Supermicro X11SCQ Manual
Supermicro
Bundkort
X11SCQ
Læs nedenfor 📖 manual på dansk for Supermicro X11SCQ (1 sider) i kategorien Bundkort. Denne guide var nyttig for 4 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/1
SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: https://www.supermicro.com/wftp/driver/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2020 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
X11sCQ/-L
Q r g 1.0uICk eferenCe uIde b
• One (1) Supermicro Motherboard
• One (1) Quick Reference Guide
• One (1) I/O Shield
• Six (6) SATA Cable (Four for -L)
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to work ProPerLy PLease downLoad aPProPrIate,
drIvers Images user s manuaL from the LInks beLow/ / ' :
MNL-2110-QRG-10b
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
+
X11SCQ
REV:1.01
MAC CODE
BAR CODE
DESIGNED IN USA
BIOS
LICENSE
Intel
Q370/H310
JGP1
JSMB1
DIMMA1
DIMMB1
DIMMA2
DIMMB2
COM3/4
COM5/6
MH12
MH11
MH9
CON1
JPW2
B3
COM2
COM1
JSTBY1
JD1
FAN1
FAN3
FAN4
FAN2
JPT1
JAT1
JPME2
JWD1
JLED1
JPL2
JPAC1
JPL1
JPW1
JL1
I-SATA5I-SATA2
I-SATA4I-SATA1 I-SATA3I-SATA0
JF1
JBT1
JSD1
JTPM1
J*
SP1LED3
LED1
EDP
CPU
AUDIO FP
USB4/5
USB6/7(3.1)
SLOT4
SLOT5
SLOT6
ON
PWR XLED
OH/ FF
RST NIC 2 NIC 1 H DD
LED
USB10/11(3.1)
LED
PWR
HD AUDIO
SLOT7
UNB NON-ECC DDR4 DIMM REQUIRED
ALWAYS POPULATE BLUE SOCKET FIRST
PCI-E M.2-M1
LAN2
USB2/3
USB8/9(3.1) LAN1
HDMI/DP
DVI-D
CPU FAN
KB/MOUSE
USB0/1
J5
Jumpers and Connectors
Memory Support
Motherboard Layout and Features
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this guide. Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
= mounting hole
LED Indicators
CPU Support
The X11SCQ/-L motherboard supports an Intel® 8th/9th Generation Core™
i9/Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® series processor in an
LGA1151 socket.
Jumper Description Default Setting
JAT1 ATX/AT Mode Pins 1-2 (ATX Mode)
JBT1 CMOS Clear Open (Normal)
JPAC1 Audio Enable Pins 1-2 (Enable)
JPL1, JPL2 LAN1/LAN2 Enable/Disable Pins 1-2 (Enable)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPT1 Onboard TPM Enable/Disable
(not available on X11SCQ-L) Pins 1-2 (Enable)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
LED Description Status
LED1 Power LED Solid Green: Power On
LED3 Standby Power LED Green: Standby Power On
Connector Description
AUDIO FP Front Panel Audio Header
B3 Onboard Battery
COM1 COM1 Header
COM2 COM2 Header
COM3/4 COM3 and COM4 Headers
COM5/6 COM5 and COM6 Headers
DVI-D Digital Video Interface Port
eDP Embedded DisplayPort
FAN1 - FAN4 CPU/System Fan Headers (FAN4: CPU Fan)
HD AUDIO Rear Audio Ports
HDMI/DP High Denition Multimedia Interface/DisplayPort
I-SATA0 - I-SATA5 SATA 3.0 Ports (SATA4/5 not available on X11SCQ-L)
JD1 Speaker/Buzzer (Pins 1-4: Speaker, Pins 3-4: Buzzer)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JL1 Chassis Intrusion Header
JLED1 3-pin Power LED Indicator Header
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 8-pin CPU Power Connector (Required)
JSD1 SATA DOM Power Connector
JSMB1 System Management Bus Header
JSTBY1 5V Standby Power Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Connector
KB/MOUSE Keyboard and Mouse Connector
LAN1, LAN2 Gigabit Ethernet (RJ45) Port
M.2 M.2 M-Key PCIE3 Connector (not available on X11SCQ-L)
MH9, MH11, MH12 M.2 Mounting screws
SLOT4 PCI-E 3.0 p1-x4 Slot (not availabe on X11SCQ-L)
SLOT5 PCI-E 3.0 p1-x4 Slot (PCI-E 2.0 p1-x4 on X11SCQ-L)
CPU Installation
Pin 1
Socket Key
CPU Key
Front Control Panel
Connectors and LED Indicators
Connectors
Connector Description
SLOT6 PCI-E 3.0 p1-x1 Slot (PCI-E 2.0 p1-x1 on X11SCQ-L)
SLOT7 PCI-E 3.0 p1-x16 Slot
SP1 Speaker/Buzzer
USB0/1 Back Panel USB 2.0 Ports
USB2/3, USB4/5 Front Accessible USB 2.0 Headers
USB6/7, USB8/9 Back Panel USB 3.1 Gen 2 Ports
(USB 3.1 Gen 1 on X11SCQ-L)
USB10/11 Front Accessible USB 3.1 Gen 2 Headers
(not available on X11SCQ-L)
Power Button
OH/Fan Fail LED
NIC1 Activity LED
Reset Button
HDD LED
PWR LED
Reset
PWR
3.3V Stby
Ground
15
3.3V Stby
16
1 2
Ground
NIC2 Activity LED
X
+3.3V
+3.3V Stby
X
+3.3V
Apply thermal
grease
Press down
and turn
clockwise
Heatsink Installation
The X11SCQ motherboard supports up to 128GB of DDR4 Non-ECC UDIMM in
four slots. Insert the desired number of DIMMs, starting with DIMMA2, DIMMB2,
then DIMMA1, DIMMB1.
The X11SCQ-L motherboard supports up to 64GB of DDR4 Non-ECC UDIMM
in two slots. Insert the desired number of DIMMs, starting with DIMMA2 then
DIMMB2.
For optimal performance, use memory modules of the same type and speed.
Connectors
Jumpers
Back Panel I/O Connectors
# # # #Description Description Description Description
1. KB/Mouse 6. HDMI 16.11. USB9 (3.1) Line In
2. USB1 7. LAN1 12. 17.USB8 (3.1) Line Out
3. USB0 8. 13. 18.USB7 (3.1) CEN/LFE Out Mic In
4. DVI-D 9. 14.USB6 (3.1) Surround Out
5. DP 10. LAN2 15. SPDIF Out
1
9
8
7
6
5
4
3
2
18
17
16
10 13
12
14
15
11
