GS38K

Date 9/19/16

Customer CKTL

Model No. GS38K

Description IB

Job No. 16CF010

Reference No. IB-16/395

Revision No. 0

Color 1C+1C(Black)

Open Size 552mm(W) X 214mm(H)

Folded Size 92mm(W) X 214mm(H)

Material 80gsm Artpaper

Prepared by Carlos Ho

Approved by Jimmy Ng / Anna Son

Vendor MILLPLAN

Supplier

CONTINENTAL CONAIR LIMITED

CHINA CREATIVE DEPARTMENT

INSTRUCTION

B O O K L E T

사 용 설 명 서

HANDHELD FABRIC STEAMER

터보 익스트림 스팀 핸디 다리미

CONAIR HANDHELD FABRIC STEAMER

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, especially when children are

present, basic safety precautions should always be followed,

including the following:

READ ALL INSTRUCTIONS BEFORE USING

KEEP AWAY FROM WATER

SAFETY PRECAUTIONS

WARNING: The polyethylene bags over the product

or its packaging may be dangerous. Keep these bags

out of the reach of babies and children.

Never use them in cribs, children’s beds, pushchairs

or playpens. The thin ﬁlm may cling to the nose and

mouth and prevent breathing. A bag is not a toy.

WARNING: Do not use this appliance near bathtubs,

showers, basins or other vessels containing water.

1. If you are using the unit in a bathroom, unplug it after you have

ﬁnished using it. Using the unit close to a source of water can,

in fact, be dangerous, even if the unit is switched off. To ensure

additional protection, have installed in your bathroom a residual

current device (RCD) with a nominal trip current no higher than 30

mA. Ask your electrical ﬁtter for advice.

2. Never immerse the unit in water or any other liquid.

3. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed persons in

order to avoid a hazard.

4. Do not use the unit if it has fallen or if it appears to be damaged.

5. Do not leave the unit unattended when it is plugged in or switched

on.

6. Unplug the unit immediately if you have problems when using it.

7. Do not use any accessories other than those recommended by

manufacturer.

8. Unplug the unit after each use and before ﬁlling or cleaning it.

9. This unit is not intended for use by people (including children) with

reduced physical, sensory or mental capabilities, or by persons

who lack experience or knowledge, unless they are supervised

or have been given instructions beforehand on the use of the

unit by a person responsible for their safety. Children should be

supervised to make sure they do not treat the unit like a toy.

10. Allow the unit to cool before storing.

11. To prevent damage to the cord, do not wrap it around the unit and

ensure it is stored without twisting or folding it.

12. When emitting steam, this appliance may cause burns if it is used

too close to the skin or eyes, or if it is used incorrectly. To reduce

the risk of contact with hot water emitting from the steam vents,

test appliance before use by holding it away from the body.

13. Do not steam garments while on a person.

14. Burns could occur from touching hot metal parts, hot water or

steam. Use care when you turn steam appliance upside down.

15. Do not operate steamer without correctly ﬁlling the water container.

Only use clean cold water for ﬁlling this appliance. In hard water

areas, we recommend the use of distilled water.

16. Use of an extension cord is not recommended. If an extension

cord is absolutely necessary, a 13-ampererated cord should be

used. Cord rated for less amperage may overheat. Care should

be taken to arrange the cord so that it cannot be pulled or tripped

over.

17. Never yank cord to disconnect from outlet, instead, grasp plug

and pull to disconnect.

18. Use with caution when carrying steamer as it contains hot water.

NOTE: Before using the garment steamer for the ﬁrst time, it is

recommended to operate the steamer for approximately 5 minutes,

unplug the unit and allow it to cool. Empty container and reﬁll

before actually using.

HOUSEHOLD USE ONLY

FILLING INSTRUCTIONS

1. Make sure the unit is unplugged.

2. Stand the unit on a table and grasp with one hand.

3. With other hand, move the release switch up toward the steam

head nozzle.

4. Pull the reservoir out, away from the steamer body.

5. The rubber inlet cover is located on the

top of the water reservoir.

6. Open the inlet cover and ﬁll the reservoir

with distilled water (which can be found

in grocery stores). We recommend that

you use distilled water only as this will

prevent mineral deposits in the boiler

that can reduce performance or clog

the water system.

7. Close the inlet cover and return the

reservoir to its place, making sure that

it snaps in place and is secure.

GET TO KNOW YOUR STEAMER

Power button(I/O button)

Red Turbo switch

Water reservoir

release switch

3-In-1

Attachments

Silicone band

Low Temperature

Guide

Bristle Brush

Blue power light

and READY light

Power cord

Built-in creaser with

garment guides

Easy-to-fill

water reservoir

BRUSH ATTACHMENT

With the garment steamer off and cool, snap the silicone band

attachment over the steam head ensuring it is ﬁrmly afﬁxed. At this

point the silicone band can be used or you can choose to afﬁx either

the Bristle Brush or Low Temperature Guide inserts into the channel

on the top of the silicone band attachment as desired. Note, only

one function of the 3-In-1 attachment can be used at a time.

CAUTION: Use extreme care when changing the attachments

after the unit has been in use as the steam head will continue to

be hot.

ACCESSORIES:

1. Silicone Band: Pulls fabric taut for easier steaming.

2. Low Temperature Guide: Helps protect delicate fabric.

3. Bristle Brush: Opens ﬁbers for better steam penetration.

OPERATING THE STEAMER

1. Fill water reservoir with distilled water. We recommend that you

use distilled water only, as this will prevent mineral deposits in the

boiler that can reduce performance or clog the water system.

2. Plug the unit into the electrical outlet and press the on/ off button

on the back of the steamer.

3. The blue READY light will illuminate and begin blinking. Allow 40

seconds for the unit to warm up. The appliance is ready to use

when the READY light stops blinking and remains solid. Note:

Before ﬁrst use or when the unit has not been used for a long

period of time, it will be necessary to prime (i.e., ﬁll with water) the

internal tank while the steamer prepares to steam. You may hear a

small tapping noise during the heat-up process; this is normal.

4. Your steamer has 2 options for steam, regular Steam and

Turbo. Use the Steam setting (blue button) for delicate fabrics or

freshening lightly wrinkled garments. Use the Turbo setting (red

button) for thicker fabrics and heavily wrinkled articles.

5. Pointing the steam jets away from you, and anyone else in the

room, press either the blue Steam button

or the red Turbo button to release steam.

Always have steam facing away from you or

anyone in the room.

6. When ﬁrst using the device, test on an old

cloth, as there may be sediment left from the

manufacturing process or transportation.

7. To stop the ﬂow of steam, depress the

button(s) that you have turned on, either the

red, blue, or both.

8. Turn off and Unplug the device when it is not in use.

USING CREASER

This garment steamer has a built-in creaser on the top of the unit. To

use, slide garment under the clip and align edge with the pattern as

marked on the creaser. Press the Steam button and steam will issue

from the port on the top of the unit. Slide the

steamer along the edge of the garment to create

a sharp crease. Note: Steam will continue to emit

from the steam slot on the front of the unit during

creaser use!

STEAMING TIPS

1. First test unit on an inconspicuous area of

the item to be steamed using the regular

Steam setting to ensure fabric can tolerate

the effects of steam. If there is no evidence

of damage, you can proceed to use the

steamer on that item.

2. To prepare your fabric for steaming, brush it with the brush

attachment. This will loosen the ﬁbers and allow better steam

penetration.

3. Hang your garment or fabric. Note: Avoid using metal clothes

hangers, if possible.

4. Pass the steam jets just above the fabric where the wrinkles are. It

may take a few passes to remove the wrinkles completely.

5. For heavier fabrics or severely wrinkled fabrics, you may position

the steamer head directly on the fabric for a few seconds to

remove wrinkles. Be cautious when working with delicate fabrics.

6. After use, turn unit off by depressing the button(s) that you have

turned on, either the red, blue, or both. Empty any remaining

water from the tank to avoid leakage. With dry hands, unplug

your garment steamer from the outlet. BE SURE TO PRESS THE

BUTTONS “O” PRIOR TO UNPLUGGING THE UNIT.

7. CAUTION: If hanging garment on a door while steaming, be

careful not to damage the door with steam.

8. When steaming, always keep the unit in motion. Do not

continuously hold steamer over an area or touch steamer jets

directly to fabric for more than a few seconds as this can cause

damage, including shrinkage, melting, or color shift on certain

types of material.

9. In the case of heavier, durable fabrics such as wool coats or

bedding, the Turbo setting and slower passes with the steamer

may be necessary to achieve desired results. As always, start

by testing on an inconspicuous area of the item to be steamed

using the regular Steam setting to ensure fabric can tolerate the

effects of steam, and adjust your technique as needed to obtain

the results desired.

NOTE: Test fabric for color fastness in an inconspicuous spot. Drape linens,

towels, handkerchiefs and napkins over a rod or place onto a towel rack.

TO MAKE CREASES OR PLEATS

1. Hang garment.

2. Fold fabric where crease or pleat is desired. Hold fold in place

while applying steam directly to fold.

TO STEAM TIES

1. Hang tie on hanger.

2. Apply steam directly to tie.

TO STEAM SHOULDERS AND SLEEVES

1. Hang garment, preferably on a padded hanger.

2. Fill out shoulders or sleeves with folded towel.

3. Apply steam to garment.

DECALCIFICATION

If the appliance begins to produce steam more slowly than usual,

or stops producing steam and then starts again, you may need

to decalcify your steamer. Decalciﬁcation refers to removing the

calcium deposits that form over time on the metal parts of the

steamer. For best performance from the Conair Garment Steamer,

decalcify the unit from time to time. The frequency depends upon

the hardness of your water and how often you use the steamer.

To decalcify, use a solution of 1/3 white vinegar and 2/3 water in

the water reservoir.

Plug the unit into electrical outlet. Wait the ready light goes on then

activate the steam trigger, and run until all amount has steamed.

Release the steam trigger, unplug from electrical outlet, and allow

to sit for 30 minutes.

Repeat the above procedure as many times as necessary until a

normal steam rate returns, usually 2 to 3 times. With each repeated

cycle, use a fresh solution of vinegar and water. Run one cycle of

fresh, cold water through the unit at the completion of decalciﬁcation

before using the unit again to steam garments.

Note: Minerals in water will vary in different areas. To insure

continued operation of the steamer, never store without cleaning

and removing excess water from the reservoir and water container.

ONE YEAR LIMITED WARRANTY

This Conair Appliance is guaranteed for consumer use for one

year. This guarantee is no longer valid in case of alteration or

repair by any unauthorized persons and only covers defects

under normal use from the date of purchase. If your product

does not perform satisfactorily because of defects in materials

or manufacture, it will be repaired or replaced under Consumer

Dispute Settlement Regulation of Fair Trade Commission.

GS38K IB-16/395

Folding method:

12 pages (6 x 2)

Produkt Specifikationer

Mærke:	Conair
Kategori:	Damprenser
Model:	GS38K

Har du brug for hjælp?

Hvis du har brug for hjælp til Conair GS38K stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Damprenser Conair Manualer

Conair ExtremeSteam GSC24PK Manual

1 Oktober 2024

Conair CompleteSteam GS2W Manual

1 Oktober 2024

Conair ExtremeSteam GS23X Manual

6 September 2024

Conair ExtremeSteam GS23 Manual

21 August 2024

21 August 2024

21 August 2024

21 August 2024

21 August 2024

Conair ExtremeSteam GS75 Manual

21 August 2024

Conair GS33 Manual

21 August 2024

Damprenser Manualer

Nyeste Damprenser Manualer

Cecotec Conga Rockstar 3700 Glass Manual

18 November 2024

Kogan KAMOP151STMA Manual

18 November 2024

Vulcan C24GA10 Manual

7 November 2024

Vulcan C24ET10-LWE Manual

7 November 2024

Ulsonix USX-ST1 Manual

2 November 2024

Ulsonix USX-ST4 Manual

2 November 2024

SilverCrest SFAV 3.7 A1 Manual

15 Oktober 2024

Quigg GT-GSF-02 Manual

14 Oktober 2024

Hoover SteamJet Compact SCM 1600 Manual

13 Oktober 2024

Bissell Big Green Machine Manual

9 Oktober 2024
