Mikrotik CCR2004-16G-2S+PC Manual
Læs nedenfor 📖 manual på dansk for Mikrotik CCR2004-16G-2S+PC (19 sider) i kategorien Router. Denne guide var nyttig for 7 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/19
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/da/mikrotik/ccr2004-16g-2s-plus-pc/html/bg1.png)
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick GuideEN - English -Quick Guide:
This Quick Guide covers the model: CCR2004-16G-2S+PC.
This is a Network Device. You can find the product model name on the case label (ID).
Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.
https://mt.lv/um
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at https://mikrotik.com/products
Configuration manual for software in your language with additional information can be found athttps://mt.lv/help
MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants
First steps:
First steps:
First steps:
First steps:First steps:
Connect your PC to the MGMT/BOOT labeled port or the first Ethernet port;
Connect the device to a power source;
Configure the IP settings of your network card to 192.168.88.2/24;
Configuration should be made using Webfig in a web browser or the WinBox configuration tool ;https://mt.lv/winbox
Open in a web browser to start setup. If the IP address is unavailable, use Winbox and choose the "Neighbors" tab to find the device. http://192.168.88.1
Proceed to connect using the MAC address. The username is "admin", and there is no password (or, for some models, check user and wireless passwords on
the sticker);
For a manual update, visit the products page at to find your product. The required packages are accessible under the https://mikrotik.com/products
"Support&Downloads" menu;
Upload downloaded packages to the Webfig or Winbox "Files" menu and reboot the device;
By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;
Set up your router password.
Safety Information:
Safety Information:
Safety Information:
Safety Information:Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate
measures
Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.
BG - Български. Бързо ръководство
BG - Български. Бързо ръководство
BG - Български. Бързо ръководство
BG - Български. Бързо ръководствоBG - Български. Бързо ръководство:
Това бързо ръководство обхваща модела: CCR2004-16G-2S+PC.
Това е мрежово устройство. Можете да намерите името на модела на продукта на етикета на регистъра (ID).
Моля, посетете страницата с ръководството за потребителя на за пълното актуализирано ръководство за употреба.
https://mt.lv/um-bg
Или сканирайте QR кода с мобилния си телефон.
Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.
Технически спецификации, пълна ЕС декларация за съответствие, брошури и повече информация за продуктите на https://mikrotik.com
/products
Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на https://mt.lv/help-bg
Устройствата MikroTik са за професионална употреба. Ако нямате квалификация, моля, потърсете консултантhttps://mikrotik.com/consultants
Първи стъпки:
Първи стъпки:
Първи стъпки:
Първи стъпки:Първи стъпки:
This device needs to be upgraded to v7.10 or the latest software version to ensure compliance with local authority regulations!
It is the end user's responsibility to follow local country regulations. All MikroTik devices must be professionally installed.
Това устройство трябва да бъде надстроено до най-новата версия v7.10 на софтуера, за да се гарантира спазването на местните наредби!
Крайните потребители са отговорни за спазването на местните разпоредби. Всички устройства на MikroTik трябва да бъдат инсталирани
професионално.
Produkt Specifikationer
Mærke: | Mikrotik |
Kategori: | Router |
Model: | CCR2004-16G-2S+PC |
Bredde: | 272 mm |
Dybde: | 195 mm |
Højde: | 44 mm |
Produktfarve: | Hvid |
Ethernet LAN-porte (RJ-45): | 16 |
Strømforbrug (typisk): | 36 W |
Driftstemperatur (T-T): | -20 - 60 °C |
Intern hukommelse: | 4 MB |
Flashhukommelse: | 128 MB |
Ethernet-grænsefladetype: | Hurtigt ethernet |
Gennemsnitstid mellem fejl (MTBF): | 200000 t |
Antal SFP + modulslots: | 2 |
