Mikrotik GPeR Manual

Mikrotik Telefon GPeR

Læs nedenfor 📖 manual på dansk for Mikrotik GPeR (3 sider) i kategorien Telefon. Denne guide var nyttig for 58 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Download PDF

Side 1/3

GPeR

Connecting

• Connect your desired network cable with power to the POE in Ethernet port, and extend it trough POE out.

• Connect cable to next GPeR unit or to the other device.

Powering

The device accepts power from the Ethernet port:

•Ethernet port accepts passive Power or 802.3af/at PoE DC ⎓24 - 57 V.

The power consumption under maximum load can reach 2 W.

Connecting to a POE Adapter:

1. Connect the Ethernet cable from the device to the POE port of the POE adapter.

2. Connect an Ethernet cable from your LAN to the LAN port of the POE adapter, please mind arrows for data

and power flow.

3. Connect the power cord to the adapter, and then plug the power cord into a power outlet.

Mounting

The device is designed for use indoors, the IP rating scale for this device is IPX0.

• It is possible to attach the device to a wall, using the provided screw hole on the mounting bracket of the

unit.

Recommended using Cat5/6 cable.

Mounting and configuration of this device should be done by a qualified person.

Expansion slots and ports

• Two Gigabit Ethernet ports.

Accessories

Package includes the following accessories that come with the device:

• Mounting bracket with screw and dowel.

Specifications

For more information about this product, specification and pictures please visit our web page:

https://mikrotik.com/product/gper

MikroTik mobile app

Use the MikroTik smartphone app to configure your router in the field, or to apply the most basic initial settings for

your MikroTik home access point.

See mikrotik.com/products for the latest version of this document. Document #50230 Modified on: 26.JUN.2019

Produkt Specifikationer

Mærke:	Mikrotik
Kategori:	Telefon
Model:	GPeR
Produktfarve:	Sort
Ethernet LAN-porte (RJ-45):	2
Ethernet LAN:	Ja
Driftstemperatur (T-T):	-40 - 70 °C
Hurtig start guide:	Ja
Strøm over Ethernet (PoE):	Ja
DC-udgangsstrøm:	2 A
Tænd/sluk-knap:	Ja
Radiofrekvens (RF) interval:	- Mhz
