Side 1/106

Sheet-fed Duplex Scanner

User’s Manual

Regulatory model: FF-0901H

Avision Inc.

Trademarks

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

Windows and MS-DOS are trademarks of Microsoft Corporation.

IBM, IBM PC are registered trademarks of International Business

Machines Corp.

ENERGY STAR® is a U.S. registered mark.

Other brands and product names herein are trademarks or

registered trademarks of their respective holders.

reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language,

in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual, or otherwise, without the prior

written permission of Avision Inc.

Material scanned by this product may be protected by

governmental laws and other regulations, such as copyright

laws, the customer is solely responsible for complying with all

such laws and regulations.

Warranty

The information contained in this document is subject to

change without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties

of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

User’s Manual

Federal Communications Commission (FCC) compliance

information statement

Part 15

The product has been tested and found to comply with the

limits for a Class A digital device pursuant to Part 15 of the FCC

Rules. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference and (2) this

device must accept any interference received including

interference that may cause undesired operation.

The FCC Class A limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction

manual may cause harmful interference in which case the user

will be required to correct the interference at his own expense.

Warning

This is a class A product. In a domestic environment this

product may cause radio interference in which case the

user may be required to take adequate measures.

iii

Disposal of Waste Equipment by Users in Private Union

This symbol on the product or on its packaging indicates that

the product can not be disposed of with your other household

waste. Instead it should be sent to appropriate facilities for

recovery and recycling in an effort to protect human health and

the environment. Fore more information about where you can

drop off your waste equipment for recycling, please contact

your local city office, your household waste disposal service or

the shop where you purchased the product.

As an ENERGY STAR® Partner, Avision Inc. has

determined that this product meets the ENERGY STAR

guidelines for energy efficiency.

User’s Manual

System Requirements

¾ IBM compatible PC 586, Pentium or higher

¾ Microsoft Windows 2000, Windows XP, Windows

Vista/Windows 7

¾ USB port 2.0 (compatible with USB 1.1)

¾ At least 100 MB of free hard disk space (500 MB is

recommended)

¾ At least 128 MB of system memory (512 MB of RAM is

recommended)

At least 1 GB of RAM for Windows Vista

¾ A CD-ROM drive

User’s Manual

2. Scanner Installation

Precautions

 Keep the scanner out of direct sunlight. Direct

exposure to the sun or excessive heat may cause

damage to the unit.

 Do not install the scanner in a humid or dusty place.

 Be sure to use the proper AC power source.

 Place the scanner securely on an even, flat surface.

Tilted or uneven surfaces may cause mechanical or

paper-feeding problems.

 Retain the scanner box and packing materials for

shipping purposes.

2-1

2.1 Installing the ADF Paper Tray

1. Attach the ADF Paper Tray to the clip joint of the

scanner as indicated below. When properly insert, you

will hear a snap-in sound.

ADF Paper

Tray

Clip Joint

2-2

User’s Manual

2.2 Installing the ADF Output Paper Tray

1. Hold the Output paper tray some 30 degrees as shown in

below.

2. Insert the right protrusion of the Output Paper Tray into

the hole on the front of the scanner.

3. Insert the left pin of the Output Paper Tray slightly into the

hole on the front of the scanner.

Scanner

Hole

Output

Paper Tray

2-3

2.3 Installing Front Paper Tray

If you wish to feed paper from the front tray, please remove

the ADF output tray first and then install the front paper tray.

1. Insert the left protrusion of the front paper tray into the

hole on the front of the scanner.

2. Press the right protrusion to fit into the hole of the scanner.

3. Insert the extension wire to the front tray.

Hole

Protrusion

Front Tray

Extension

Wire

2-4

User’s Manual

2.4 Installing the Scanner Driver and Connecting the

Cables

NOTE:

1). The Windows system CD may be required when installing

on some PC’s.

2). To ensure your computer can identify the USB scanner,

please install scanner driver first before connecting the

scanner to your computer.

3). The scanner driver contains both TWAIN driver and WIA

driver. If you are running Windows Me, Windows XP, or

Windows Vista, after the installation of scanner driver is

completed, this scanner allows you to scan via a TWAIN

user interface or a WIA (Windows Image Acquisition)

interface. Start your TWAIN-compatible image editing

software application to select a TWAIN or WIA user

interface. Or you might launch Microsoft’s Scanner and

Camera Wizard to scan via a WIA user interface.

2.4.1 Connecting to Power

Before connecting, make sure the power switch is off.

Plug the small end of the power adaptor into the power jack of

your scanner. Insert the other end to an appropriate power

outlet.

2-5

2.4.2 Turning on the Power

After the power cable has been connected, press the power

switch to the “-” position to turn on the scanner. To turn off

the scanner, please press the power switch to the “O”

position.

Power Switch

2.4.3 Installing the Scanner Driver

NOTE:

1. The Windows system CD may be required when installing

on some PC’s.

2. To ensure your computer can identify the USB scanner,

please install scanner driver first before connecting the

scanner to your computer.

3. The scanner driver contains both TWAIN driver and WIA

driver. If you are running Windows XP, or Windows Vista,

after the installation of scanner driver is completed, this

scanner allows you to scan via a TWAIN user interface or a

WIA (Windows Image Acquisition) interface. Start your

TWAIN-compatible image editing software application to

select a TWAIN or WIA user interface. Or you might

launch Microsoft’s Scanner and Camera Wizard to scan via

a WIA user interface.

2-6

User’s Manual

1. Place the supplied CD-ROM onto your CD-ROM drive.

2. The software installation graphic appears. If not, run

“setup.exe”.

Contents on the installation graphic:

y Install Button Manager: To use the buttons on

the scanner, you need to install Button Manager.

To ensure Button Manager works properly, please

FIRST install Button Manager before installing the

scanner driver.

y Install Scanner Driver: To communicate with

your scanner, you need to install the scanner driver.

After installing the Button Manager software, click

Install Scanner Driver to install the scanner

driver on your computer.

y Install Adobe Reader: To view the user’s

manuals for the scanner and Button Manager, you

need to use Adobe Reader to open and view the

manuals in pdf file format. If you already have

Adobe Reader installed on your computer, you may

disregard this item.

2-7

y View Manual: Click “View Manual” to view or

print the detailed user manual for the scanner and

Button Manager respectively.

3. Click Install Button Manager to install the Button

Manager software and then click Install Scanner Driver

to install the scanner driver on your computer.

2.4.4 Connecting to Computer

1. Connect the square end of the USB cable to the USB port of

your scanner. Connect the rectangle end to the USB port of

your computer.

2. The computer should detect a new USB device and prompt

a “New Hardware Found” message.

2-8

User’s Manual

2-9

3. In Windows 2000, confirm that the “Search for a better

driver.” is selected and click the “Next” button.

In Windows XP, click the Next button to continue. When

the XP certification screen appears, click Continue

Anyway to complete the installation.

4. When the Finish Finish dialog is prompted, click the

button.

Note:

To uninstall the scanner driver in Windows XP, be sure to keep

your scanner connecting to your computer.

User’s Manual

3. Completing Your First

Scan

3.1 Loading Your Paper

3.1.1 Notice on Using the ADF

Before using the ADF, please make sure that your paper meets

the following specifications:

• Document(s) can range in size from 3.5 by 2 inches to

8.5 by 14 inches (Legal).

• Document(s) can range in weight from 9 to 34 lbs

(34~127 g/m 2)

• Document(s) should be square or rectangular and in good

condition (not fragile or worn).

• Document(s) should be free of curl, wrinkle, tears, wet

ink, or punch holes.

• Document(s) should be free of staples, paper clips, paper

sticky notes.

3-1

3.1.2 Placing Your Document in the ADF Paper Tray

Fanning Your Document

Standard paper size should feed easily through the scanner.

To avoid occasional paper jam when automatically feeding

multiple documents, loosen the paper before loading.

Document feeding

Place your document with the text face down on the ADF

Paper Tray. Align the two sides of the document with the

slide guides. Please note that the ADF Paper Tray can hold

up to 50-page document at a time.

Your

Document

(Face

Down)

Paper

Guide

3-2

User’s Manual

3.1.3 Placing Your Document On the Front Tray

Place your document with the text face down on the front tray

as indicated below.

Your

Document

(face

down)

3-3

3.2 Verifying Your Scanner Installation

To verify if your scanner installation is correct, Avision provides

you a useful test program called Avision Capture Tool. With

this tool, you can perform simple scans and view the captured

images. In addition, it helps you complete your scan at a rated

speed.

The following procedure describes how to verify your scanner

installation. If the installation is not correct, please review the

preceding section to check if the cable connection and scanner

driver have been successfully installed.

Before you begin, be sure the scanner is on.

1. Select Start>Programs>Avision AVxxx Scanner>Avision

Capture Tool.

Note: If Avision Capture Tool does not appear on “All

Programs” of your Start menu, please access from the

following path:

C\Windows\TWAIN_32\Avision\Avxxx\Avision Capture

Tool.exe

The Select Scanner Model dialog box will be displayed.

2. Select your driver type and scanner model and click OK.

The following Avision Capture Tool dialog box will be

displayed.

3-4

User’s Manual

Fit

Page

Actual

Size

File Format Save File Path

Setup

Scan

3. Choose your desired file format from the File Format drop

down list box. (Default is BMP, other choice includes TIFF,

MTIFF, PDF, MPDF, GIF, and JPEG.) The supported file

formats vary depending on your scanner model.

4. Type your desired folder name and file name in the File

Path box. (Default is C:\My Scan\Image.)

Note: If you do not wish to save the scanned image,

deselect the Save button since default is Save Enable. In

this case, the thumbnail view will be disabled. And

therefore, after viewing all the scanned images, only the

last one will remain on the screen.

5. Click the Setup button ( ) or choose Setup from the

File menu to prompt the Scanner Properties dialog box.

3-5


Selection

Box

6. From the Image Selection Box, choose your desired image

type for your scanned image. (Default is Front B&W) If

you have a duplex scanner, choose Front and Rear to scan

both sides of your document.

7. Click OK to quit the Scanner Properties dialog box. (To

learn more details about the Scanner Properties dialog box,

please see the subsequent chapter, Using the Scanner

Properties Dialog Box.)

8. Place your document face down on the document glass or

face up in the auto document feeder.

9. In the Scan Validation dialog box, click the Scan button

( ) or choose Scan from the File menu.

10. The document will be scanned and displayed in the Scan

Validation screen. After the scanned images have been

displayed, your scanner installation verification is

completed.

3-6

User’s Manual

Fit Page View

Status Bar

Thumbnail View

11. You can view the scanned image in Fit Page ( ) or

Actual Size (100%) button ( ) from the Viewing toolbars

at the right side.

12. Click the Close box or Quit from the File menu to exit the

Scan Validation Tool.

3-7

3-8

3.1.4 A Glance of the Scanner Properties Dialog Box

2 3

1. Tab Options Choice: Image, Compression, Color Dropout,

Paper, Options, Settings, Information.

2. Image

Selection Box

Choose your image type and the side of

document you wish to scan. Options vary

based on type of scanner.

3. Brightness: Adjust the brightness level from –100 to +100.

4. Contrast Adjust the contrast level from –100 to +100.

5. Resolution Determine the quality of the scanned image.

The industry standard is 200 dpi.

6. Invert Reverse the color of your scanned image.

7. Scan Source

Choice: Auto Document Feeder, Flatbed,

Flatbed (Book), Automatic (varies due to

different scanner model)

8. Defaults Reset all values on the tabs to the factory

default settings.

User’s Manual

4. Using the Scanner

Properties Dialog Box

The Scanner Properties dialog box allows you to conﬁgure the

scanner’s settings. It consists of several tabbed windows each

of which will be described in this chapter.

The Scanner Properties dialog box

4-1

4.1 Buttons on the Scanner Properties Dialog Box

The buttons on the Scanner Properties dialog box

Buttons Description

Defaults Defaults Click the button, the factory default

settings will be shown on each tab.

Scan After all the scan settings are satisfactory, click

the Scan button to start scanning your

document.

Close Close Click the button to leave the Scanner

Properties dialog box.

4-2

User’s Manual

The following table shows the default settings：

Tab name Default settings

Image Image：Front B&W

Binarization：Dynamic Threshold

Resolution：200 dpi

Invert：Blank on White

Scan Source：Auto Document Feeder

Threshold：None

Brightness：None

Contrast：None

Compression None

Color Dropout

None

Paper Cropping：Automatic

Deskew：Yes

Orientation：Portrait

OverScan：0.00

Multifeed Detection：None

Unit：Inch

Options Rotation Degrees：None

Blank Page Removal：None

Edge Fill：，White 0 mm

Image Control Option：None

Setting Enable Energy Saver：Enable, 15

minutes after last scan action

Show Scanning Progress：Yes

Show Warning Message：Yes

Save Settings after Closing：Yes

4-3

4.2 The Image Tab

The Image tab allows you to choose the front side and (or) the

rear side of your document, the type of image, and to set

several basic scan settings. Note that except for the resolution,

you can set individual scan settings for the front side and the

rear side. For example, all settings in the Image tab,

Compression tab, Color Dropout tab can be set individually for

the front and the rear side. However, the settings in the Paper

tab, the Option tab, and the Setting tab have to be set the

same for the front and rear side.

The Image tab dialog box

4-4

User’s Manual

4.2.1 The Image Selection Box

The Image Selection box inclu

the image type and document s

option. If you wish to scan both

front side and the rear side of y

color document, you can check b

Front Color and Rear Color at

same time. Note the options v

based on type of scanner.

Example 1：

：

：：Scanning a two-sided color document, both

sides in color

Side/Image

Selection

Front

Rear

4-5

4.2.2 Other Image Options

Binarization

This is the process of converting a

grayscale or color image to a bi-tonal

image. There are several different

methods of performing this conversion.

Options: Dynamic Threshold, Fixed

Processing, Halftone 1~5, Error

Diffusion.

Dynamic Threshold: Selecting

Dynamic Threshold allows the scanner

to dynamically evaluate each document

to determine the optimal threshold value

to produce the highest quality image.

This is used to scan mixed document

containing faint text, shaded background,

or color background with a single setting.

If Dynamic Threshold is selected,

Threshold, Brightness, and Contrast are

not available.

Sensitivity of Dynamic Threshold

Occasionally your scanned image may

contain small dots or speckles. To remove

these spots, increase the sensitivity value

by moving the bar to the right. The value

ranges from 1 to 30. The default is 20.

4-8

User’s Manual

Fixed Processing: Used for black-and-

white and other high contrast documents. A

single level is set to determine the black-

and-white transition. The threshold is

programmable over the entire density

range. Fixed Processing sets Contrast to

0. If Fixed Processing is selected,

Contrast is not available.

Halftone: In addition to the black and

white display, Halftone can present a

somehow gray shade of image by using

different size of dots. Halftone image looks

like the picture we have seen in the

newspaper. Options include Halftone 1,

Halftone 2, Halftone 3, Halftone 4,

Halftone 5.

Error Diffusion: Error Diffusion is a type

of Halftone. Error Diffusion gives good

image texture and makes text in images

more readable than Halftone.

Halftone Image

4-9

Error Diffusion Image

4-10

User’s Manual

Threshold Used to convert a grayscale image to a

bi-tonal image. The value ranges from 0 to

255. A low threshold value produces a

lighter image, and can be used to subdue

backgrounds and subtle, unneeded

information. A high threshold value produces

a darker image, and can be used to help pick

up faint images.

Adjust the threshold setting by dragging the

Threshold sliding bar to the left or right to

achieve the desired threshold setting.

200 dpi,

Threshold:80,

Brightness: 0

200 dpi,

Threshold:170,

Brightness: 0

4-11

Gray

Document Type: Choice: Normal, Photo, Document

Three options of document type are provided when you choose

Gray as the image type for your scanned document. Choice:

Normal, Photo, Document.

• Document: Choose Document if your original contains

pure text or a mixture of text and graphic since it is an

optimal setting for regular business document. When

using Document, only Threshold can be adjusted.

• Photo: Choose Photo if your original contains photo to

reproduce your photo in vivid grayscale image. When

using Photo, no Threshold and Contrast can be adjusted.

• Normal: Normal When using , Threshold, Brightness, and

Contrast can be adjusted.

Threshold: The value ranges from 0 to 255. The default is

230. A low threshold value produces a lighter image, and can

be used to subdue backgrounds and subtle, unneeded

information. A high threshold value produces a darker image,

and can be used to help pick up faint images. Adjust the

threshold setting by dragging the Threshold sliding bar to the

left or right to achieve the desired threshold setting.

4-12

User’s Manual

Normal


Document

(Threshold: 230)

Normal


Document

(Threshold: 230)

4-13

Brightness Adjusts the lightness or darkness of an

image. The higher the value, the brighter

the image. Drag the slider to the right or

left to increase or decrease the brightness.

The range is from –100 to +100.

Contrast Adjusts the range between the darkest and

the lightest shades in the image. The

higher the contrast, the bigger the different

grayscale. Drag the slider to the right or

left to increase or decrease the contrast.

The range is from –100 to +100.

Brightness: -50 Brightness: 0

(Normal)

Brightness: +50

Contrast: -50 Contrast: 0

(Normal)

Contrast: +50

4-14

User’s Manual

Resolution A good control of the resolution results a

good detail of an image that scans. The

resolution is measured by dots per inch

(dpi). Normally, the greater the dpi number,

the higher the resolution and the image file

size. Be aware that greater resolution takes

more time to scan, and more disk space for

the scanning image. For your information,

an A4 size color image scanned at 300 dpi at

True Color mode consumes approximately 25

MB of disk space. A higher resolution

(usually means over 600 dpi) is only

recommended when you need to scan a

small area at True Color mode.

Choose a resolution value from the drop

down list. The default value is 200 dpi.

Available resolutions are 75, 100, 150,

200,300, 400 and 600. Or you may choose

your desired value by clicking the box in the

right side of the drop down list and press the

arrow key to select your desired value and

then click the Add button to include it in the

drop down list. Note: The resolution is up to

300 dpi if an imprinter or a MICR reader is

installed or connected to the scanner.

Resolution: 75 dpi

Resolution: 150 dpi

4-15

Invert Reverses the brightness and the colors in the

image. The default setting is Black on a White

background. Reverse mode is White on a Black

background. For color images, each pixel will be

changed into its complementary color at the

command of Invert.

Black on White

White on Black

4-16

User’s Manual

Scan

Source

Choice:

y Auto Document Feeder: Used to scan

multiple pages.

y Flatbed: Used to scan a single page. For

example, pages from newspaper clipping,

paper with wrinkles or curls.

y Flatbed (book): Used to scan several

inside pages from book.

y Automatic: Allow the scanner automatically

set its scan source. If Automatic is selected

and there is document in both the auto

document feeder (ADF) and the flatbed, then

the scan source will be automatically set to

ADF. If Automatic is selected and there is

document only in flatbed, then the scan

source will be set to flatbed.

y Merge Two Sides into One Image:

If you have a sheet-fed duplex scanner with

front input tray, you can scan an A3 size

document with an innovative method. Thus,

fold your A3 size document into A4, and then

load the paper in the front tray. Choose

Merge Two Sides from the Scan Source

option and then the scanner is able to scan

both sides of your document and merge two

A4 images into one A3 image.

When you select Merge Two Sides into One

Image, the Cropping or Multi-feed function

will be disabled.

Note the options vary based on type of

scanner.

4-17

Color

Matching

The purpose of Color Matching is getting the

accurate color. This option uses the default

parameters (ICC profile) to adjust the colors

of the image.

Normal

After Color Matching

4.2.3 Scanning color images

The following options are available for scanning color images.

y Brightness

y Contrast

y Resolution

y Invert

4-18

User’s Manual

4.2.4 Scanning grayscale images

The following options are available for scanning gray images.

y Brightness

y Contrast

y Resolution

y Invert

4.2.5 Scanning B&W images

The following options are available for scanning B&W images.

y Binarization (Dynamic Threshold)

y Resolution

y Invert

y Binarization (Fix Processing)

y Threshold

y Brightness

y Resolution

y Invert

4-19

4.2.6 Editing Profiles

The Scanner Properties dialog box allows you to change and

save your frequently used scan settings into a profile. You can

edit these profiles by renaming or deleting them.

To add a new profile,

1. Customize your settings. (For example, change your

resolution, image type, cropping method, scan size, or

other scan settings.)

2. Click the Image tab and then choose “Profiles” to prompt

the “Edit Your Profile” dialog box.

3. Click “Add” to enter the name of the profile and then

choose “Save”.

4. The new profile will be saved and shown in the “Profiles”

dropdown list box.

4-20

User’s Manual

To load a profile,

1. From the Image tab dialog box, choose your favorable

profile from the “Profiles” dropdown list box.

2. Your favorable profile will be immediately loaded and

displayed on Scanner Properties dialog box.

To delete a profile,

1. From the Image tab dialog box, click “Profiles” to prompt

the Edit Your Profile dialog box.

2. Choose the profile you want to delete from the dropdown

list box.

3. Click “Delete”. A Confirm message “Are you sure you

want to delete this profile?” is prompted.

4. Choose “Yes” to delete or “Cancel” to quit.

4-21

To rename a profile,

1. From the Image tab dialog box, click “Profiles” to prompt

the Edit Your Profile dialog box.

2. Choose the profile you want to rename from the dropdown

list box and then click the Rename button.

3. Enter new name for the profile.

4. Choose “Save” to save the new profile or “Cancel” to quit.

Note:

The preset default profiles include Flatbed, Simplex-B&W, 200

dpi, Simplex-Gray, 200 dpi, Simplex-Color, 200 dpi, Duplex-

B&W, 200 dpi, Duplex-Gray, 200 dpi, Duplex-Color, 200 dpi. If

you have a simplex or a sheetfed scanner, the duplex or the

flatbed option will not be available.

4-22

User’s Manual

4.3 The Compression Tab

The Compression tab allows you to compress your scanned

image and choose the level of compression. Bi-tonal images

are normally compressed using CCITT standard called Group 4

(G4). Color and grayscale images are often compressed using

JPEG technology. Move the JPEG Quality slider to the right or

left to increase or decrease the level of compression. Note the

greater the compression level, the lower image quality. Default

is 50%.

Note that the compression depends on your image editing

application. If your image editing application does not support

the type of compression format, then either a warning

message will appear or the image quality of the compressed file

will not be acceptable.

JPEG (Joint Photographic Editor Group). This group developed

and lent their name to a file compression standard for color and

grayscale images that is widely used by scanners, and software

applications. On Microsoft Windows-based systems, a file with

the extension .jpg has normally been compressed using this

standard.

For scanning color or gray images, the following compressions

are available:

y None

y JPEG

For scanning B&W images, the following compressions are

available:

y None

y G4

4-23

Produkt Specifikationer

Mærke:	Avision
Kategori:	Scanner
Model:	AV220D2+
Bredde:	337 mm
Dybde:	168 mm
Højde:	162 mm
Vægt:	3600 g
Produktfarve:	Black, White
Indbygget skærm:	Ingen
USB-port:	Ja
Strømforbrug (standby):	24 W
Strømforbrug (typisk):	37 W
Maksimal ISO A-serie papirstørrelse:	A4
ISO A-serie, størrelser (A0...A9):	A4
Scanner type:	ADF-scanner
Optisk scanningsopløsning:	600 x 600 dpi
Input farvedybde:	48 Bit
Output farvedybde:	24 Bit
Intern hukommelse:	256 MB
Strømforsyningstype:	Vekselstrøm
Dimensioner (BxDxH):	337 x 168 x 162 mm
Strømforbrug (strømbesparelse):	5 W
USB version:	2.0
Bæredygtighedscertifikater:	ENERGY STAR
Medfølgende software:	Button Manager, AVScan, PaperPort 11, ScanProfolio
Kompatible operativsystemer:	Windows 2K, Windows XP, Windows Vista, Windows 7
Sensortype:	CCD
Standard grænseflader:	USB 2.0
Duplex scanning:	Ingen
Automatisk dokumentføder (ADF) medievægt:	28 - 158 g/m²
Maksimal scanningsstørrelse:	216 x 910 mm
Farvescanning:	Ja
ADF-scanningshastighed (sort/hvid, A4):	50 sider pr. minut
ADF-scanningshastighed (farve, A4):	50 sider pr. minut
Daglig driftscyklus (maks.):	- Sider
Scan drivere:	ISIS, TWAIN
Lyskilde:	CCFL
Maksimalt scanningsområde (ADF):	216 x 356 mm
Mindste scanningsområde (ADF):	50 x 74 mm
Scanning af film:	Ingen
Duplex ADF-scanningshastighed (sort/hvid, A4):	100 ipm
Duplex ADF-scanningshastighed (farve, A4):	100 ipm
Standard indgangskapacitet:	50 ark
