Xvive PX-A Manual
Læs nedenfor 📖 manual på dansk for Xvive PX-A (1 sider) i kategorien Øreprop. Denne guide var nyttig for 12 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/1
Headphones
Earphones / IEMs
VOCALIST
DRUMMER
DC Power
Click Track Kick Drum Instruments
Vocal Other Vocals Instruments
Input 3Input 2Input 1
● 3-channel mixer and headphone amplier for personal in-ear-monitoring
applications
● Ultra-compact and lightweight design
● Cat 5 cable transmits three channels of audio and 9 volts of PoE (Power
over Ethernet)
● Level control knob powers o the unit all the way counterclockwise
● DIP switches inside PX-A allow you to control how each channel is panned:
left, right, or both
● PoE/battery power switch selects either Cat 5 9V PoE power or 2x AAA
battery power
● Runs for up to 5 hours on 2 AAA batteries (not included)
● LED indicates when battery power is being used
● Sturdy beltpack clip
● Ultra-rugged impact-resistant metal chassis
● Compatible with Xvive PX-B Snake, EC25 Ethernet cable, PX-H Hub
FEATURES
PRODUCT OVERVIEW
PX-A PORTABLE 3-CHANNEL
PERSONAL MIXER
For the Xvive PX System
LISTENING TO AUDIO AT EXCESSIVE VOLUMES CAN CAUSE PERMANENT
HEARING DAMAGE. USE AS LOW A VOLUME AS POSSIBLE.
Overexposure to excessive sound levels can damage your ears, resulting in
permanent noise-induced hearing loss. Do not use earphones for a long time
and set the volume below 50%.
Xvive accepts no liability for any loss which may be su ered by any person
who relies either wholly or in part upon any description, photograph, or
statement contained herein. Technical specications, appearances and other
information are subject to change without notice.
LIMITED WARRANTY
LEGAL DISCLAIMER
For the applicable warranty terms and conditions and additional information
regarding the Xvive Limited Warranty, please email support@xvive.com.
WARNING
PX-A
APPLICATION EXAMPLES WITH PX-B AND EC25 ETHERNET CABLE
Input 1 Volume
Ethernet input
Input 2 Volume
Input 3 Volume
Stereo setup DIP switches
L switch ON = audio is sent to the left earphone
R switch ON = audio is sent to the right earphone
L and R both ON = audio is sent to left and right sides
Earphone/headphone output
Earphone/headphone volume
PoE / battery
power switch
Battery compartment
and stereo setup
DIP switches
CH1
ON ON ON
L R L R L R
CH2 CH3
CH3 CH1 CH4
CH2
T568B
Orange+
White
Orange
Green
Brown+White
Brown
Green+White
Blue
Blue+White
ETHERNET INPUT
CH 1 is input 1 XLR hot and XLR cold Blue Blue+White
, ,
CH 2 is input 3 XLR hot and XLR cold Green Green+White, ,
CH 3 is input 2 XLR hot and XLR cold Orange Orange+White, ,
CH 4 is PoE power input, Brown (+), Brown+White (-)
2nd oor, Building 12, Xicheng Industrial Area, Xixiang Town, Baoan District,
Shenzhen Guangdong China. 518101
XVIVE CUSTOMER SERVICE
Email: support@xvive.com
Or, you can nd your local distributor at www.xvive.com
SHENZHEN FZONE TECHNOLOGY CO., LTD.
SPECIFICATIONS
Input type:
Output type:
Output impedance:
Max. output:
Power input:
Battery life:
Current:
PoE power requirement:
Ethernet input for audio and power
1/8” TRS (stereo)
8-80 Ω
2x 150 mW @ 16 Ω
PoE (Power over Ethernet) or 2x AAA batteries
~5 hours
~210 mA
9V/2A center-negative (powers up to 5 PX-A units)
9V / 500mA center-negative for one PX-A unit
Power LED
PoE mode: solid on
Battery mode:
100% - 20% charged: Blue LED
20% - 10% charged: Pink LED
10% - 0% charged: Red LED
(When the LED is red, the batteries should be replaced)
料号：111081438 PX-A Manual 尺寸： 105*245MM 材质：100G书纸
Produkt Specifikationer
| Mærke: | Xvive |
| Kategori: | Øreprop |
| Model: | PX-A |
