Bitstream: When connected to equipment with a built-in MPEG decoder.
•PCM
: When connected to equipment without a built-in MPEG decoder.
BD-Video Secondary Audio
Turn on/off the clicking sound on the menu and audio with secondary video in
picture-in-picture mode. (]11)
•On
: The primary audio and secondary audio are mixed and output. The sampling
frequency is converted to 48 kHz.
• Off: The clicking sound on the menu and secondary audio are not output.
PCM Down Conversion
Select how to output audio with a sampling frequency of 96 kHz.
• Signals are converted to 48 kHz despite the settings across in the following cases:
– when the signals have a sampling frequency of over 96 kHz
– when the disc has copy protection
– when “BD-Video Secondary Audio” is set to “On”
• On: Signals are converted to 48 kHz. (Choose when the connected equipment
cannot process signals with sampling frequency of 96 kHz.)
•Off
: Signals are output as 96 kHz. (Choose when the connected equipment can
process signals with sampling frequency of 96 kHz.)
This unit BD-video Audio formats are output as :
Setting of “Digital Audio Output” With or without
secondary audio/
clicking sound
HDMI AV OUT DIGITAL AUDIO OUT
(COAXIAL and OPTICAL)
(Audio format of
playback disc) Bitstream j PCM BD-Video
Secondary Audio
On j Off
Dolby D/Dolby D+/
Dolby True HD
Bitstream j PCM
Dolby D/Dolby
D+/Dolby True
HD
Bitstream On With Dolby Digital Dolby Digital
Without The original format Dolby Digital
Off With or Without The original format Dolby Digital
PCM On or Off With or Without 5.1ch PCM 2ch PCM
DTS/DTS-HD Bitstream On Bitstream With Dolby Digital Dolby Digital
Without The original format DTS
PCM With 5.1ch PCM 2ch PCM
Without The original format DTS
Off Bitstream or PCM With or Without The original format DTS
PCM On Bitstream With Dolby Digital Dolby Digital
Without 5.1ch PCM 2ch PCM
PCM With or Without 5.1ch PCM 2ch PCM
Off Bitstream or PCM With or Without 5.1ch PCM 2ch PCM
MPEG Bitstream On Bitstream With Dolby Digital Dolby Digital
Without The original format MPEG
PCM With 5.1ch PCM 2ch PCM
Without The original format MPEG
Off Bitstream or PCM With or Without The original format MPEG
PCM On Bitstream With Dolby Digital Dolby Digital
Without 5.1ch PCM 2ch PCM
PCM With or Without 5.1ch PCM 2ch PCM
Off Bitstream or PCM With or Without 5.1ch PCM 2ch PCM
REFERENCE
23 En
English
■Setup Page
■Disc
■SD card
REFERENCE
FREQUENTLY ASKED QUESTIONS
What do I need to play multi channel surround
sound?
• Connect the appropriate amplifier/receiver to the HDMI terminal, the DIGITAL AUDIO
OUT terminal (OPTICAL, COAXIAL), or the 5.1ch AUDIO OUT terminal on this unit.
5, 6
How do I set this unit to play 7.1ch surround
sound?
• After connecting this unit to an amplifier/receiver compatible with Dolby Digital Plus,
Dolby TrueHD, DTS-HD and 7.1ch LPCM using an HDMI cable, set the items in the Setup
menu as follows.
– “Priority setting”: “Audio Quality”
– “Speaker” “Multi-Channel”
20, 22
Can headphones and speakers be directly
connected to this unit?
• You cannot directly connect them to this unit. Connect through the amplifier/receiver, etc. 5, 6
My television has S VIDEO IN terminal,
COMPONENT VIDEO IN terminals and HDMI
IN terminal.
Which should I connect with?
• The different levels of picture quality input are listed below in order from highest to lowest.
HDMI IN➝COMPONENT VIDEO IN➝S VIDEO IN➝VIDEO IN. However, it will take
longer for the picture output to start up when this unit is connected with the HDMI IN
terminal.
–
Can I play BD-Video and DVD-Video bought in
another country?
• You cannot play:
– BD-Video discs that do not include region code “B”.
– DVD-Video discs that do not include region number “2” or “ALL”.
Refer to the cover of this owner’s manual for more information about your region code
and number.
Refer to the disc’s jacket for more information.
iii
Can BD-Video/DVD-Video that does not have a
region code/number be played?
• The region management information for BD-Video/DVD-Video indicates that the disc
conforms to industry standards. You cannot play discs that do not conform to industry
standards or do not have a region code or number.
–
Please tell me about disc compatibility with this
unit.
• This unit plays BD-Video, DVD-Video, CD, BD-RE (BD-RE Recording Format/JPEG),
BD-R (BD-R Recording Format), DVD-RAM (DVD Video Recording format/AVCHD
format/JPEG), DVD-R/RW (DVD-Video format, DVD Video Recording format and
AVCHD format), DVD-R DL (DVD-Video format, DVD Video Recording format and
AVCHD format), DVD+R, DVD+RW and DVD+R DL.
• This unit also plays CD-R/RW discs which have been recorded in one of the following
standards: CD-DA, MP3 and still pictures (JPEG). Close the session after recording.
• You cannot write to a disc with this unit.
2
2, 15
–
What kinds of operations are available on the SD
card slot on this unit?
• The following operations are available.
– Playback JPEG data recorded with a digital camera etc.
– Playback AVCHD motion pictures recorded with High Definition Camcorder
– If a BD-Video disc supporting this function is used, it is possible to copy secondary video
recorded on the disc to the card and play it back together with the images on the disc.
(Virtual package)
–
–
11
What kinds of cards can be used? • SD Memory Cards (from 8 MB to 2 GB), SDHC Memory Cards (from 4 GB to 16 GB),
miniSD Cards*, and microSD Cards* can be used.
* A miniSD Card and a microSD Card must be used in the attached adaptor.
• To play the virtual package, it is recommended that you use a card that supports SD
Speed Class Rating Class 2 and has 256 MB or more free space.
3
–
REFERENCE
24 En
Before requesting service, make the following checks.
The following do not indicate a problem with this unit:
• Regular disc rotating sounds.
• Image disturbance during search.
■To reset this unit Page
■Power
■Operation
■Displays
TROUBLESHOOTING GUIDE
To restore the unit if it freezes due to one
of the safety devices being activated
• Press and hold [STANDBY/ON] on the main unit for 3 seconds. (The settings remain
unchanged.)
–
To return all settings other than some
settings to the factory preset
• Select “Yes” in “Default Settings” in the Setup menu.
This returns all values in the Setup menu and the on-screen menu, except for “On-screen
Language”, “DVD-Video Ratings” and “BD-Video Ratings” to the default settings.
19
To return to the factory preset (No
setting)
• Reset the unit as follows:
1Press [STANDBY/ON] on the unit to turn off the unit.
2Press and hold [ ], [ OPEN/CLOSE] and [ ] on the unit at the same time for
more than 5 seconds until “HELLO” is displayed on the unit.
3The power is turned on and then turned off automatically.
–
No power. • Insert the power cable securely into a known active household mains socket. 4, 5
The unit switches to standby mode. • One of the unit’s safety devices is activated. Press [STANDBY/ON] on the main unit to turn
the unit on.
–
The remote control doesn’t work
properly.
• The batteries are depleted. Replace them with new ones.
• You are not pointing the remote control at the main unit’s remote control signal sensor
during operation.
• Coloured glass may obstruct the signal reception/transmission.
• Don’t place the signal sensor in direct sunlight or in areas that may be subject to sunlight
exposure.
3
3
–
–
The unit is on but cannot be operated. • Confirm the correct drive is selected.
• Some operations may be prohibited by the disc.
• The unit is hot (“U59” appears on the display). Wait for “U59” to disappear.
• One of the unit’s safety devices may have been activated.
Reset the unit as follows:
1Press [STANDBY/ON] on the main unit to switch the unit to standby.
If the unit doesn’t switch to standby, press and hold [STANDBY/ON] on the main unit
for about 3 seconds. The unit is forcibly switched to standby. Alternatively, disconnect the
power cable, wait one minute, then reconnect it.
2Press [STANDBY/ON] on the main unit to switch it on. If the unit still cannot be operated,
consult the dealer.
• Condensation has formed: Wait 1 to 2 hours for it to evaporate.
9
–
27
–
–
Play fails to start even when [ ] (PLAY)
is pressed.
Play starts but then stops immediately.
• Insert the disc correctly with the label facing up.
• The disc is dirty.
• You tried to play a blank disc or unplayable disc on this unit.
9
27
2, 3
Cannot eject disc. • The unit may have a problem. While the unit is off, press and hold [ ] and [ ] on
the main unit at the same time for about 5 seconds. Remove the disc and consult the dealer.
–
Startup is slow.
When the unit is turned on, audio and
video output takes a long time.
It takes time before play starts.
• Startup takes time in the following situations.
– Immediately after a power failure or the power cable is connected.
– When the unit is connected with an HDMI cable.
–
Cannot set “On” in “BD-Video 24p
Output”.
• Only when the unit is connected to the HDMI terminal of a TV supporting 24p can you
select “On”. In some cases where the unit is connected to a TV via an amplifier/receiver
through the HDMI terminals, you may not be able to select “On”. In this case, connect the
unit to a TV through the HDMI terminal and connect it to the amplifier/receiver through any
terminal other than HDMI.
21
The display is dim. • Change “FL Display” in the Setup menu. 21
The elapsed time displayed is actually
less than the playtime.
• The displayed play time is converted from the number of frames at 29.97 frames (equal to
0.999 seconds) to one second. There will be a slight difference between the time displayed
and the actual elapsed time (e.g., actual one-hour elapsed time may display as approximately
59 minutes 56 seconds).
–
REFERENCE
25 En
English
■TV screen and video Page
■Sound
■HDMI connections
The images from this unit do not appear
on the television.
Picture is distorted.
• Make sure that the television is connected to the VIDEO OUT terminal, S VIDEO OUT
terminal, COMPONENT VIDEO OUT terminals or HDMI AV OUT terminal on this unit.
• Make sure that the television’s input setting (e.g., AV1) is correct.
• An incorrect resolution is selected in “Component Resolution”, when the television is
connected to COMPONENT VIDEO OUT terminals. While stopped, press and hold [ ]
and [ ] (PLAY) on the main unit at the same time for more than 5 seconds to cancel this
setting. Set the item again.
• If “BD-Video 24p Output” is turned “On” when the unit is connected to a TV through any
terminal other than HDMI, images may not display properly. In this case, turn “BD-Video
24p Output” to “Off”.
• The unit and television are using different video systems. While stopped, keep pressing [ ]
and [ OPEN/CLOSE] on the main unit for 5 or more seconds. The system switches from
PAL to NTSC or vice versa.
• The system used on the disc doesn’t match your television.
– PAL discs cannot be correctly viewed on an NTSC television.
– This unit can convert NTSC signals to PAL60 for viewing on a PAL television (“NTSC
Contents Output” in the “Picture”).
4, 5
–
22
21
–
–
19
The screen changes automatically. • When the “Screen Saver Function” in the Setup menu is set to “On”, the display may return
to the screen saver mode automatically if there is no operation for 10 minutes or more.
21
Video is not output in high definition. • High definition video cannot be output through the VIDEO OUT or S VIDEO OUT
terminals.
• Confirm that the “HDMI Video Mode”, “HDMI Video Format”, and “Component
Resolution” in the Setup menu are set properly.
• The video output resolution is restricted to “576p/480p” when DVD-Video and BD-Video
discs recorded at a rate of 50 frames per second is output from the COMPONENT VIDEO
OUT terminals.
–
21, 22
–
Status messages do not appear. • Select “Automatic” in “On-screen Messages” in the Setup menu. 21
The 4:3 aspect ratio picture expands left
and right.
Screen size is wrong.
• Use the television to change the aspect. Refer to your television’s operating instructions.
• When using a component video cable, set “Progressive” to “Off”. If the situation is not
restored after that, set “TV Aspect” to “4:3 Pan & Scan”.
–
18, 21
There is a lot of after-image when playing
video.
• Turn “3D NR” or “Integrated NR” off if it is on. 18
When playing DVD-Video using
progressive output, one part of the
picture momentarily appears to be
doubled up.
• Set “Progressive” of “Picture” menu on the on-screen menu to “Off”. This problem is caused
by the editing method or material used on DVD-Video, but should be corrected if you use
interlace output.
• When the unit is connected using HDMI terminal, refer to “HDMI connections” (]below).
18
–
There is no apparent change in picture
quality when adjusted with the “Picture”
menu in the on-screen menu.
• The effect is less perceivable with some types of video. –
The masked-off area is masked in gray. • If the “Screen Saver Function” in the Setup menu is set to “Off”, the masked-off area is
displayed in black.
21
No sound.
Low volume.
Distorted sound.
Cannot hear the desired audio type.
• Check the connections and the “Digital Audio Output” settings. Check the input mode on the
amplifier/receiver if you have connected one.
•Press [AUDIO] to select the audio.
• Match the speaker settings with the connected equipment. Change multi channel speaker
settings by selecting “Multi Channel” in “Speaker”.
• When “BD-Video Secondary Audio” is set to “Off”, Dolby Digital Plus, Dolby TrueHD and
DTS-HD are output from the DIGITAL AUDIO OUT terminal as Dolby Digital or DTS
Digital Surround bitstream.
4-6, 20
10
22
–
Cannot switch audio. • There are discs for which audio cannot be changed because of how the disc was created.
• When connecting an amplifier/receiver using a coaxial cable, optical digital audio cable or
an HDMI cable, you cannot switch the audio if “Digital Audio Output” is set to “Bitstream”.
Set “Digital Audio Output” to “PCM” or connect using audio cables.
–
5, 6, 20
The images from this unit do not appear
on the television.
Picture is distorted.
• Press [ ] and [ ] (PLAY) simultaneously on the unit for more than 5 seconds to shift the
mode to one more compatible with HDMI equipment. However, Dolby Digital Plus, Dolby
TrueHD, and DTS-HD audio are not output in bitstream. To output the bitstream, select
“Default Settings” to restore the factory presets and make proper settings.
• To output video from a device connected with an HDMI cable, set “HDMI Video Mode” to
“On” in the Setup menu.
• Picture may not be seen when more than 4 devices are connected with HDMI cables.
Reduce the number of connected devices.
• When “BD-Video 24p Output” is set to “On”, HDMI authentication takes place where 24 p
images switch to other images, and a black screen is displayed.
19
21
–
21
The 4:3 aspect ratio picture expands left
and right.
Screen size is wrong.
• Change “TV Aspect” type to “16:9”. 21
MISE EN MARCHE
6 Fr
Avec 5.1ch AUDIO OUT
Une fois branché à un amplificateur/récepteur compatible à l’aide des bornes de 5.1ch AUDIO OUT, vous pouvez apprécier le son
d’ambiance.
Avec DIGITAL AUDIO OUT
Vous pouvez apprécier le son d’ambiance, une fois l’appareil branché à l’ampliticateur/récepteur, à l’aide de la borne COAXIAL ou
OPTICAL.
Branchement d’un amplificateur/récepteur (à l’exception du branchement HDMI)
Remarques
PARAMÈTRES NÉCESSAIRES
• « Enceinte »: « Multicanaux » (]22)
• Le disque à 7.1 canaux est associée au
canal audio 5.1.
Lorsqu’il est branché à un téléviseur
compatible HDMI (]4, )
• « Sortie audio HDMI »: « Non » (]21)
(Sinon, le son provient du téléviseur.)
• Selon la manière dont le disque a été
enregistré, il est possible que le son ne soit
pas reproduit correctement sur le nombre
de canaux souhaité
Remarques
PARAMÈTRES NÉCESSAIRES
• « Sortie audio numérique »: selon
l’amplificateur/récepteur branché (]20)
Lorsqu’il est branché à un téléviseur
compatible HDMI (]4, )
• « Sortie audio HDMI »: « Non » (]21)
(Sinon, le son ne peut ne pas être reproduit
avec les paramètres souhaités.)
Haut-parleurs multicanaux
Branchez les
câbles audio aux
bornes
correspondant aux
haut-parleurs que
vous avez
connectés.
Amplificateur/récepteur
doté d’une entrée audio à
5.1 canaux
Branchement de câbles
Haut-parleur avant (L/R)
Haut-parleur surround (L/R)
Enceinte centrale
Caisson de grave
Partie arrière de l’appareil
Câble coaxial
Avec la borne COAXIAL
Partie arrière de
l’appareil
Amplificateur/récepteur
avec un décodeur intégré
ou une combinaison
décodeur-amplificateur/
récepteur
Câble audio numérique
et optique
Avec la borne OPTICAL
Partie arrière de
l’appareil
Amplificateur/récepteur
avec un décodeur intégré
ou une combinaison
décodeur-amplificateur/
récepteur
