Side 1/1
3.0
Licence No. 0124
In ac cord anc e with AS/NZS 6400
Sussex Taps Pty Ltd
WATER RATING
www.waterrat ing.gov.au
The mo re
stars the mo re
water efcient
1/2" BSP Fittings
with conical Seals FLEXIBLE HOSES
CLAMP
FIXING
NUT
Hole Size
32-35mm
50mm Max.
Bench thickness
BASE
O RING
Product code
Installation guidelines
Plumber note
Suba
- The Mixer is supplied assembled, only the Fixing nut and the Clamp need to be removed.
- After removing the mentioned parts, lower the Mixer on to the mounting surface and fit the Flexible Hoses.
- In some cases the Flexible Hoses may need to be fed through from under the mounting surface and then
attached. (Tighten using appropriate spanner)
- After securing the Flexible Hoses, fit Clamp and attach the Fixing Nut from underneath.
- Before fully securing the Mixer ensure that the Base O Ring is intact and the Mixer is properly centered over the
mounting surface hole.
- The Mixer mounting surface must be completely sealed and water-tight.
- The 1/2” Fittings of the Flexible Hoses have a conical seal, ensure that the matching threads are cut square
and burr free.
- Prior to connecting the Flexible Hoses, ensure all pipework is thoroughly flushed and ensure pipework is free
of any dirt or debri.
- Isolating Stop Valves are recommended with all installations. (not supplied)
- Connect the Flexible Hoses to Hot and Cold pipework fittings, ensure the Hoses do not kink or become twisted
when tightening.
- Check all fittings and connections are secure and water-tight.
- On-site testing using higher water pressures must be conducted with the Mixer in the closed position.
(STATIC TEST)
- Under no circumstances is the Mixer to be opened when exceeding the maximum stated water pressure.
- At the completion of testing, do not relieve any high water pressure by operating the Mixer.
- Exposing the internals of the Mixer Car tridge to higher than specified water pressures will void the
manufacturers warranty.
BBM Basin mixer
BEBM85 Extended basin mixer 85mm outlet
BEBM125 Extended basin mixer 125mm outlet
BLBM Lever basin mixer
BLEBM85 Lever extended basin mixer 85mm outlet
BLEBM125 Lever extended basin mixer 125mm outlet
Basin mixer
sussextaps.com.au
Tapware is to be installed by a Licensed Plumber in accordance with AS/NZS 3500:2003
Recommended working water pressure 300-500 kpa. Maximum water temperature is 65 deg.c
Copyright © Sussex Taps.
