Pairing the Blood Pressure Monitor with your Smart-

phone

To begin using Bluetooth® for the rst time, please visit the

website at http://www.rossmax.com for the initial set-up

instructions.

1. Download and install the applicable APP onto your

smartphone.

2. To bind this device with your smartphone, turn on the

device, Bluetooth® and the App of smartphone, and fol-

low set-up and binding instructions.

3. If the binding is successful, the Bluetooth® symbol ( )

will appear on the display and keep ashing during data transfer. The current measured

value will automatically be transferred to the App when the measurement is completed.

4. If the binding has failed, the Bluetooth® symbol ( ) will not appear on the display and

the current measured value will not automatically be transferred to the App. In this case,

the value is saved in the selected user memory zone. Please re-bind this device with your

smartphone and follow App instructions for Bluetooth® transfer.

APP

120mmHg

USB PC

BP Manager

1. The monitor has two memory zones (1 and 2). Each zone can store up to 60 measure-

ments.

2. To read memory values from a selected memory zone, use the User-Switching key to

select a memory zone (1 or 2) from which you want to recall values. Press the Memory

key. The rst reading displayed is the average of all morning readings from the last 7

days.

3. Continue to press the Memory key to view the average of all nighttime readings from

the last 7 days.

4. Press the Memory key again to view the average of the last 3 measurements stored in

memory, and the last previously stored measurement. Every measurement comes with

an assigned memory sequence number.

5. All readings currently saved on the device can be transferred to the App using Blue-

tooth® after successful completion of the binding process. Select the desired user

memory zone and follow App instructions, the Bluetooth® transfer starts automatically.

Data transfer will be halted while performing a measurement or operating the device.

Note: The memory bank can store up to 60 readings per memory zone. When the num-

ber of readings exceeds 60, the oldest data will be replaced with the new record.

Note: AM is dened as 4:00 AM – 11:59 AM

Note: PM is dened as 6:00 PM – 2:00 AM

1. Press the User-Switching key to select memory zone 1 or memory zone 2.

2. Press and hold the Memory key for approximately 5 seconds, then the data in the mem-

ory zone can be erased automatically.

1. Adjust the date/time/Bluetooth® in the monitor by installing or replacing batteries or

holding down the ON/OFF/START key for approximately 5 seconds under power o

mode. The display will show a blinking number showing the year.

2. Change the year by pressing the Memory key, each press will increase the number.

Press the ON/OFF/START key to conrm the entry and the screen will show a blinking

number representing the date.

3. Change the date, the hour and the minute as described in Step 2 above, using the

Memory key to change and the ON/OFF/START key to conrm the entries.

4. After adjusting the date/time, the Bluetooth® symbol ( ) and the blinking icon “ ”

will be shown on the display simultaneously. Use the Memory key to choose whether

automatic Bluetooth® data transfer is activated (Bluetooth® symbol ( )+ ) or de-

activated (Bluetooth® symbol ( )+ ) and conrm with the ON/OFF/START key.

5. Press the ON/OFF/START key again, “0” will reappear as the Blood Pressure Monitor is

ready for measurement.

Rossmax provides a free, integrated and user-friendly blood pressure management soft-

ware which can be downloaded and installed on your computer. You may purchase a spe-

cial designed USB cable in order to connect Rossmax’s blood pressure monitor and your

PC. Please visit the website at http://www.rossmax.com for proceeding the downloading

and installation process.

If any abnormality will arise during use, please check the following points.

Symptoms Check Points Correction

No display when

the ON/OFF/START

key is pressed

Have the batteries run down? Replace them with four new batteries.

Have the batteries' polarities

been positioned incorrectly? Re-insert the batteries in the correct

positions.

EE mark shown

on display or the

blood pressure

value is displayed

excessively low

(high)

Is the cuff placed correctly? Wrap the cuff properly so that it is

positioned correctly.

Did you talk or move during

measurement? Measure again. Keep arm steady dur-

ing measurement.

Did you vigorously shake the

cuff during measurement?

Note: If the unit still does not work, return it to your dealer. Under no circumstance should

you disassemble and repair the unit by yourself.

1. The unit contains high-precision assemblies. Therefore, avoid extreme temperatures, hu-

midity, and direct sunlight. Avoid dropping or strongly shocking the main unit, and pro-

tect it from dust.

2. Clean the blood pressure monitor body and the cu carefully with a slightly damp, soft

cloth. Do not press. Do not wash the cu or use chemical cleaner on it. Never use thinner,

alcohol or petrol (gasoline) as cleaner.

3. Leaky batteries can damage the unit. Remove the batteries when the unit is not used for

a long time.

4. The unit should not be operated by children so to avoid hazardous situations.

5. If the unit is stored near freezing, allow it to acclimate at room temperature before use.

6. This unit is not eld serviceable. You should not use any tool to open the device nor should

you attempt to adjust anything inside the device. If you have any problems, please contact

the store or the doctor from whom you purchased this unit or please contact Rossmax

International Ltd.

7. As a common issue for all blood pressure monitors using the oscillometric measurement

function, the device may have diculty in determining the proper blood pressure for us-

ers diagnosed with diabetes, poor circulation of blood, kidney problems, or for users suf-

fered from stroke, or for unconscious users.

8. This unit is able to detect common arrhythmia (atrial or ventricular premature beats or

atrial brillation). The ARR, AFib and PC icons are displayed after the measurement if Atrial

Fibrillation and Premature Contraction was detected during the measurement. If ARR,

AFib or PC icons are displayed, you are advised to wait for a while and take another meas-

urement. It is strongly recommended that you consult your physician if the ARR, AFib or

PC icons appear often.

9. While the given device is able to detect specic pulse arrhythmia, the measurement ac-

curacy of the blood pressure meter may be impaired with the occurrence of pulse ar-

rhythmia.

10. To stop operation at any time, press the ON/OFF/START key, and the air in the cu will be

rapidly exhausted.

11. Once the ination reaches 300 mmHg, the unit will start deating rapidly for safety rea-

sons.

12. Please note that this unit can be a home healthcare product, but it is not intended to

serve as a substitute for the advice of a physician or medical professional.

13. Do not use this device for diagnosis or treatment of any health problem or disease. Meas-

urement results are for reference only. Consult a healthcare professional for interpreta-

tion of pressure measurements. Contact your physician if you have or suspect any medi-

cal problem. Do not change your medications without the advice of your physician or

healthcare professional.

14. Electromagnetic interference: Avoid strong electrical or electromagnetic elds in the

direct vicinity of the device (e.g.mobile telephones, microwave ovens) or less than 1,5

km from AM, FM or TV broadcast antennas. These may lead to temporary impairment of

measurement accuracy.

15. Dispose of device, batteries, components and accessories according to local regulations.

16. This monitor may not meet its performance specication if stored or used outside tem-

perature and humidity ranges specied in Specications.

Measurement Method Oscillometric

Measurement Range Pressure: 30~260 mmHg; Pulse: 40~199 beats/

minute

Pressure Sensor Semi conductor

Accuracy Pressure: ± 3 mmHg; Pulse: ± 5% of reading

Inflation Pump Driven

Deflation Automatic Air Release Valve

Memory capacity 60 memories for each zone x 2 zones

Auto-shut-off 1 minute after last key operation

Permissible Operating Temperature

and Humidity 10°C~40°C (50°F~104°F); %~85% RH; 700~1060 15

hPa

Permissible Transport and Storage

Temperature and Humidity -10°C~60°C (14°F~140°F); 10%~90% RH; 700~1060

hPa

DC Power Source DC 6V four AAA Batteries

AC Power Source DC 6V, (Plug size: outer(-) is Ø4.0, in≥600mA -

ner(+) is Ø1.7)

Dimensions 96 139.7 63.2 (L) X (W) X (H) mm

Weight 248.6g (G.W.) (w/o Batteries)

Arm circumference Adult: 24~40 cm (9.4”~15.7”)

Limited Users Adult users

: Type BF: Device and cuff are designed to provide

special protection against electrical shocks.

IP Classification IP21: Protection against harmful ingress of water

and particulate matter

*Specifications are subject to change without notice.

Recalling Values from Memory

Clearing Values from Memory

Time and Bluetooth® Adjustment

Data Transfer via Bluetooth®

Data Transfer to PC

Troubleshooting

Cautionary Notes

Specications

6. If Bluetooth® has been activated, the data is automatically transferred to the App after suc-

cessful completion of the binding process, please see Data Transfer via Bluetooth®.

This blood pressure monitor will re-inate automatically to higher pressure if the system

detects that more pressure is needed to take a blood pressure measurement.

Note: 1. This monitor automatically switches o approximately 1 minute after last key op-

eration.

2. To interrupt the measurement, simply press the ON/OFF/START key; the cu will deate

immediately.

17. Please note that when inating, the functions of the limb in question may be impaired.

18. During the blood pressure measurement, blood circulation must not be stopped for an

unnecessarily long time. If the device malfunctions, remove the cu from the arm.

19. Avoid any mechanical restriction, compression or bending of the cu line.

20. Do not allow sustained pressure in the cu or frequent measurements. The resulting re-

striction of the blood ow may cause injury.

21. Ensure that the cu is not placed on an arm in which the arteries or veins are undergoing

medical treatment, e.g. intravascular access or therapy, or an arteriovenous (AV) shunt.

22. Do not apply the cu on the side, where a mastectomy has been performed in your

patient history.

23. Do not place the cu over wounds as this may cause further injury.

24. Only ever use the cus provided with the monitor or original replacement cus. Other-

wise erroneous results will be recorded.

25. Batteries can be fatal if swallowed. You should therefore store the batteries and products

where they are inaccessible to small children. If a battery has been swallowed, call a doc-

tor immediately.

26. Do not use the tubing and/or AC adaptor for any other purpose than those specied, as

they can cause risk of strangulation.

27. Do not service or maintain device and cu while in use.

28. This device should not be used adjacent to or stacked with other equipment.

29. Please do not use any other cables or accessories not approved by the manufacturer in

this manual to avoid negative inuence on electromagnetic compatibility.

APP

Electromagnetic Compatibility Information

1. This device needs to be installed and put into service in accordance with the information provided

in the user manual.

2. WARNING: Portable RF communications equipment (including peripherals such as antenna cables

and external antennas) should be used no closer than 30 cm (12 inches) to any part of the X5,

including cables specied by the manufacturer. Otherwise, degradation of the performance of this

device could result.

If higher IMMUNITY TEST LEVELS than those specied in Table 9 are used, the minimum separation

distance may be lowered. Lower minimum separation distances shall be calculated using the

equation specied in 8.10.

Manufacturer’s declaration-electromagnetic immunity

The X5 is intended for use in the electromagnetic environment specied below. The customer or

the user of the X5 should assure that is used in such and environment.

Immunity

test IEC 60601 test level Compliance level Electromagnetic environment-guidance

Conducted

RF IEC

61000-4-6

3 Vrms:

0,15 MHz – 80 MHz

6 Vrms: in ISM and

amateur radio bands

between

0,15 MHz and 80 MHz

80 % AM at 1 kHz

3 Vrms:

0,15 MHz – 80 MHz

6 Vrms: in ISM and

amateur radio bands

between

0,15 MHz and 80 MHz

80 % AM at 1 kHz

Portable and mobile RF communications

equipment should be used no closer to

any part of the X5 including cables, than

the recommended separation distance

calculated from the equation applicable

to the frequency of the transmitter.

Recommended separation distance:

d = 1,2 √P, d = 1,2 √P 80MHz to 800 MHz,

d = 2,3 √P 800MHz to 2,7 GHz

Where P is the maximum output power

rating of the transmitter in watts (W) ac-

cording to the transmitter manufacturer

and d is the recommended separation

distance in metres (m).

Interference may occur in the vicinity of

equipment marked with the following

symbol:

Radiated RF

IEC 61000-

4-3

10 V/m

80 MHz – 2,7 GHz

80 % AM at 1 kHz

10 V/m

80 MHz – 2,7 GHz

80 % AM at 1 kHz

NOTE1: At 80 MHz and 800 MHz, the higher frequency range applies.

NOTE2: These guidelines may not apply in all situations. Electromagnetic propagation is aected

by absorption and reection from structures, objects and people.

More information on EMC compliance of the device can be obtained from Rossmax website: www.

rossmax.com

Notes: 1. Unbinding your device will not delete the data from the App.

2. If you re-bind your smartphone with your blood pressure monitor, all prior reading history

stored on the phone App will be retained.

3. Bluetooth® data transfer will reduce the battery capacity.

IN0X50000000000XX

OBM_IB_X5(2)NA17BT_

EN_SW_ver2021

WARNING: The symbol on this product means that it's an electronic product and

following the European directive 2012/19/EU the electronic products have to be dis-

posed on your local recycling centre for safe treatment. Rossmax Swiss GmbH,

Widnauerstrasse 1, CH-9435 Heerbrugg, Switzerland

Model: X5

www.rossmax.com

Warranty Card

This instrument is covered by a 5 year guarantee from the date of purchase. The guar-

antee is valid only on presentation of the warranty card completed or stamped by the

seller/dealer confirming date of purchase or the receipt. Batteries, cuff and accessories

are not included. Opening or altering the instrument invalidates the guarantee. The

guarantee does not cover damage, accidents or non-compliance with the instruction

manual. Please contact your local seller/dealer or www.rossmax.com.

Customer Name: ____________________________________________________

Address: ___________________________________________________________

Telephone: __________________________________________________________

E-mail address: ______________________________________________________

Product Information

Date of purchase: ___________________________________________________

Store where purchased:

____________________________________________________________________

Blood Pressure Monitor

- The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Rossmax International Ltd. is under

license. Other trademarks and trade names are those of their respective owners.
