Supermicro A2SAN-E Manual
Supermicro
Bundkort
A2SAN-E
Læs nedenfor 📖 manual på dansk for Supermicro A2SAN-E (1 sider) i kategorien Bundkort. Denne guide var nyttig for 6 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/1
SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• ftp://ftp.supermicro.com/CDR_Images/CDR-A1-UP/Drivers & Utilities:
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2017 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
A2SAN-H/-E/-L and X11SAN
Q R G R . 1.00uick efeRence uide ev
• One (1) Supermicro Motherboard
• One (1) SATA Data Cable
• One (1) SATA Power Cable
• One (1) USB 2.0 Cable
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
F or your system to work properly please download appropriate,
drivers images user s manual From the links below/ / ' :
MNL-1935-QRG-100
• One (1) Audio Cable
• One (1) COM Port Cable
• One (1) Quick Reference
Guide
JMD1
JPW1
JMP1
JLPC80
JSMBUS1
J5
JPT1
1
3
2
4
2
10
Connectors
SO-DIMM Memory Installation
Jumpers, Connectors & LED Indicators Memory SupportMotherboard Layouts and Mechanical Drawings
Jumpers
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide. Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
Front Control Panel (JF1)
CPU Support
54
3
7
26
1
X11SAN and X11SAN-WOHS support Intel® Pentium N4200.
A2SAN-H/-E and A2SAN-H/-E-WOHS support Intel® Atom E3940.
A2SAN-L and A2SAN-L-WOHS support Intel® Atom E3930.
The A2SAN-H/-E/-L and X11SAN motherboard supports up to 8GB of
DDR3L 1867MHz Non-ECC SO-DIMM in one memory slot.
Power Button
1
Reset Button
2
3.3V
3.3V Stby
Reset
PWR
HDD LED
Power LED
Ground
Ground
7 8
Jumper Description Jumper Setting (Default *)
JLCDPWR1 LVDS Panel VCC Power 3.3V/5V/12V Pins 1-3* (3.3V), Pins 3-5 (5V), Pins 3-4 (12V)
JPF1 Power Force On Pins 1-2* (Power Force On)
Pins 2-3 (PWR BTN Power On)
JPME2 Manufacturing Mode Pins 1-2* (Normal)
Pins 2-3 (Manufacturing Mode)
JPT1 TPM Enable/Disable JPT1_1N2* (Enable)
JPT1_3N4 (Disable)
Connector Description
AUDIO FP Front Panel Audio Header (Mic In/Line Out)
BT1 Battery Connector
(To Clear CMOS, remove the battery, short pins 1-2 and install the battery.)
FAN1 System Fan Header
I-SATA1 Intel PCH SATA 3.0 Port
JCOM1: COM1/COM2
JCOM2: COM3/COM4
Serial COM Ports
(JCOM1 supports RS232/RS422/RS485, JCOM2 supports RS232)
JD1 Speaker Header (Pins 1-4)
JF1 Front Control Panel Header
JGP1 8-bit General Purpose I/O Header
JHDMI1 Back Panel HDMI Port
JIP1 LVDS Inverter Power Header
JLAN1: LAN1, LAN2 LAN (RJ45) Ports
JLPC80 Port 80 Connector (for debugging only)
JMD1 M.2 Slot (B-KEY) (supports PCIe Gen2 X1, SATA or USB 2.0))
JMP1 Mini PCI-E Slot (supports PCIe Gen2 X1 or USB 2.0)
JPH1 SATA Power Connector (for one HDD system)
JPW1 4-pin 12V-Standby R/A Type Power Connector
JSMBUS1 System Management Bus Header
LVDS1 Dual Channel 48-bit LVDS Connector
USB4/5 Back Panel Universal Serial Bus (USB) 3.0 Ports
USB0/1, USB2/3 USB 2.0 Headers
USB6 USB 3.1 Type C Header
VGA Back Panel VGA Port
LED Description Status
LED1 Power LED (for debugging only) Solid Green: S0 mode
Solid Red: S3/S4/S5 modes
# #Denition Description
1 5LAN1 USB6 (3.1)
2 6LAN2 HDMI Port
3 7USB5 (3.0) VGA Port
4 USB4 (3.0)
= mounting hole
DESIGNED IN USA
A2SAN-L
REV:1.02
BAR CODE
JGP1
BT1
JCOM1: COM1/COM2JCOM2: COM3/COM4
CPU1
FAN1
JPME2
JPF1
LAN2
JD1
LVDS1
I-SATA1
JHDMI1
LED1
JLCDPWR1 JF1
JIP1
JPH1
LAN1
JLAN1
AUDIO FP
USB6(3.1)
X
X
X
USB2/3
USB0/1
VGA
JF1 ONPWR
RST
X
HDD LED
PWR LED
SPEAKER
JD1:
USB4/5(3.0)
LED Indicators
Align
1. Position the SO-DIMM module's bottom key so it aligns with the receptive
point on the slot.
2. Insert the SO-DIMM module vertically at about a 45 degree angle. Press
down until the module locks into place. The side clips will automatically
secure the SO-DIMM module, locking it into place.
Insert this end rst
Locking Clip
SO-DIMM Removal
1. Push the side clips at the end of slot to release the SO-DIMM module. Pull
the SO-DIMM module up to remove it from the slot.
Back Panel I/O Connectors
Back Panel I/O With Heatsink (A2SAN-H/-L)
Back Panel I/O Without Heatsink
(A2SAN-H/E/L-WOHS, X11SAN-WOHS)
Bottom Layout and Mechanical Drawing
Top Layout and Mechanical Drawing
Back Panel I/O With Heatsink (X11SAN)
Back Panel I/O With Heatsink (A2SAN-E)
