SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• http://www.supermicro.com/wftpDrivers & Utilities:
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2019 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
X11DP -n/X11DP -nti i
Q r g r . 1.1uICk eferenCe uIDe ev
b
• One (1) Supermicro Motherboard
• Two (2) SATA Cables
• One (1)
Mini SAS to 4 SATA cable
• One (1) I/O Shield
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to work ProPerly Please DownloaD aPProPrIate,
DrIvers Images user s manual from the lInks below/ / ' :
MNL-1773-QRG-11b
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPME2 Manufacturing Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset to System)
Connector Description
BT1 Onboard CMOS battery socket
COM1/COM2 Back panel COM port/COM header for front access
FAN1-6, FANA/FANB System cooling fan headers (FAN1-FAN6, FAN A, FAN B)
IPMI_LAN Dedicated IPMI_LAN port
I-SATA0~3, I-SATA4~7 SATA 3.0 connection header supported by the Intel PCH
JD1 Speaker/buzzer header (used in conjunction with an external
speaker/buzzer) (optional)
JF1 Front Panel Control header
JIPMB1 4-pin BMC External I2C header (for an IPMI-supported card)
JL1
Chassis intrusion header ( : Please connect a cable from the Note
Chassis Intrusion header at JL1 to the chassis to receive an alert
via IPMI.)
JM2_1 PCI-E M.2 slot
JNVI2C1 NVMe I2C header
JNVME1/JNVME2 NVMe Slot1/NVMe Slot2
JPI2C1 Power Supply SMBbus I2C header
JPWR1/JPWR2 8-pin Power Supply connectors
JPWR3 24-pin ATX main power supply connector
JRK1 Intel VROC RAID Key for NVMe SSD
JSTBY1 Standby power header
JTPM1 Port 80 connector for Trusted Platform Module (TPM)
LAN1/LAN2 Gigabit LAN/10G LAN Ethernet ports on the backpanel
S-SATA0-3 S-SATA 3.0 connection header
S-SATA4/S-SATA5 Powered S-SATA Ports SuperDOM (Disk On Module) devices
SLOT1/SLOT3 PCI-Express 3.0 X8 Slots supported by CPU1
SLOT2 PCI-Express 3.0 X16 Slot supported by CPU1
SLOT4/SLOT5/SLOT6 PCI-Express 3.0 X16 Slots supported by CPU2
T-SGPIO3 General Purpose Serial I/O port
UID Unit Identier (UID) switch
USB0/1 & USB4/5 Backpanel USB 2.0 ports (USB0/1) & USB 3.0 ports (USB4/5)
USB2/3 Front Accessible USB 2.0 header for USB 2/3
USB6 Type A USB 3.0 Header
USB7/8 Front Accessible USB 3.0 header for USB7/8
VGA VGA Port
LED Description Status
LE1 UID (Unit Identier) LED BMC Heartbeat LED
LE2 Onboard Power LED On: Onboard power on
LE3 PCI-E M.2 Activity LED On: PCI-E M.2 active
LEDM1 BMC Heartbeat LED Blinking Green: BMC normal
#1 #2
#3
#4
Small Guiding Post
Large Guiding PostOval D
T30 Torx Driver
Use a torque
of 12 lbf·in
Oval C
Printed Triangle
Mounting the Processor Heatsink Module
into the CPU socket (on the motherboard)
T e screws in theighten th
sequence of 1, 2, 3, 4 (top 3 quarter view)
Jumpers and Connectors
Back Panel I/O Connectors
Memory Support
Motherboard Layout and Features
Installing Processor/Heatsink Module
Front Control Panel (JF1)
CPU Support
CPU/Heatsink Installation
This motherboard supports dual Intel Xeon Scalable-SP or
2nd Gen Intel Xeon Scalable-SP series processors with support of UltraPath
Interconnect (UPI) of up to 10.4 GT/s.
This motherboard supports up to 4TB of 3DS LRDIMM, LRDIMM, 3DS RDIMM,
and RDIMM DDR4 (288-pin) ECC 2933/2666/2400/2133 MHz memory modules in
16 slots. ( . Up to 5TB is supported with (L)RDIMM and DCPMM populated Notes: 1
in a balanced memory conguration. 2. 2933 MHz memory is supported by
2nd Gen Intel Xeon Scalable-SP(82xx/62xx) series processors only. . Unbalanced 3
memory conguration decreases memory performance and is not recommended.)
87
6
15
4
3
2
10
9
Back Panel I/O Ports
No. Description No. Description
1. COM1 6. USB 1 (USB 2.0)
2. 7.USB 4 (USB 3.0) GLAN1 (X11DPi-N), 10G_LAN1 (X11DPi-NT)
3. 8.USB 5 (USB 3.0) GLAN2 (X11DPi-N), 10G_LAN2 (X11DPi-NT)
4. 9. VGAIPMI LAN
5. 10.USB 0 (USB 2.0) Unit Identier Switch (UID)
A
A
B
B
C
C
Pin 1
Align CPU Pin 1
CPU (Upside Down)
w/CPU LGA Lands up
CPU/Heatsink Package
(Upside Down)
Align Notch C of the CPU
and Notch C of the Processor Clip
Align Notch B of the CPU
and Notch B of the Processor Clip
Heatsink
(Upside Down)
C
D
dc
a
b
A
B
f
Triangle on the CPU
Triangle on the
Processor Clip
Power
UID LED
NIC1 Active L
ED
HDD LED
PWR LED
3.3V Stby
3.3V Stby
Ground
19
X
Ground
X
3.3V Stby
20
1 2
Ground
Power Fail LED
NIC2 Active LED
NMI
3.3V
3.3V
OH/Fan Fail LED
Reset
Notes: 1. Please refer to Chapter 2 of the user's manual for detailed instructions of CPU/Heatsink and
memory Installation. 2. 10GbE LAN ports are for X11DPi-NT only. 3. Please refer to our website at www.
supermicro.com for CPU/Memory support updates. 4. All graphics shown in this quick reference guide
are for illustration only. Your components may or may not look the same as the graphics shown in this
quick reference guide.
1
43
2
CPU1
BIOS
LICENSE
MAC CODE BAR CODE
JTPM1
JPCIE3
JPCIE1
JPCIE6
JPCIE4
JPCIE2
JPCIE5
JRK1
JPWR3
JPI2C1 JPWR2JPWR1
JF1
JL1
JSTBY1
BT1
T-SGPIO3
JWD1
JPME2JIPMB1
LE1
LEDM1
JBT1
FAN4
FAN3
FAN1FAN2
FAN5
FANA
FANB
VGA
LE2
P1-DIMMA2
P1-DIMMA1
P1-DIMMB1
P1-DIMMC1
P1-DIMMF1
P1-DIMME1
P1-DIMMD1
P1-DIMMD2
P2-DIMMB1
P2-DIMMA1
P2-DIMMA2
P2-DIMMD2
P2-DIMMD1
P2-DIMME1
P2-DIMMF1
BMC LAN CTRL
FAN6
BIOS
JP4
JM2_1 JP2
LE3
A
JD1
M.2-PCH
A
C
JNVI2C2
PWRI2C
M.2-P
S-SATA5
S-SATA4
(3.0)USB 7/8
(3.0)
USB 6
USB 2/3
COM2
CPU1 SLOT1 PCI-E 3.0 X8
CPU1 SLOT2 PCI-E 3.0 X16
CPU1 SLOT3 PCI-E 3.0 X8
CPU2 SLOT4 PCI-E 3.0 X16
CPU2 SLOT5 PCI-E 3.0 X16
CPU2 SLOT6 PCI-E 3.0 X16
UID
LAN2 LAN1
USB0/1
(2.0)
USB4/5 (3.0)
IPMI_LAN
COM1
S-SATA 0~3
I-SATA 4~7
I-SATA 0~3
CPU2
(2.0)
Rev. 2.00
PCH
P2-DIMMC1
X11DPi-N(T)
JNVME1JNVME2
JNVI2C1
USB2/3
JWD1
T-SGPIO3
SLOT4 SLOT6
SLOT5
SLOT3
SLOT2
SLOT1
LEDM1
COM2
JIPMB1
JPME2
USB6
USB7/8
JM2_1
JTPM1
JD1
JRK1
LE3
S-SATA0-3
I-SATA0-3
I-SATA4-7
FANB
FANA
JL1
BT1
FAN6
LE1
UID VGA
FAN5
LAN2
LAN1
USB0/1
IPMI LAN
USB4/5 COM1
JPI2C1
JPWR1
JPWR2
JPWR3
JF1
LE2
P2-DIMMD2
P2-DIMMD1
P2-DIMME1
P2-DIMMF1
P1-DIMMA2
P1-DIMMA1
P1-DIMMB1
P1-DIMMC1
P2-DIMMC1
P2-DIMMB1
P2-DIMMA1
P2-DIMMA2
FAN3
FAN4
JSTBY1
S-SATA4
S-SATA5
JNVI2C1 JNVME1
JNVME2
P1-DIMMD2
P1-DIMMD1
P1-DIMME1
P1-DIMMF1
FAN1
FAN2
CPU1
CPU2
= mounting hole
JBT1
PCI-E M.2 Slot Installation
A Holder B Holder Mount
C Card Holder Mount
Turn 90 degrees
to lock
Locked position
with M.2 card
Locked positionLocked position
D Plastic screw
STOP
Turn 90 degrees
to lock
A+B+C A+B+D
Press in here
B
D
A
BC
A
Rectangle hole
on MB
Copyright 2017 by Super Micro Computer, Inc. All rights reserved.©
H e MB ol Lo ioncat on t h e 42
M.2 60 CCard A+B+
M.2 80 CCard A+B+
M.2 110 DCard A+B+
Memory Population Table
Memory Population Table for the X11DP Motherboard w/16 DIMM Slots Onboard
When 1 CPU is used: Memory Population Sequence
1 CPU & 1 DIMM CPU1: P1-DIMMA1
1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
1 CPU & 4 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 5 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 6 DIMM CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 7 DIMMs
(Unbalanced: not recom-
mended)
CPU1:P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 8 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-
DIMME1/P1-DIMMF1
When 2 CPUs are used: Memory Population Sequence
2 CPUs & 2 DIMMs CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 4 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
CPU2: P2-DIMMA1/P2-DIMMD1
2 CPUs & 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1
2 CPUs & 8 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 10 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 14 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMA2/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 16 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-
DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/P2-
DIMME1/P2-DIMMF1
