Thank you for purchasing this

SB18BRGB Sound Bar

Please read through these instructions carefully so you will know

how to operate your model properly.

After you have nished reading the instructions, keep this document

in a safe place for future reference.

Before You Start

Read and understand all instructions before you use your product. If you do not follow the instructions

in this manual, we are not responsible for injury or damage resulting from improper handling. This will

also void the warranty.

Important Safety Precautions

• Be sure to observe the following guidelines:

- Do not increase speaker volume so high that you cannot hear what is around you.

- Use caution or temporarily discontinue use in potentially hazardous situations.

• Do not make any adjustment on the product when driving or in other situations where distractions can be

hazardous. Responsible and safe driving is your primary responsibility when operating a vehicle.

• Start volume at a low setting then gradually increase the volume until you can hear it comfortably, without

sound distortion and ear discomfort.

• In the event of smoke, strange noise or odor emitted from the product or any other abnormal operational

signs appearing on the product, disconnect the product from the power supply. Discontinue use and contact

your dealer or our technical support. Using the product in this condition may result in permanent damage to

the system.

• Servicing must only be carried out by a technician. Contact our technical support for any service questions.

Installation Precautions

• WARNING: Always consult a professional installer.

• Installation must be performed by a professional. Contact our technical support for any installation questions.

• Observe the safety and operating instructions of the devices which are connected to the product.

• Only use attachments/accessories specied by the manufacturer for installation.

• Do not modify this product, as this affects the safety of the product and creates a risk of injury.

• Before installation, disconnect the negative terminal of the vehicle battery to prevent damage to the product,

re, and/or possible injury.

Care for Your Product

• DO NOT clean the product in hot weather (e.g. hot sunlight).

• DO NOT use abrasive or highly alkaline cleaner on the product.

• DO NOT use gasoline, acetone, carbon tetrachloride or other aggressive chemical solutions on the product.

• DO NOT scrape the product with razor blade or other sharp instrument.

• DO NOT use a pressure washer or pressurized water.

• This product is water resistant. However, never submerge the product in water.

Mounting

Mounting on ATV or UTV

Always consult an expert when in doubt about the installation.

You must work with an assistant to mount the sound bar due to its heavy weight.

Use only the supplied accessory for mounting. Using other mounting methods may void the warranty.

To ensure security of the mounted sound bar, always check the mounting conditions (e.g. clamp

fastening) of the sound bar before each vehicle ride.

Spring washer

Upper clamp

Lower clamp

Rubber strip

Mounting bar

(Ø 1.75” − 2”)

Lower clamp

Sliding block

Power Connection

Option 1: Using Power Port

If your vehicle has a 12V power port, directly connect the sound bar to your vehicle for power connection.

1. Insert the 12V power port plug of the sound bar into your vehicle power port.

Note: To avoid battery drain, it is recommended to unplug after each use (if the port power is not switched

off with the ignition key).

To your vehicle power port

12V power port plug with 10A fuse

Option 2: Using Power Port Plug Adapter

If your vehicle dose not have a 12V power port, use the supplied power port plug adapter for connection to

your vehicle battery.

Important:

• To avoid short circuits and any resulting damage to the sound bar, the negative terminal of the vehicle battery

must be disconnected rst.

1. Connect the black/ground wire of the power port plug adapter to the vehicle’s metal frame or to the negative

battery terminal. Fasten the ground wire with a bolt/screw on the metal surface. Make sure the metal surface

is clean with no paint, rust or dirt.

2. Connect the red wire of the power port plug adapter to the positive battery terminal.

If needed, use extension wires of 12-14 gauge for connection to the battery. Remember to install a 15A

in-line fuse (not included) and an on/off switch (not included). An on/off switch is not needed if you

unplug the sound bar after each use or if the vehicle power port is turned off with the ignition key. Refer to

the illustration.

3. Insert the power port plug of the sound bar into the power port plug adapter.

THIS PACKAGE CONTAINS

1x SB18BRGB sound bar

Mounting kit + 1x Hex wrench

1x 12V power port plug adapter

1x Remote control + 1x Keychain

1x User manual + 1x Warranty card

IMPORTANT

Please enter below the Serial No. which is located on the exterior of the product. Retain this

information for future reference.

Model

Serial No.

Date of Purchase

Getting to Know Your Sound Bar

Introduction

The product is a Bluetooth speaker system which is ideal for installation in an ATV (All Terrain Vehicle) or UTV

(Utility Vehicle). You can stream audio from a mobile phone to this product via Bluetooth. You can also play music

les stored in a USB ash drive, and music from an external device (e.g. a mobile phone or MP3 player) can be

played via 3.5mm AUX input jack.

You can output audio from the sound bar to an external amplier or powered speakers through RCA output.

The product is integrated with LED lights which can be controlled using the supplied lighting controller.

This product is shockproof and water resistant. This product is designed to be operated with 10-16 VDC negative

ground vehicle power supply only. Never connect this product to any other voltage supply (e.g. 24 VDC).

Product Overview

1 2 3

1 3.5mm audio input jack

2 RCA audio output sockets

3 USB port

4 12V power port plug with 10A fuse

5 Power button (hold down to power on or off);

Mode button

6 Volume buttons

7 Start/pause/resume play button

8 Track selection buttons

9 Remote sensor (aim the remote control directly

at the sensor when using the remote controller)

10 Display

4 5 Power Connection

Vehicle’s metal frame

Black wire

12V power port plug with 10A fuse

Power port plug adapter

Red wire

Battery Fuse

(not included) 1

On/Off switch

(not included)

Option 3: Direct connection to vehicle battery

Important:

• To avoid short circuits and any resulting damage to the sound bar, the negative terminal of the vehicle battery

must be disconnected rst.

1. Remove the plug from the supplied power port plug cable.

2. Connect the power port plug’s negative wire to the vehicle’s metal frame or to the negative battery terminal,

and the power port plug’s positive wire to the positive battery terminal.

• To prevent electrical damage, you must install 1) a 15A fuse (not included) and 2) an on/off switch (not

included) to be in line with the power wire which connects to the positive battery terminal.

• Fasten the ground wire with a bolt/screw on the metal surface. Make sure the metal surface is clean with no

paint, rust or dirt.

Turn on or off

• Press and hold on the sound bar (or on the remote control) to turn on or off the sound bar. When turned

on, the power LED indicator illuminates on the power port plug.

• on the remote control to turn on or off the LED lights.Press briey

To avoid battery drain when the sound bar is not used, disconnect the sound bar from the battery by

unplugging the power port plug or using the inline on/off switch (not included).

1. Correctly orient the supplied sliding block, and attach

it to the bottom side of the lower clamp using the

supplied hex wrench. Make sure not to tighten the

block for subsequent slide into the groove.

2. Find the groove on the top panel of the sound bar.

Correctly orient the sliding block and slide it into the

groove from either end of the groove. Then slide the

clamp to a proper position and tighten it with the hex

wrench.

3. Attach the supplied rubber strips over the clamp and

cage bar for secure clamping and abrasion prevention.

4. Tighten the upper clamp to the lower clamp with the

hex wrench. Make sure the supplied spring washers

are used to provide more stable bolt fastening against

vibration.

Repeat the steps above to secure the sound bar with

the other clamp assembly.

SB18BRGB

0823
