Side 1/1
SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: https://www.supermicro.com/wftp/driver/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2021 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
X12ste-f
Q r g 1.0uICk eferenCe uIde a
• One Supermicro Motherboard
• One Quick Reference Guide
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to work ProPerly Please download aPProPrIate,
drIvers Images user s manual from the lInks below/ / ' :
MNL-2387-QRG 100
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
VGA
JBT1
M.2-H PCI-E 4.0 X4/S A 3.0 KEY-MAT
JBM1
JUSB3P1
USB 3/4 (3.2)
USB1/2
MH2
MH10
MH11
MH1
JPT1
JTPM1 JUSB1
USB2 (3.0)
JSD1
MH5
CPU MICRO-LP PCIe 4.0 X8
JVRM1
JPG1
JCPLD1 J3
JPME2
JPO1
JWD1
X12STE-F
REV:1.00
DESIGNED IN USA
MH9
BIOS
LICENSE
MAC CODE
BAR CODE
MH3
BT1
MH7
MH6
MH8
JVR1
SW1
JUIDB1
LED2
LEDM1
J5
DIMMA2
DIMMB1
DIMMA1
DIMMB2
CPU
PCH
I-SATA6
JKVM1
BMC
J2
J6
DIMM Memory Installation
Jumpers, Connectors, and LED Indicators Memory SupportMotherboard Layout and Features
Jumpers
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in
this guide. Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors, and LED indicators. Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
The X12STE-F motherboard supports up to 128GB of DDR4 ECC and Non-
ECC VLP UDIMM with speeds of up to 3200MHz in four memory slots.
Recommended Population (Balanced)
DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory
4GB 4GB 8GB
4GB 4GB 4GB 4GB 16GB
8GB 8GB 16GB
8GB 8GB 8GB 8GB 32GB
16GB 16GB 32GB
16GB 16GB 16GB 16GB 64GB
32GB 32GB 64GB
32GB 32GB 32GB 32GB 128GB
64GB 64GB 128GB
1. Insert DIMM modules in the following order: DIMMA2, DIMMB2, then
DIMMA1, DIMMB1. For the system to work properly, use memory mod-
ules of the same type and speed.
Jumper Description Default Setting
JBM1 IPMI Share LAN Enable/Disable Pins 1-2 Open (Enabled)
JBT1 CMOS Clear Open (Normal)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPO1 CPU Throttle When PWR_Fail Pins 2-3 (Disabled)
JPT1 Onboard TPM 2.0 Enable/Disable Pins 1-2 (Enabled)
JVRM1 VRM SMB Clock (to BMC or PCH) Pins 1-2 (BMC Normal)
JWD1 Watchdog Timer Pins 1-2 (Reset)
LED Description Status
LED2 Unit Identier LED Solid Blue: Unit Identied
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
Connector Description
BT1 Onboard Battery
I-SATA6 SATA 3.0 Port
J2 MicroLP PCIe 4.0 p1-x8 Slot for AOM-BPN-MC12SN
J5 PCIe 4.0 p1-x8 Slot
J6 M.2 PCIe 4.0 x4/SATA 3.0 Key-M (2280/22110)
JKVM1 VGA/COM1/USB Connector on the I/O Backplane
JSD1 SATA DOM Power Connector
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID Switch
JVR1 VRM I2C SMBus to Header
SW1 Power Button
USB1/2 (JKVM1) Back Panel USB 2.0 Ports via JKVM1
USB3/4 (JUSB3P1) Back Panel USB 3.2 Type C Connector
USB5 (JUSB1) USB 3.0 Type A (Debug only)
VGA VGA Port via JKVM1
CPU Installation
Pin 1
Socket Key
CPU Key
Heatsink Installation
Thermal
Grease
Screw 1 Screw 2
Screw 3
Screw 4
Mounting
Holes
Release Tabs
Notches
Press both notches
straight down into
the memory slot.
CPU Support
The X12STE-F motherboard supports the Intel® Xeon E-2300 Family and Pentium
series processor in an LGA1200 socket.
Connectors
LED Indicators
= mounting hole
